Mosby - Midwest National Air Center
Airport details
| Country | United States of America |
| State | Missouri |
| Region | K3 |
| Airspace | Kansas City Ctr |
| Municipality | Clay County |
| Elevation | 774ft (236m) |
| Timezone | GMT -6 |
| Coordinates | 39.33250, -94.30964 |
| Magnetic var | |
| Type | land |
| Available since | X-Plane v10.40 |
| ICAO code | KGPH |
| IATA code | n/a |
| FAA code | GPH |
Communication
| Midwest National Air Center CTAF/UNICOM | 122.700 |
| Midwest National Air Center KANSAS CITY Approach/Departure | 119.000 |
Approach frequencies
| ILS-cat-I | RW18 | 110.55 | 18.00mi |
| 3° GS | RW18 | 110.55 | 18.00mi |
Nearby Points of Interest:
Excelsior Springs Hall of Waters Commercial West Historic District
-Claybrook House
-James Brothers' House and Farm
-The Elms Historic District
-First Methodist Church
-Hall of Waters
-Excelsior Springs Hall of Waters Commercial East Historic District
-Ligon Apartments
-Watkins Woolen Mill State Park and State Historic Site
-Missouri City Savings Bank Building and Meeting Hall
-Jewell Hall
-Jewell-Lightburne Historic District
-Frank Hughes Memorial Library
-Arthur-Leonard Historic District
-Clay County Savings Association Building
-IOOF Liberty Lodge No. 49
-Miller Building
-South Liberty Courthouse Square Historic District
-Dougherty–Prospect Heights Historic District
-Clinton House
-Nebo Hill Archeological Site
-Odd Fellows Home District
-Woodneath
-Fort Osage
-Aker Cemetery
Nearby beacons
| code | identifier | dist | bearing | frequency |
|---|---|---|---|---|
| ANX | NAPOLEON VORTAC | 16.5 | 143° | 114 |
| MCI | KANSAS CITY VORTAC | 20 | 264° | 113.25 |
| RN | HUGGY (KANSAS CITY) NDB | 25.2 | 267° | 416 |
| BQS | BRAYMER VOR/DME | 26.9 | 56° | 115.35 |
| ST | TARIO (ST JOSEPH) NDB | 34.5 | 300° | 260 |
| PK | HERBB (OLATHE) NDB | 40 | 216° | 420 |
| AZN | AMAZON (SAINT JOSEPH) NDB | 43.1 | 313° | 233 |
| JZ | NEWBN (LAWRENCE) NDB | 46.6 | 244° | 338 |
| STJ | SAINT JOSEPH (ST JOSEPH) VORTAC | 47.2 | 316° | 115.50 |
| SZL | WHITEMAN (KNOB NOSTER) TACAN | 50.3 | 128° | 109.80 |
| OWI | OTTAWA NDB | 64.7 | 230° | 251 |
Departure and arrival routes
| Transition altitude | 18000ft |
| Transition level | 18000ft |
| SID end points | distance | outbound heading | |
|---|---|---|---|
| ALL | |||
| WLDCT5 | 156mi | 263° | |
| TIFTO6 | 75mi | 280° | |
| ROYAL9 | 59mi | 342° | |
| RW18 | |||
| LAKES3 | 134mi | 83° | |
| RACER7 | 127mi | 154° | |
| CHIEF7 | 47mi | 316° | |
| RW36 | |||
| LAKES3 | 134mi | 83° | |
| RACER7 | 127mi | 154° | |
| CHIEF7 | 47mi | 316° | |
| STAR starting points | distance | inbound heading | |
|---|---|---|---|
| ALL | |||
| JHAWK6 | 60.7 | 65° | |
| BQS7 | 26.9 | 236° | |
| TYGER6 | 40.3 | 341° | |
Instrument approach procedures
| runway | airway (heading) | route (dist, bearing) |
|---|---|---|
| RW18 | LASSO (227°) | LASSO OSRAF (9mi, 265°) 2700ft |
| RNAV | OSRAF 2700ft CIREH (6mi, 189°) 2600ft HOBVO (3mi, 189°) 1460ft KGPH (2mi, 189°) 828ft WEXAL (11mi, 189°) 2700ft WEXAL (turn) | |
| RW36 | ANX (323°) | ANX SUPEE (5mi, 290°) 2900ft WEXAL (5mi, 276°) 2700ft |
| RW36 | BQS (236°) | BQS WEXAL (36mi, 224°) 2700ft WEXAL (turn) 2700ft |
| RNAV | WEXAL 2700ft IJUBO (6mi, 9°) 2400ft ZAGRI (2mi, 9°) 1640ft KGPH (3mi, 9°) 820ft (5605mi, 113°) 1177ft OSRAF (5603mi, 293°) 2700ft OSRAF (turn) |
Holding patterns
| STAR name | hold at | type | turn | heading* | altitude | leg | speed limit |
|---|---|---|---|---|---|---|---|
| BQS7 | BQS | NDB | right | 54 (234)° | 1.0min timed | ICAO rules | |
| BQS7 | FONIX | VHF | right | 57 (237)° | 1.0min timed | ICAO rules | |
| JHAWK6 | JHAWK | VHF | left | 223 (43)° | < 17999ft | 1.0min timed | ICAO rules |
| TYGER6 | TYGER | VHF | left | 135 (315)° | < 17999ft | 1.0min timed | ICAO rules |
| *) magnetic outbound (inbound) holding course | |||||||
