Country | Ethiopia |
State | Tigray |
Region | HA |
Airspace | Addis Abeba Ctr |
Municipality | Southern Tigray |
Elevation | 7399ft (2255m) |
Timezone | GMT +3 |
Coordinates | 13.47332, 39.51821 |
Magnetic var | |
Type | land |
Available since | X-Plane v10.32 |
ICAO code | HAMK |
IATA code | MQX |
FAA code | n/a |
Alula Aba Nega Mekele Intl Ground Control | 121.900 |
Alula Aba Nega Mekele Intl Tower | 118.800 |
ILS-cat-I | RW29 | 111.7 | 18.00mi |
3° GS | RW29 | 111.7 | 18.00mi |
code | identifier | dist | bearing | frequency |
---|---|---|---|---|
QHA | MEKELE VOR/DME | 0.3 | 95° | 116.60 |
MK | MEKELE NDB | 0.5 | 291° | 256 |
AX | AXUM NDB | 59.1 | 312° | 440 |
Transition altitude | 12500ft |
SID end points | distance | outbound heading | |
---|---|---|---|
RW11 | |||
GADG1C, GADG1D | 50mi | 132° | |
XUDA1C, XUDA1D | 50mi | 189° | |
AVUN1C, AVUN1D | 50mi | 230° | |
SIME1D, SIME1C | 50mi | 246° | |
UTED1C, UTED1D | 50mi | 255° | |
XUBI1D, XUBI1C | 50mi | 278° | |
UTVE1C, UTVE1B | 50mi | 296° | |
TEXO1B, TEXO1C | 50mi | 312° | |
RW29 | |||
GADG1A, GADG1B | 50mi | 132° | |
XUDA1A, XUDA1B | 50mi | 189° | |
AVUN1A, AVUN1B | 50mi | 230° | |
SIME1B, SIME1A | 50mi | 246° | |
UTED1B, UTED1A | 50mi | 255° | |
XUBI1A, XUBI1B | 50mi | 278° | |
UTVE1A | 50mi | 296° | |
TEXO1A | 50mi | 312° |
STAR starting points | distance | inbound heading | |
---|---|---|---|
RW11 | |||
XUDA1B | 50.2 | 9° | |
AVUN1B | 49.8 | 50° | |
SIME1B | 49.5 | 66° | |
UTED1B | 49.6 | 75° | |
XUBI1B | 49.5 | 98° | |
UTVE1C | 49.6 | 116° | |
TEXO1C | 49.7 | 132° | |
GADG1B | 50.3 | 312° | |
RW29 | |||
XUDA1A | 50.2 | 9° | |
AVUN1A | 49.8 | 50° | |
SIME1A | 49.5 | 66° | |
UTED1A | 49.6 | 75° | |
XUBI1A | 49.5 | 98° | |
UTVE1B, UTVE1A | 49.6 | 116° | |
TEXO1B, TEXO1A | 49.7 | 132° | |
GADG1A | 50.3 | 312° |
runway | airway (heading) | route (dist, bearing) |
---|---|---|
RW11-Z | MK110 (75°) | MK110 12500ft MK112 (10mi, 42°) 10000ft |
RW11-Z | MK111 (111°) | MK111 12500ft MK112 (10mi, 111°) 10000ft |
RNAV | MK112 10000ft MK113 (4mi, 111°) 9000ft HAMK (5mi, 111°) 7447ft MK114 (24mi, 111°) 11600ft | |
RWNVA | MK002 (323°) | MK002 14000ft MK003 (11mi, 2°) 10100ft |
RWNVA | MK005 (264°) | MK005 12500ft MK003 (9mi, 222°) 10100ft |
RWNVA | MK007 (291°) | MK007 11600ft MK003 (6mi, 291°) 10100ft |
RNAV | MK003 10100ft MK004 (5mi, 291°) 9330ft HAMK (8mi, 291°) 7415ft (2486mi, 251°) 11500ft MK002 (2493mi, 72°) 14000ft |
STAR name | hold at | type | turn | heading* | altitude | leg | speed limit |
---|---|---|---|---|---|---|---|
AVUN1A | MK002 | VHF | right | 179 (359)° | 14000ft - 24000ft | 1.5min timed | ICAO rules |
AVUN1B | MK110 | VHF | right | 219 (39)° | 12500ft - 24000ft | 1.5min timed | ICAO rules |
GADG1A | MK002 | VHF | right | 179 (359)° | 14000ft - 24000ft | 1.5min timed | ICAO rules |
GADG1B | MK110 | VHF | right | 219 (39)° | 12500ft - 24000ft | 1.5min timed | ICAO rules |
SIME1A | MK002 | VHF | right | 179 (359)° | 14000ft - 24000ft | 1.5min timed | ICAO rules |
SIME1B | MK110 | VHF | right | 219 (39)° | 12500ft - 24000ft | 1.5min timed | ICAO rules |
TEXO1A | MK002 | VHF | right | 179 (359)° | 14000ft - 24000ft | 1.5min timed | ICAO rules |
TEXO1B | MK005 | VHF | right | 39 (219)° | 12500ft - 24000ft | 1.5min timed | ICAO rules |
TEXO1C | MK111 | VHF | right | 289 (109)° | 12500ft - 24000ft | 1.5min timed | ICAO rules |
UTED1A | MK002 | VHF | right | 179 (359)° | 14000ft - 24000ft | 1.5min timed | ICAO rules |
UTED1B | MK110 | VHF | right | 219 (39)° | 12500ft - 24000ft | 1.5min timed | ICAO rules |
UTVE1A | MK002 | VHF | right | 179 (359)° | 14000ft - 24000ft | 1.5min timed | ICAO rules |
UTVE1B | MK005 | VHF | right | 39 (219)° | 12500ft - 24000ft | 1.5min timed | ICAO rules |
UTVE1C | MK111 | VHF | right | 289 (109)° | 12500ft - 24000ft | 1.5min timed | ICAO rules |
XUBI1A | MK002 | VHF | right | 179 (359)° | 14000ft - 24000ft | 1.5min timed | ICAO rules |
XUBI1B | MK111 | VHF | right | 289 (109)° | 12500ft - 24000ft | 1.5min timed | ICAO rules |
XUDA1A | MK002 | VHF | right | 179 (359)° | 14000ft - 24000ft | 1.5min timed | ICAO rules |
XUDA1B | MK110 | VHF | right | 219 (39)° | 12500ft - 24000ft | 1.5min timed | ICAO rules |
*) magnetic outbound (inbound) holding course |
