Airports for X-Plane

Chicago - Chicago Midway Intl

Airport details

CountryUnited States of America
StateIllinois
RegionK5
AirspaceChicago Ctr
MunicipalityChicago
Elevation620ft (189m)
TimezoneGMT -6
Coordinates41.78597, -87.75242
Magnetic var
Typeland
Available sinceX-Plane v10.32
ICAO codeKMDW
IATA codeMDW
FAA codeMDW

Communication

Chicago Midway Intl ATIS132.750
Chicago Midway Intl UNICOM122.950
Chicago Midway Intl Clearance DEL121.850
Chicago Midway Intl Ground Control121.650
Chicago Midway Intl Tower118.700
Chicago Midway Intl Tower119.450
Chicago Midway Intl Tower135.200
Chicago Midway Intl Approach/Departure118.400
Chicago Midway Intl Approach/Departure128.200

Approach frequencies

ILS-cat-IRW04R111.518.00mi
ILS-cat-IRW13C109.918.00mi
ILS-cat-IRW31C109.918.00mi
3° GSRW04R111.518.00mi
3° GSRW13C109.918.00mi
3° GSRW31C109.918.00mi
Nearby Points of Interest:
Mr. Robert Silhan House
-
Arthur J. Dunham House
-
J. Sterling Morton High School East Auditorium
-
Hofmann Tower
-
Cornell Square
-
Berwyn Health Center
-
Berwyn Municipal Building
-
Riverside Historic District
-
Central Berwyn Bungalow Historic District
-
Coonley House
-
F. F. Tomek House
-
Central Manufacturing District–Pershing Road Development Historic District
-
Goldblatt's Building
-
Davis Square
-
Jewish People's Institute
-
Union Stock Yard Gate
-
Central Park Theater
-
St. Matthew Evangelical Lutheran School
-
William and Jessie M. Adams House
-
Yale Apartments
-
La Grange Village Historic District
-
Gunderson Historic District
-
Henry E. Legler Regional Branch of the Chicago Public Library
-
Schulze Baking Company Plant
-
Edward Hines, Jr., Veterans Administration Hospital

Runway info

Runway 13C / 31C
 length1987m (6519ft)
 bearing125° / 305°
 width46m (150ft)
 surfaceasphalt
 displ threshold141m (463ft) / 212m (696ft)
 blast zone75m (246ft) / 69m (226ft)
Runway 4R / 22L
 length1964m (6444ft)
 bearing52° / 232°
 width46m (150ft)
 surfaceasphalt
 displ threshold158m (518ft) / 193m (633ft)
 blast zone108m (354ft) / 86m (282ft)
Runway 4L / 22R
 length1678m (5505ft)
 bearing52° / 232°
 width46m (150ft)
 surfaceasphalt
 displ threshold231m (758ft) / 268m (879ft)
 blast zone6m (20ft) / 8m (26ft)
Runway 13L / 31R
 length1567m (5141ft)
 bearing125° / 305°
 width46m (150ft)
 surfaceasphalt
 displ threshold229m (751ft) / 0m (0ft)
 blast zone8m (26ft) / 0m (0ft)
Runway 13R / 31L
 length1176m (3858ft)
 bearing125° / 305°
 width18m (60ft)
 surfaceasphalt
 blast zone101m (331ft) / 29m (95ft)

Airport layout


Taxiway locations

 A  B  D  E1  E2  E3  F  F1
 F2  F3  F4  G  J  K  M  N
 N1  N2  P  Q  R  T  V  W
 Y  Y3  Y4  Y5  Y6  Z
Parking locations

