Country | Poland |
State | West Pomeranian Voivodeship |
Region | EP |
Airspace | Warsaw Ctr |
Municipality | gmina Goleniów |
Elevation | 153ft (47m) |
Timezone | GMT +1 |
Coordinates | 53.58472, 14.90222 |
Magnetic var | |
Type | land |
Available since | X-Plane v10.40 |
ICAO code | EPSC |
IATA code | SZZ |
FAA code | n/a |
Szczecin Goleniow ATIS | 132.125 |
Szczecin Goleniow Szczecin Tower | 121.250 |
ILS-cat-I | RW31 | 110.5 | 18.00mi |
3° GS | RW31 | 110.5 | 18.00mi |
code | identifier | dist | bearing | frequency |
---|---|---|---|---|
SCZ | SZCZECIN VOR/DME | 0.9 | 297° | 114.75 |
HC | HERINGSDORF NDB | 30.9 | 292° | 330 |
TSN | SWIDWIN TACAN | 35.8 | 78° | 116 |
ND | SWIDWIN NDB | 36 | 78° | 280 |
DRE | DME | 56.9 | 130° | 115.30 |
Transition altitude | 6500ft |
SID end points | distance | outbound heading | |
---|---|---|---|
RW13 | |||
NEHI1D | 25mi | 41° | |
UNVO1D | 23mi | 96° | |
APNE1E, APNE1D | 24mi | 130° | |
PESE1D | 21mi | 262° | |
BINK1D | 25mi | 286° | |
RW31 | |||
NEHI1F | 25mi | 41° | |
UNVO1F | 23mi | 96° | |
APNE1F | 24mi | 130° | |
PESE1F | 21mi | 262° | |
BINK1F | 25mi | 286° |
STAR starting points | distance | inbound heading | |
---|---|---|---|
RW13 | |||
BODL1A | 25.5 | 58° | |
FARC1A | 30.7 | 114° | |
OBDE1A | 21.4 | 196° | |
ELTU1A | 19.2 | 260° | |
ZAWI1A | 28.0 | 294° | |
RW31 | |||
BODL1B | 25.5 | 58° | |
FARC1B | 30.7 | 114° | |
OBDE1B | 21.4 | 196° | |
ELTU1B | 19.2 | 260° | |
ZAWI1B | 28.0 | 294° |
runway | airway (heading) | route (dist, bearing) |
---|---|---|
RW13 | ORBOF (117°) | ORBOF 3500ft SC412 (2mi, 117°) 2600ft |
RW13 | SEFIF (117°) | SEFIF 2200ft SC414 (7mi, 264°) SC413 (5mi, 297°) SC412 (5mi, 55°) 2200ft |
RNAV | SC412 2200ft SC411 (5mi, 117°) 1700ft EPSC (5mi, 117°) 169ft SC421 (4mi, 117°) SEFIF (5mi, 297°) 2200ft | |
RW31 | SEFIF (117°) | SEFIF 2200ft SC524 (8mi, 162°) SC523 (5mi, 117°) SC522 (5mi, 56°) 2200ft |
RW31 | ZOCEK (297°) | ZOCEK 3500ft SC522 (2mi, 298°) 2600ft |
RNAV | SC522 2200ft SC521 (5mi, 297°) 1700ft EPSC (5mi, 297°) 205ft SC531 (5mi, 297°) SEFIF (4mi, 117°) 2200ft |
STAR name | hold at | type | turn | heading* | altitude | leg | speed limit |
---|---|---|---|---|---|---|---|
ELTU1A | ELTUB | VHF | left | 45 (225)° | 1.0min timed | 230 | |
ELTU1B | ELTUB | VHF | left | 45 (225)° | 1.0min timed | 230 | |
OBDE1A | OBDEJ | VHF | left | 355 (175)° | 1.0min timed | 230 | |
OBDE1B | OBDEJ | VHF | left | 355 (175)° | 1.0min timed | 230 | |
ZAWI1A | ZAWIK | VHF | left | 125 (305)° | 1.0min timed | 230 | |
ZAWI1B | ZAWIK | VHF | left | 125 (305)° | 1.0min timed | 230 | |
*) magnetic outbound (inbound) holding course |
