Airports for X-Plane

Houston - Houston Southwest Executive

Airport details

CountryUnited States of America
StateTexas
RegionK4
AirspaceHouston Oceanic Ctr
MunicipalityArcola
Elevation65ft (20m)
TimezoneGMT -6
Coordinates29.50608, -95.46867
Magnetic var
Typeland
Available sinceX-Plane v10.40
ICAO codeKAXH
IATA coden/a
FAA codeAXH

Communication

Houston Southwest Executive CTAF/UNICOM123.000
Houston Southwest Executive HOUSTON Approach/Departure123.800

Approach frequencies

LOCRW09108.918.00mi

Runway info

Runway 9 / 27
 length1526m (5007ft)
 bearing94° / 274°
 width30m (100ft)
 surfaceasphalt

Airport layout


Taxiway locations

 A  B  C  E  G
Parking locations

 GA

Nearby beacons

codeidentifierdistbearingfrequency
EFDELLINGTON (HOUSTON) TACAN17.272°109.40
IAHHUMBLE (HOUSTON) VORTAC27.815°116.60
BVPNIXIN (HOUSTON) NDB32.127°326
VUHSCHOLES (GALVESTON) VOR/DME34.5112°113
MHFTRINITY (SMITH POINT) VOR/DME37.787°113.60
ELAEAGLE LAKE VOR/DME45.2280°116.40
CXALIBI (HOUSTON) NDB55.6360°281
TNVNAVASOTA VOR/DME56.1323°115.90
DASDAISETTA VORTAC59.350°116.90
PSXPALACIOS VORTAC62.5228°117.30
CLROWDY (COLLEGE STATION) NDB74.5319°260

Departure and arrival routes

Transition altitude18000ft
Transition level18000ft
SID end pointsdistanceoutbound heading
ALL
 GIFFA1113mi7°
 ELD1265mi36°
 AEX3291mi71°
 IDU1241mi243°
 PSX2157mi273°
 LOA4221mi333°
 CRIED1166mi344°
RW09
 INDIE8234mi30°
 LURIC8231mi42°
 STRYA8241mi66°
 MMALT5162mi87°
 HOODO799mi106°
 WATFO5107mi135°
 KARRR6127mi228°
 BORRN460mi285°
 STYCK8165mi345°
 BLTWY7111mi354°
 WYLSN8121mi357°
RW27
 INDIE8234mi30°
 LURIC8231mi42°
 STRYA8241mi66°
 MMALT5162mi87°
 HOODO799mi106°
 WATFO5107mi135°
 KARRR6127mi228°
 BORRN460mi285°
 STYCK8165mi345°
 BLTWY7111mi354°
 WYLSN8121mi357°

STAR starting pointsdistanceinbound heading
ALL
 TSHRT134.274°
 BLUBL464.7134°
 OHIIO442.9211°
 HUDZY449.7228°
 CESAN490.4231°
 WAPPL673.5237°
 TKNIQ354.8285°

Instrument approach procedures

runwayairway (heading)route (dist, bearing)
RW09ZABRO (75°)ZABRO
BEBAY (5mi, 5°) 2000ft
 RNAVBEBAY 2000ft
JIVIX (6mi, 94°) 2000ft
KAXH (7mi, 93°) 116ft
(5691mi, 107°) 469ft
WENPI (5687mi, 287°)
HEBUR (8mi, 185°)
KEEDS (11mi, 272°) 2700ft
KEEDS (turn)
RW27TEGOY (299°)TEGOY
VAGGE (5mi, 5°) 2000ft
 RNAVVAGGE 2000ft
HEGRE (6mi, 274°) 1100ft
KAXH (3mi, 274°) 111ft
RUPRE (4mi, 273°)
KEEDS (10mi, 209°) 2700ft

Holding patterns

STAR namehold attypeturnheading*altitudelegspeed limit
BLUBL4ELLVRVHFright351 (171)°18000ft - 45000ft1.5min timedICAO rules
HUDZY4BRWCKVHFleft55 (235)°DME 20.0miICAO rules
HUDZY4WAPPLVHFleft55 (235)°DME 10.0miICAO rules
OHIIO4LYMBOVHFright71 (251)°DME 20.0miICAO rules
OHIIO4ZEEKKVHFright46 (226)°DME 10.0miICAO rules
TKNIQ3TKNIQVHFleft91 (271)°DME 10.0miICAO rules
TSHRT1ALIEFVHFright209 (29)°DME 10.0miICAO rules
TSHRT1HYDRLVHFright209 (29)°DME 10.0miICAO rules
WAPPL6BRWCKVHFleft55 (235)°DME 20.0miICAO rules
WAPPL6WAPPLVHFleft55 (235)°DME 10.0miICAO rules
*) magnetic outbound (inbound) holding course