 Atlantic  Eagle  Executive  GA  Gate  Signature  Southwest

Nearby beacons

codeidentifierdistbearingfrequency
MXKEDZI (CHICAGO) NDB3.8125°248
GCODME14.1324°108.25
CGTCHICAGO HEIGHTS VORTAC18.4147°114.20
GYGARIE (GARY) NDB22.9117°236
DPADUPAGE (CHICAGO) VOR/DME27.4280°108.40
OBKNORTHBROOK VOR/DME27.6335°113
JOTJOLIET VOR/DME29.1247°112.30
EONPEOTONE VORTAC31184°113.20
UGWAUKE (CHICAGO/WAUKEGAN) NDB40.7356°379
IKKDME42.9188°111.60
VPSEDLY (VALPARAISO) NDB44.1111°212
IKLUKOW (KANKAKEE) NDB46.6191°272
ENWDME49.4348°109.20
DTGDWIGHT NDB49.7226°344
RAPASER (RACINE) NDB54.2351°206
HRK(RACINE) DME58.6356°117.70
BUU(BURLINGTON) DME59.4329°114.50
PNTPONTIAC VOR/DME72.9225°109.60

Departure and arrival routes

Transition altitude18000ft
Transition level18000ft
SID end pointsdistanceoutbound heading
RW04 (ALL)
 MIDWA6, CICER218mi118°
RW13C
 CICER2, MIDWA618mi118°
RW13L
 CICER2, MIDWA618mi118°
RW22L
 MIDWA6, CICER218mi118°
RW22R
 CICER2, MIDWA618mi118°
RW31C
 CICER2, MIDWA618mi118°
RW31R
 CICER2, MIDWA618mi118°

STAR starting pointsdistanceinbound heading
ALL
 MOTIF647.453°
 GSH778.9279°
RW04R
 ENDEE629.363°
 FISSK4, PANGG331.1294°
RW13C
 ENDEE629.363°
 PANGG3, FISSK431.1294°
RW22L
 ENDEE629.363°
 FISSK4, PANGG331.1294°
RW31C
 ENDEE629.363°
 FISSK4, PANGG331.1294°

