Airports for X-Plane

Madera - Madera Muni

Airport details

CountryUnited States of America
StateCalifornia
RegionK2
AirspaceOakland Ctr
MunicipalityMadera
Elevation251ft (77m)
TimezoneGMT -8
Coordinates36.98861, -120.11244
Magnetic var
Typeland
Available sinceX-Plane v10.40
ICAO codeKMAE
IATA codeMAE
FAA codeMAE

Communication

Madera Muni Madera AWOS134.725
Madera Muni Madera CTAF122.800

Runway info

Runway 12 / 30
 length1690m (5545ft)
 bearing129° / 309°
 width46m (150ft)
 surfaceasphalt
 blast zone61m (200ft) / 61m (200ft)
Runway 8 / 26
 length1128m (3701ft)
 bearing90° / 270°
 width46m (150ft)
 surfaceasphalt

Airport layout


Taxiway locations

 P
Parking locations

 Admin  Barber  Jet

Nearby beacons

codeidentifierdistbearingfrequency
CZQCLOVIS (FRESNO) VORTAC15.5109°112.90
HYPEL NIDO (MERCED) VOR/DME19.5309°114.20
FRAFRIANT VORTAC25.777°115.60
PXNPANOCHE VORTAC35.9248°112.60
NLCNAVY LEMOORE TACAN39.3167°113.30
VISVISALIA VOR/DME48.1135°109.40
MODMODESTO VOR/DME55.7307°114.60

Instrument approach procedures

runwayairway (heading)route (dist, bearing)
RW12BLEAR (22°)BLEAR
RUGUE (17mi, 317°) 2000ft
IDAYI (7mi, 52°) 2000ft
RW12EBTUW (158°)EBTUW
COPPY (7mi, 150°) 2000ft
IDAYI (7mi, 230°) 2000ft
 RNAVIDAYI 2000ft
FOSAB (6mi, 129°) 1900ft
CIVSI (3mi, 129°) 1080ft
KMAE (3mi, 129°) 285ft
(6824mi, 107°) 800ft
KITBY (6825mi, 287°) 2000ft
KITBY (turn)
RW30BLEAR (22°)BLEAR
KITBY (7mi, 111°) 2000ft
GEVRY (7mi, 51°) 2000ft
RW30NIVEE (263°)NIVEE
JENYE (8mi, 224°) 3500ft
GEVRY (7mi, 233°) 2000ft
 RNAVGEVRY 2000ft
HATXI (6mi, 309°) 1900ft
KNOSP (3mi, 309°) 860ft
KMAE (2mi, 309°) 290ft
(6824mi, 107°) 800ft
KITBY (6825mi, 287°) 2000ft
KITBY (turn)
