Airports for X-Plane

Carbondale/murphysboro - Southern Illinois

Airport details

CountryUnited States of America
StateIllinois
RegionK5
AirspaceKansas City Ctr
MunicipalityJackson County
Elevation411ft (125m)
TimezoneGMT -6
Coordinates37.77690, -89.24999
Magnetic var
Typeland
Available sinceX-Plane v10.40
ICAO codeKMDH
IATA codeMDH
FAA codeMDH

Communication

Southern Illinois ATIS119.850
Southern Illinois CTAF125.350
Southern Illinois UNICOM122.950
Southern Illinois Ground Control121.800
Southern Illinois CARBONDALE Tower125.350
Southern Illinois CARBONDALE Tower126.250

Approach frequencies

ILS-cat-IRW18L110.918.00mi
3° GSRW18L110.918.00mi

Runway info

Runway 18L / 36R
 length1985m (6512ft)
 bearing182° / 2°
 width30m (100ft)
 surfaceasphalt
Runway 6 / 24
 length1267m (4157ft)
 bearing66° / 246°
 width30m (100ft)
 surfaceasphalt
Runway 18R / 36L
 length1075m (3527ft)
 bearing181° / 1°
 width18m (60ft)
 surfaceasphalt

Airport layout - runway 18R / 36L


Taxiway locations

 18L  18R  24  36L  36R  6  A  B
 B1  B2  C  C1  E  F  H  J
Parking locations

 FBO  GA  Terminal

Nearby beacons

codeidentifierdistbearingfrequency
MDCABBI (CARBONDALE-MURPHYSBORO) NDB5.63°388
MWADME11.395°110.40
MWJONNY (MARION) NDB13.777°382
CGIGIRARDEAU DME36.3210°112.90
CGDUTCH (CAPE GIRARDEAU) NDB38221°248
ENLCENTRALIA VORTAC38.88°115
VNNVERNON DME40.837°113.80
CIRCAIRO NDB43178°397
FAMFARMINGTON VORTAC47.1264°115.70
JDGOOEY (BELLEVILLE) NDB48325°385
CNGCUNNINGHAM (PADUCAH) VOR/DME50.1152°113.10
FWCWAYNE CO (FAIRFIELD) NDB53.754°257
SKESCOTT (BELLEVILLE) TACAN54.1322°112.20
CPACORE (CAHOKIA/ST LOUIS) NDB58.7313°350
TOYTROY VORTAC65.8325°116

Instrument approach procedures

runwayairway (heading)route (dist, bearing)
RW18LELUME (154°)ELUME
HEMPA (5mi, 91°) 2700ft
RW18LFOGBO (210°)FOGBO
HEMPA (5mi, 271°) 2700ft
RW18LHEMPA (182°)HEMPA 2700ft
 RNAVHEMPA 2700ft
JOROB (6mi, 182°) 2100ft
KMDH (6mi, 183°) 459ft
(5370mi, 113°) 800ft
SOPAW (5370mi, 293°) 2700ft
SOPAW (turn)
RW36RHENAN (332°)HENAN
SOPAW (5mi, 271°) 2700ft
RW36RJESHE (30°)JESHE
SOPAW (5mi, 91°) 2700ft
RW36RSOPAW (1°)SOPAW 2700ft
 RNAVSOPAW 2700ft
RYMAN (6mi, 2°) 2100ft
ZAGDA (3mi, 2°) 1200ft
KMDH (3mi, 359°) 452ft
(5370mi, 113°) 811ft
HEMPA (5369mi, 293°) 2700ft
HEMPA (turn)