Instrument approach procedures

runwayairway (heading)route (dist, bearing)
RW04LCGT (327°)CGT
YIGUT (11mi, 287°) 2400ft
JERNU (7mi, 305°) 2300ft
RW04LEON (4°)EON
TASUE (22mi, 329°) 2300ft
JERNU (5mi, 52°) 2300ft
RW04LJOT (67°)JOT
TASUE (15mi, 81°) 2300ft
JERNU (5mi, 52°) 2300ft
 RNAVJERNU 2300ft
HADGI (5mi, 52°) 2300ft
CEXUD (3mi, 52°) 1460ft
KMDW (3mi, 54°) 672ft
(5305mi, 115°) 1100ft
YIGUT (5306mi, 295°) 2400ft
YIGUT (turn)
RW04RYALQUE (51°)ALQUE 6000ft
BANER (3mi, 52°) 5000ft
CADON (3mi, 52°) 4000ft
CITGO (5mi, 52°) 2400ft
YIPEE (2mi, 52°) 1700ft
RW04RYOLCYK (329°)OLCYK 4000ft
SAVRD (9mi, 306°) 4000ft
HILND (4mi, 305°) 2700ft
YIPEE (3mi, 358°) 1700ft
 RNAVYIPEE 1700ft
KMDW (4mi, 51°) 669ft
(5305mi, 115°) 1100ft
EON (5305mi, 295°) 2600ft
EON (turn)
RW04RZJOT (67°)JOT
ALQUE (13mi, 86°) 6000ft
RW04RZWUPOR (51°)WUPOR
ALQUE (13mi, 51°) 6000ft
 RNAVALQUE 6000ft
BANER (3mi, 52°) 5000ft
CADON (3mi, 52°) 4000ft
CITGO (5mi, 52°) 2400ft
OLOXE (3mi, 52°) 1460ft
KMDW (3mi, 51°) 669ft
(5305mi, 115°) 1100ft
EON (5305mi, 295°) 2600ft
EON (turn)
RW13CYPLOPP (51°)PLOPP 4000ft
YUCAN (3mi, 305°) 3000ft
JUPIR (4mi, 5°) 2000ft
RW13CYTINLY (23°)TINLY
OOPLA (9mi, 308°) 4000ft
GIKLE (6mi, 6°) 2500ft
JUPIR (6mi, 61°) 2000ft
RW13CYZABNU (67°)ZABNU 4000ft
TOYUL (15mi, 56°) 2500ft
GIKLE (5mi, 56°) 2500ft
JUPIR (6mi, 61°) 2000ft
 RNAVJUPIR 2000ft
NIDEE (2mi, 82°) 2000ft
DULTE (1mi, 113°)
KMDW (3mi, 125°) 654ft
(5305mi, 115°) 1100ft
EON (5305mi, 295°) 2600ft
EON (turn)
RW13CZGIKLE (86°)GIKLE 2500ft
AAMEE (5mi, 60°) 2300ft
 RNAVAAMEE 2300ft
RUDDY (3mi, 71°) 2000ft
NAANN (2mi, 117°) 1600ft
HHALL (turn) 1280ft
KMDW (2mi, 125°) 654ft
(5305mi, 115°) 1100ft
EON (5305mi, 295°) 2600ft
EON (turn)
RW13LCGT (327°)CGT
KANLE (28mi, 308°) 2300ft
HANOD (5mi, 52°) 2300ft
RW13LEON (4°)EON
KANLE (36mi, 340°) 2400ft
HANOD (5mi, 52°) 2300ft
RW13LJOT (67°)JOT
KANLE (23mi, 47°) 2300ft
HANOD (5mi, 52°) 2300ft
 RNAVHANOD 2300ft
EXEKE (5mi, 125°) 2300ft
KMDW (5mi, 126°) 656ft
(5305mi, 115°) 1020ft
IGECY (5305mi, 295°) 2100ft
EON (20mi, 184°) 2600ft
EON (turn)
RW22LXPKACH (62°)PKACH 6000ft
MIING (20mi, 65°) 4000ft
 RNAVMIING 4000ft
FENCK (3mi, 87°) 4000ft
ZASIV (4mi, 51°) 2900ft
EGLUQ (3mi, 306°) 1900ft
YACHT (1mi, 252°) 1500ft
KMDW (3mi, 233°) 656ft
(5305mi, 115°) 1300ft
EON (5305mi, 295°) 2600ft
EON (turn)
RW22LYSTERE (261°)STERE 3000ft
TACTT (5mi, 270°) 3000ft
SAILZ (5mi, 270°) 3000ft
 RNAVSAILZ 3000ft
DXXON (3mi, 267°) 3000ft
MNDOE (2mi, 267°) 2400ft
JIBBB (2mi, 252°) 1900ft
YACHT (1mi, 242°) 1500ft
KMDW (3mi, 233°) 656ft
(5305mi, 115°) 1300ft
EON (5305mi, 295°) 2600ft
EON (turn)
RW22LZSTERE (261°)STERE
TACTT (5mi, 270°) 3000ft
SAILZ (5mi, 270°) 3000ft
 RNAVSAILZ 3000ft
DXXON (3mi, 267°) 3000ft
MNDOE (2mi, 267°) 2500ft
ZUDVI (4mi, 241°) 1260ft
HINSN (2mi, 241°) 738ft
(5304mi, 115°) 1300ft
EON (5305mi, 295°) 2600ft
EON (turn)
RW22RCGT (327°)CGT
SAVEE (22mi, 19°) 3000ft
HAXOM (7mi, 305°) 3000ft
RW22REON (4°)EON
SAVEE (39mi, 30°) 3000ft
HAXOM (7mi, 305°) 3000ft
 RNAVHAXOM 3000ft
RUGGO (5mi, 232°) 3000ft
CIDIG (5mi, 232°) 1420ft
KMDW (3mi, 230°) 661ft
(5305mi, 115°) 1100ft
IGECY (5305mi, 295°)
EON (20mi, 184°) 2600ft
EON (turn)
RW31CYHILLS (306°)HILLS 5000ft
GLEAM (3mi, 306°) 4000ft
RUNTS (5mi, 306°) 2500ft
HOBEL (3mi, 306°) 1700ft
RW31CYTWEEN (357°)TWEEN 4000ft
PRIUS (4mi, 51°) 2900ft
HOBEL (3mi, 357°) 1700ft
 RNAVHOBEL 1700ft
KMDW (4mi, 306°) 660ft
(5305mi, 115°) 1100ft
EON (5305mi, 295°) 2600ft
EON (turn)
RW31CZHILLS (306°)HILLS 5000ft
GLEAM (3mi, 306°) 4000ft
 RNAVGLEAM 4000ft
RUNTS (5mi, 306°) 2500ft
HOBEL (3mi, 306°) 1700ft
KMDW (4mi, 306°) 660ft
(5305mi, 115°) 1100ft
EON (5305mi, 295°) 2600ft
EON (turn)
RW31RCGT (327°)CGT
HAKBO (9mi, 356°) 2300ft
RW31REON (4°)EON
WOMAT (19mi, 18°) 2400ft
HAKBO (7mi, 52°) 2300ft
RW31RIDUDE (277°)IDUDE
HAKBO (7mi, 232°) 2300ft
RW31RJOT (67°)JOT
WOMAT (28mi, 87°) 2400ft
HAKBO (7mi, 52°) 2300ft
 RNAVHAKBO 2300ft
FANEK (5mi, 306°) 2300ft
CENAP (3mi, 305°) 1220ft
KMDW (2mi, 303°) 663ft
(5305mi, 115°) 1100ft
IGECY (5305mi, 295°) 2300ft
EON (20mi, 184°) 2600ft
EON (turn)

