Country | Poland |
State | Silesian Voivodeship |
Region | EP |
Airspace | Warsaw Ctr |
Municipality | gmina Ożarowice |
Elevation | 995ft (303m) |
Timezone | GMT +1 |
Coordinates | 50.47417, 19.08000 |
Magnetic var | |
Type | land |
Available since | X-Plane v10.40 |
ICAO code | EPKT |
IATA code | KTW |
FAA code | n/a |
Pyrzowice ATIS | 120.230 |
Pyrzowice Tower | 129.255 |
Pyrzowice Approach | 121.075 |
Pyrzowice Approach | 135.405 |
Pyrzowice Dep/Delivery | 121.805 |
ILS-cat-II | RW27 | 109.9 | 18.00mi |
3° GS | RW27 | 109.9 | 18.00mi |
Runway 09 / 27 | ||
length | 3191m (10469ft) | |
bearing | 90° / 270° | |
width | 45m (148ft) | |
surface | concrete | |
displ threshold | 0m (0ft) / 319m (1047ft) | |
blast zone | 32m (105ft) / 30m (98ft) |
code | identifier | dist | bearing | frequency |
---|---|---|---|---|
KAX | KATOWICE VOR/DME | 0.2 | 55° | 114.80 |
PSZ | DME | 30.2 | 205° | 116.90 |
WIE | DME | 33.1 | 305° | 109.65 |
KAK | KRAKOW VOR/DME | 36.1 | 119° | 112.80 |
N | NADA (OSTRAVA) NDB | 58.3 | 231° | 258 |
OTA | OSTRAVA VOR/DME | 59.7 | 231° | 117.45 |
R | RADA (OSTRAVA) NDB | 61.2 | 231° | 534 |
Transition altitude | 6500ft |
SID end points | distance | outbound heading | |
---|---|---|---|
RW09 | |||
NAVU3L | 45mi | 57° | |
KURO3L | 42mi | 82° | |
LUXA4L | 87mi | 105° | |
REGT2L | 89mi | 124° | |
BABK3L | 54mi | 156° | |
TUSI3L | 42mi | 219° | |
BAVO3L | 44mi | 242° | |
EMBI3L | 41mi | 255° | |
NUMB3L | 38mi | 264° | |
SUDO3L | 28mi | 285° | |
BARE3L | 28mi | 321° | |
RW27 | |||
NAVU3M | 45mi | 57° | |
KURO3M | 42mi | 82° | |
LUXA4M | 87mi | 105° | |
REGT2M | 89mi | 124° | |
BABK3M | 54mi | 156° | |
TUSI3M | 42mi | 219° | |
BAVO3M | 44mi | 242° | |
EMBI3M | 41mi | 255° | |
NUMB3M | 38mi | 264° | |
SUDO3M | 28mi | 285° | |
BARE3M | 28mi | 321° |
STAR starting points | distance | inbound heading | |
---|---|---|---|
RW09 | |||
BAVO3V | 44.2 | 62° | |
MAPI3V | 31.9 | 94° | |
BARE3V | 28.3 | 141° | |
KUKA3V | 42.3 | 251° | |
GOVR3V | 78.0 | 281° | |
LENO3V | 101.2 | 301° | |
MEBA3V | 65.0 | 331° | |
RW27 | |||
BAVO3D | 44.2 | 62° | |
MAPI3D | 31.9 | 94° | |
BARE3D | 28.3 | 141° | |
KUKA3D | 42.3 | 251° | |
GOVR3D | 78.0 | 281° | |
LENO3D | 101.2 | 301° | |
MEBA3D | 65.0 | 331° |
runway | airway (heading) | route (dist, bearing) |
---|---|---|
RW09 | EZWOP (90°) | EZWOP 5000ft ONZIL (5mi, 90°) 4000ft |
RNAV | ONZIL 4000ft KT736 (5mi, 90°) 3000ft EPKT (7mi, 91°) 1020ft KT417 (19mi, 90°) 4000ft | |
RW27 | PABWO (270°) | PABWO 5000ft TOZIZ (5mi, 270°) 4000ft |
RNAV | TOZIZ 4000ft KT536 (5mi, 270°) 3000ft EPKT (7mi, 270°) 1053ft KT411 (13mi, 270°) KT373 (6mi, 241°) 4000ft |
STAR name | hold at | type | turn | heading* | altitude | leg | speed limit |
---|---|---|---|---|---|---|---|
BARE3D | BAREX | VHF | left | 331 (151)° | 1.0min timed | 230 | |
BARE3D | PABWO | VHF | left | 86 (266)° | 1.0min timed | 230 | |
BARE3V | BAREX | VHF | left | 331 (151)° | 1.0min timed | 230 | |
BARE3V | EZWOP | VHF | left | 265 (85)° | 1.0min timed | 230 | |
BAVO3D | IVMEM | VHF | right | 230 (50)° | 1.0min timed | 230 | |
BAVO3D | PABWO | VHF | left | 86 (266)° | 1.0min timed | 230 | |
BAVO3V | EZWOP | VHF | left | 265 (85)° | 1.0min timed | 230 | |
BAVO3V | KT742 | VHF | right | 232 (52)° | 1.0min timed | 230 | |
GOVR3D | PABWO | VHF | left | 86 (266)° | 1.0min timed | 230 | |
GOVR3D | XENGO | VHF | right | 124 (304)° | 1.0min timed | 230 | |
GOVR3V | EZWOP | VHF | left | 265 (85)° | 1.0min timed | 230 | |
GOVR3V | XENGO | VHF | right | 124 (304)° | 1.0min timed | 230 | |
KUKA3D | KUKAM | VHF | right | 4 (184)° | 1.0min timed | 230 | |
KUKA3D | PABWO | VHF | left | 86 (266)° | 1.0min timed | 230 | |
KUKA3V | EZWOP | VHF | left | 265 (85)° | 1.0min timed | 230 | |
KUKA3V | UPMAK | VHF | right | 319 (139)° | 1.0min timed | 230 | |
LENO3D | ERKEB | VHF | right | 145 (325)° | 1.0min timed | 230 | |
LENO3D | PABWO | VHF | left | 86 (266)° | 1.0min timed | 230 | |
LENO3V | EZWOP | VHF | left | 265 (85)° | 1.0min timed | 230 | |
LENO3V | MODGU | VHF | right | 179 (359)° | 1.0min timed | 230 | |
MAPI3D | MAPIK | VHF | left | 232 (52)° | 1.0min timed | 230 | |
MAPI3D | PABWO | VHF | left | 86 (266)° | 1.0min timed | 230 | |
MAPI3V | EZWOP | VHF | left | 265 (85)° | 1.0min timed | 230 | |
MAPI3V | MAPIK | VHF | left | 232 (52)° | 1.0min timed | 230 | |
MEBA3D | PABWO | VHF | left | 86 (266)° | 1.0min timed | 230 | |
MEBA3D | UVRET | VHF | left | 183 (3)° | 1.0min timed | 230 | |
MEBA3V | EZWOP | VHF | left | 265 (85)° | 1.0min timed | 230 | |
MEBA3V | UVRET | VHF | left | 183 (3)° | 1.0min timed | 230 | |
*) magnetic outbound (inbound) holding course |
