Airports for X-Plane

Chetwynd

Airport details

CountryCanada
StateBritish Columbia
RegionCY
AirspaceEdmonton Ctr
MunicipalityChetwynd
Elevation2000ft (610m)
TimezoneGMT -7
Coordinates55.68722, -121.62665
Magnetic var
Typeland
Available sinceX-Plane v10.40
ICAO codeCYCQ
IATA codeYCQ
FAA coden/a

Communication

CHETWYND LWIS122.550
CHETWYND CTAF123.200

Runway info

Runway 05 / 23
 length1364m (4475ft)
 bearing80° / 260°
 width30m (100ft)
 surfaceasphalt

Airport layout


Parking locations

 GA  Ramp  Tie-Down

Nearby beacons

codeidentifierdistbearingfrequency
YXJFORT SAINT JOHN VOR/DME43.451°114.20
XJFORT SAINT JOHN NDB44.453°326
ZXJTAYLOR (FT ST JOHN) NDB44.563°246

Departure and arrival routes

Transition altitude18000ft
Transition level18000ft
SID end pointsdistanceoutbound heading
RW05
 IRBAS217mi71°

Instrument approach procedures

runwayairway (heading)route (dist, bearing)
RW23-YEPINE (264°)EPINE
OLIPU (4mi, 311°) 4300ft
RW23-YIRBAS (251°)IRBAS 7000ft
OLIPU (6mi, 251°) 4300ft
 RNAVOLIPU 4300ft
KENKA (5mi, 251°) 3900ft
CYCQ (6mi, 251°) 2049ft
PENGU (4mi, 250°)
SPARD (23mi, 249°) 8900ft
SPARD (turn)
RW23-ZEPINE (264°)EPINE
ULOTA (4mi, 311°) 5400ft
RW23-ZIRBAS (251°)IRBAS
ULOTA (6mi, 251°) 5400ft
 RNAVULOTA 5400ft
TOVAV (5mi, 251°) 4100ft
CYCQ (6mi, 251°) 2049ft
SPARD (26mi, 249°) 8900ft
SPARD (turn)
RWNVASPARD (69°)SPARD
IKDIN (6mi, 70°) 7500ft
KEPMA (5mi, 70°) 6000ft
 RNAVKEPMA 6000ft
IMAKI (5mi, 68°) 5200ft
KEDKI (5mi, 68°) 4400ft
ODGEL (3mi, 68°) 3960ft
VISDO (2mi, 68°) 3960ft
KEKDU (4mi, 69°)
EPINE (9mi, 89°) 6300ft
EPINE (turn)