Holding patterns

STAR namehold attypeturnheading*altitudelegspeed limit
ENDEE6CHUMPVHFright323 (143)°DME 10.0miICAO rules
ENDEE6ENDEEVHFright210 (30)°DME 10.0miICAO rules
ENDEE6IRKNDBleft248 (68)°18000ft - 45000ft1.5min timedICAO rules
ENDEE6KAMBLVHFright267 (87)°DME 10.0miICAO rules
ENDEE6LLVSSVHFright253 (73)°DME 10.0miICAO rules
ENDEE6MAGOOVHFright219 (39)°1.5min timedICAO rules
ENDEE6MMEGGVHFright210 (30)°DME 10.0miICAO rules
ENDEE6NANEEVHFleft210 (30)°DME 10.0miICAO rules
ENDEE6POOGYVHFleft220 (40)°DME 10.0miICAO rules
FISSK4FISSKVHFright111 (291)°DME 8.0miICAO rules
FISSK4OZZEYVHFleft143 (323)°DME 8.0miICAO rules
GSH7GSHNDBleft92 (272)°1.0min timedICAO rules
GSH7HALIEVHFleft87 (267)°1.0min timedICAO rules
GSH7IROCKVHFright87 (267)°1.0min timedICAO rules
MOTIF6BDFNDBright247 (67)°18000ft - 45000ft1.5min timedICAO rules
MOTIF6CVANDBright305 (125)°1.0min timedICAO rules
MOTIF6IRKNDBleft248 (68)°18000ft - 45000ft1.5min timedICAO rules
MOTIF6MAGOOVHFright219 (39)°1.5min timedICAO rules
MOTIF6MINOKVHFright202 (22)°< 17999ft1.0min timedICAO rules
MOTIF6MOTIFVHFright202 (22)°< 17999ft1.0min timedICAO rules
MOTIF6PIANDBright253 (73)°1.0min timedICAO rules
MOTIF6PNTNDBleft214 (34)°18000ft - 45000ft1.5min timedICAO rules
PANGG3HALIEVHFleft87 (267)°1.0min timedICAO rules
PANGG3IROCKVHFright87 (267)°1.0min timedICAO rules
PANGG3PANGGVHFleft94 (274)°DME 10.0miICAO rules
*) magnetic outbound (inbound) holding course
