Grand Ledge - Abrams Muni
Airport details
| Country | United States of America |
| State | Michigan |
| Region | K5 |
| Airspace | Cleveland Ctr |
| Municipality | Grand Ledge |
| Elevation | 839ft (256m) |
| Timezone | GMT -5 |
| Coordinates | 42.77488, -84.73314 |
| Magnetic var | |
| Type | land |
| Available since | X-Plane v10.30 |
| ICAO code | 4D0 |
| IATA code | n/a |
| FAA code | 4D0 |
Communication
| Abrams Muni CTAF/UNICOM | 122.700 |
| Abrams Muni LANSING Approach/Departure | 118.650 |
Runway info
Runway 9 / 27  | ||
| length | 973m (3192ft) | |
| bearing | 87° / 267° | |
| width | 23m (75ft) | |
| surface | asphalt | |
| Runway 18 / 36 | ||
| length | 787m (2582ft) | |
| bearing | 180° / 0° | |
| width | 37m (120ft) | |
| surface | grass | |
| displ threshold | 121m (397ft) / 121m (397ft) | |
Nearby beacons
| code | identifier | dist | bearing | frequency |
|---|---|---|---|---|
| GR | KNOBS (GRAND RAPIDS) NDB | 29.3 | 281° | 263 |
| BT | BATOL (BATTLE CREEK) NDB | 31.8 | 228° | 272 |
| JXN | DME | 33.2 | 152° | 115.45 |
| VIO | VICTORY VOR/DME | 33.6 | 271° | 115.95 |
| LFD | LITCHFIELD VOR/DME | 42.8 | 183° | 111.20 |
| FNT | FLINT VORTAC | 44.9 | 79° | 116.90 |
| MB | OLSTE (SAGINAW) NDB | 47.8 | 39° | 257 |
| AZO | KALAMAZOO VOR/DME | 48.5 | 237° | 109 |
| MOP | MOUNT PLEASANT VOR/DME | 50.9 | 360° | 110.60 |
| AZ | AUSTN (KALAMAZOO) NDB | 52.3 | 231° | 371 |
| MBS | SAGINAW VOR/DME | 53.7 | 41° | 112.90 |
| TCU | TECUMSEH NDB | 58.2 | 131° | 239 |
| ADG | ADRIAN NDB | 61.6 | 144° | 278 |
| HIC | WHITE CLOUD VOR/DME | 64.5 | 309° | 117.60 |
| IRS | STURGIS NDB | 65.6 | 216° | 382 |
Instrument approach procedures
| runway | airway (heading) | route (dist, bearing) |
|---|---|---|
| RW09 | YEVUD (87°) | YEVUD 3000ft |
| RNAV | YEVUD 3000ft ZABVU (6mi, 87°) 2500ft 4D0 (5mi, 87°) 871ft (5173mi, 117°) 1241ft CUTTY (5173mi, 297°) 3000ft CUTTY (turn) |
Disclaimer
The information on this website is not for real aviation. Use this data with the X-Plane flight simulator only! Data taken with kind consent from X-Plane 12 source code and data files. Content is subject to change without notice.
