Airports for X-Plane

Sta Cruz De La Palma - La Palma Island - La Palma

Airport details

CountrySpain
StateCanary Islands
RegionGC
AirspaceCanaries Ctr
MunicipalityVilla de Mazo
Elevation106ft (32m)
TimezoneGMT +0
Coordinates28.62639, -17.75556
Magnetic var
Typeland
Available sinceX-Plane v10.40
ICAO codeGCLA
IATA codeSPC
FAA coden/a

Communication

La Palma AWOS118.000
La Palma La Palma Ground121.800
La Palma La Palma Tower118.900
La Palma Canarias126.100
Nearby Points of Interest:
Iglesia de Nuestra Señora de Bonanza, El Paso
-
Iglesia de San Andrés
-
Church of San Mauro Abad y Casa Parroquial

Runway info

Runway 18 / 36
 length2256m (7402ft)
 bearing179° / 359°
 width45m (148ft)
 surfaceasphalt
 displ threshold47m (154ft) / 139m (456ft)

Airport layout


Taxiway locations

 A  B  C
Parking locations

 Spot

Nearby beacons

codeidentifierdistbearingfrequency
BVPALMA DME1.4182°112.40
BXLA PALMA NDB1.4183°389
LGMLA GOMERA VOR/DME45.8138°116
HIEEL HIERRO NDB49.1189°376
HRHIERRO DME49.1189°113.20

Departure and arrival routes

Transition altitude6000ft
SID end pointsdistanceoutbound heading
RW18
 BIMB6U190mi32°
 KONB2U205mi43°
 SAMA6U221mi56°
 VAST5U246mi66°
 SARA1U201mi73°
 KORA7U279mi78°
 LARY2U155mi85°
 TFN4U79mi93°
 GDV4U127mi103°
 LPC6U132mi109°
 TFS3U68mi120°
RW36
 BIMB6T190mi32°
 KONB2T205mi43°
 SAMA6T221mi56°
 VAST5T246mi66°
 SARA1T201mi73°
 KORA7T279mi78°
 LARY2T155mi85°
 TFN4T79mi93°
 GDV4T127mi103°
 LPC6T132mi109°
 TFS3T68mi120°

STAR starting pointsdistanceinbound heading
RW18
 ORTI1Y, ORTI1F178.2203°
 KONB1Y, KONB1N205.1223°
 TERT4T, TERT2F278.2254°
 LARY1Y, LARY1F154.5265°
 RUSI1F, RUSI1N, RUSI1T, RUSI3Y260.5267°
RW36
 ORTI3V, ORTI1A178.2203°
 KONB3V, KONB1Q205.1223°
 TERT7V, TERT2A278.2254°
 LARY1A, LARY1V154.5265°
 RUSI1A, RUSI6V, RUSI4X, RUSI1Q260.5267°

Holding patterns

STAR namehold attypeturnheading*altitudelegspeed limit
KONB1YNASOLVHFright56 (236)°> 4500ftDME 4.5miICAO rules
KONB3VARACOVHFright127 (307)°> 4500ftDME 4.0miICAO rules
LARY1VARACOVHFright127 (307)°> 4500ftDME 4.0miICAO rules
LARY1YNASOLVHFright56 (236)°> 4500ftDME 4.5miICAO rules
ORTI1YNASOLVHFright56 (236)°> 4500ftDME 4.5miICAO rules
ORTI3VARACOVHFright127 (307)°> 4500ftDME 4.0miICAO rules
RUSI1TNASOLVHFright56 (236)°> 4500ftDME 4.5miICAO rules
RUSI3YNASOLVHFright56 (236)°> 4500ftDME 4.5miICAO rules
RUSI4XARACOVHFright127 (307)°> 4500ftDME 4.0miICAO rules
RUSI6VARACOVHFright127 (307)°> 4500ftDME 4.0miICAO rules
TERT4TNASOLVHFright56 (236)°> 4500ftDME 4.5miICAO rules
TERT7VARACOVHFright127 (307)°> 4500ftDME 4.0miICAO rules
*) magnetic outbound (inbound) holding course
