Airports for X-Plane

Shaunavon

Airport details

CountryCanada
StateSaskatchewan
RegionCY
AirspaceWinnipeg Ctr
MunicipalityShaunavon
Elevation3027ft (923m)
TimezoneGMT -6
Coordinates49.65833, -108.40592
Magnetic var
Typeland
Available sinceX-Plane v10.40
ICAO codeCJC5
IATA coden/a
FAA coden/a

Communication

Shaunavon CTAF122.800

Runway info

Runway 12 / 30
 length926m (3038ft)
 bearing123° / 303°
 width23m (75ft)
 surfaceasphalt
Runway 02 / 20
 length1019m (3343ft)
 bearing52° / 232°
 width12m (39ft)
 surfacehard surface
 displ threshold171m (561ft) / 93m (305ft)

Airport layout


Nearby beacons

codeidentifierdistbearingfrequency
YYNSWIFT CURRENT VOR/DME47.248°117.40

Instrument approach procedures

runwayairway (heading)route (dist, bearing)
RW12UKIGO (102°)UKIGO
PIBTI (6mi, 57°) 4800ft
RW12YYN (228°)YYN
SAXIX (41mi, 242°) 4800ft
PIBTI (6mi, 237°) 4800ft
 RNAVPIBTI 4800ft
OBRER (6mi, 123°) 4700ft
CJC5 (5mi, 123°) 3059ft
VEPRO (7mi, 124°) 5200ft
VEPRO (turn)
RW30XIDUN (335°)XIDUN
LISPI (6mi, 57°) 4700ft
RW30YYN (228°)YYN
URMUR (45mi, 210°) 4700ft
LISPI (6mi, 238°) 4700ft
 RNAVLISPI 4700ft
KEPDO (6mi, 304°) 4700ft
DUXUK (2mi, 303°) 4020ft
CJC5 (3mi, 304°) 3067ft
AVAXU (7mi, 303°) 5200ft
AVAXU (turn)
