Breda - Gilze Rijen
Airport details
| Country | Netherlands |
| State | North Brabant |
| Region | EH |
| Airspace | Amsterdam Ctr |
| Municipality | Rijen |
| Elevation | 47ft (14m) |
| Timezone | GMT +1 |
| Coordinates | 51.56887, 4.92522 |
| Magnetic var | |
| Type | land |
| Available since | X-Plane v10.40 |
| ICAO code | EHGR |
| IATA code | GLZ |
| FAA code | n/a |
Communication
| Gilze Rijen Tower | 125.325 |
| Gilze Rijen RAPCON WEST | 123.575 |
Approach frequencies
| ILS-cat-I | RW28 | 111.9 | 18.00mi |
| 3° GS | RW28 | 111.9 | 18.00mi |
Runway info
Runway 10 / 28  | ||
| length | 2771m (9091ft) | |
| bearing | 96° / 276° | |
| width | 45m (148ft) | |
| surface | asphalt | |
| displ threshold | 130m (427ft) / 101m (331ft) | |
| Runway 02 / 20 | ||
| length | 2030m (6660ft) | |
| bearing | 27° / 207° | |
| width | 30m (98ft) | |
| surface | asphalt | |
| displ threshold | 58m (190ft) / 59m (194ft) | |
Nearby beacons
| code | identifier | dist | bearing | frequency |
|---|---|---|---|---|
| GZR | GILZE-RIJEN TACAN | 0.3 | 109° | 116.40 |
| EHV | EINDHOVEN TACAN | 18.3 | 105° | 117.20 |
| WDT | WOENSDRECHT TACAN | 22.9 | 258° | 115 |
| FRT | DME | 26.7 | 340° | 117.15 |
| BUN | BRUNO VOR/DME | 27.2 | 190° | 110.60 |
| ONW | ANTWERP NDB | 27.6 | 222° | 355 |
| ANT | ANTWERP (DEURNE) VOR/DME | 28.3 | 230° | 113.50 |
| RTM | ROTTERDAM VOR/DME | 29.3 | 312° | 110.40 |
| VKL | VOLKEL TACAN | 29.6 | 84° | 108.30 |
| BBL | KLEINE BROGEL TACAN | 31.4 | 127° | 109.60 |
| NIK | NICKY VOR/DME | 36.8 | 241° | 117.40 |
| OP | BRUSSELS NATIONAL NDB | 39.8 | 208° | 402 |
| OB | BRUSSELS NDB | 40.6 | 205° | 293 |
| FLO | FLORA VOR/DME | 42.3 | 163° | 112.05 |
| BUB | BRUSSELS VOR/DME | 42.5 | 210° | 114.60 |
| DLN | DEELEN TACAN | 45.8 | 63° | 112.20 |
| SPL | SCHIPHOL (AMSTERDAM) VOR/DME | 46.2 | 347° | 108.40 |
| PAM | PAMPUS VOR/DME | 46.4 | 12° | 117.80 |
| AMS | DME | 46.5 | 344° | 113.95 |
| OZ | BRUSSELS NATIONAL NDB | 47.7 | 212° | 314 |
| NW | MAASTRICHT NDB | 48.6 | 120° | 373 |
| BBE | BEAUVECHAIN TACAN | 49.1 | 191° | 116 |
| HTB | BEAUVECHAIN NDB | 49.2 | 191° | 381 |
| AFI | AFFLIGEM VOR/DME | 49.5 | 230° | 114.90 |
| HUL | HULDENBERG VOR/DME | 50.3 | 199° | 117.55 |
| ONL | LIEGE NDB | 57.1 | 144° | 290 |
| FRO | DME | 57.2 | 33° | 111.40 |
| SPY | DME | 58.4 | 356° | 113.30 |
| LGE | LIEGE VOR/DME | 58.6 | 149° | 115.45 |
| LNO | OLNO VOR/DME | 66 | 141° | 112.80 |
Disclaimer
The information on this website is not for real aviation. Use this data with the X-Plane flight simulator only! Data taken with kind consent from X-Plane 12 source code and data files. Content is subject to change without notice.
