Country | Ethiopia |
State | Amhara Region |
Region | HA |
Airspace | Addis Abeba Ctr |
Municipality | North Gondar |
Elevation | 6541ft (1994m) |
Timezone | GMT +3 |
Coordinates | 12.53234, 37.43180 |
Magnetic var | |
Type | land |
Available since | X-Plane v10.40 |
ICAO code | HAGN |
IATA code | GDQ |
FAA code | n/a |
Gonder Atse Tewodros Ground Control | 121.900 |
Gonder Atse Tewodros Tower | 118.600 |
code | identifier | dist | bearing | frequency |
---|---|---|---|---|
AZZ | GONDER NDB | 2 | 170° | 349 |
BDR | BAHIR DAR VOR/DME | 56 | 187° | 114.40 |
TN | BAHIR DAR NDB | 56.9 | 188° | 420 |
Transition altitude | 12500ft |
SID end points | distance | outbound heading | |
---|---|---|---|
RW17 | |||
AZ20A1, AZ20A2 | 49mi | 41° | |
AZ19A1, AZ19A2 | 50mi | 67° | |
AZ18A1, AZ18A2 | 51mi | 111° | |
AZ17A1 | 52mi | 159° |
STAR starting points | distance | inbound heading | |
---|---|---|---|
RW35 | |||
GN14A2, GN14A3, GN14A1 | 38.6 | 221° | |
GN13A1, GN13A2 | 39.5 | 248° | |
GN12A1, GN12A2 | 41.0 | 291° | |
GN11A1, GN11A2 | 42.0 | 339° | |
GN10A1, GN10A2 | 27.5 | 355° |
runway | airway (heading) | route (dist, bearing) |
---|---|---|
RW35-Y | GN001 (350°) | GN001 12500ft GN004 (6mi, 350°) 10800ft |
RW35-Y | GN002 (327°) | GN002 12500ft GN004 (8mi, 280°) 10800ft |
RW35-Y | GN003 (12°) | GN003 12500ft GN004 (8mi, 60°) 10800ft |
RNAV | GN004 10800ft GN005 (5mi, 350°) 9300ft GN006 (6mi, 350°) 7526ft (2353mi, 252°) GN001 (2351mi, 72°) 12500ft GN001 (turn) 12500ft |
STAR name | hold at | type | turn | heading* | altitude | leg | speed limit |
---|---|---|---|---|---|---|---|
GN10A1 | GN001 | VHF | right | 167 (347)° | > 12500ft | 1.0min timed | ICAO rules |
GN10A2 | GN003 | VHF | right | 237 (57)° | > 12500ft | 1.0min timed | ICAO rules |
GN11A1 | GN001 | VHF | right | 167 (347)° | > 12500ft | 1.0min timed | ICAO rules |
GN11A2 | GN002 | VHF | right | 97 (277)° | > 12500ft | 1.0min timed | ICAO rules |
GN12A1 | GN002 | VHF | right | 97 (277)° | > 12500ft | 1.0min timed | ICAO rules |
GN12A2 | GN001 | VHF | right | 167 (347)° | > 12500ft | 1.0min timed | ICAO rules |
GN13A1 | GN002 | VHF | right | 97 (277)° | > 12500ft | 1.0min timed | ICAO rules |
GN13A2 | GN001 | VHF | right | 167 (347)° | > 12500ft | 1.0min timed | ICAO rules |
GN14A1 | GN002 | VHF | right | 97 (277)° | > 12500ft | 1.0min timed | ICAO rules |
GN14A2 | GN001 | VHF | right | 167 (347)° | > 12500ft | 1.0min timed | ICAO rules |
GN14A3 | GN003 | VHF | right | 237 (57)° | > 12500ft | 1.0min timed | ICAO rules |
*) magnetic outbound (inbound) holding course |
