Airports for X-Plane

Merced - Castle

Airport details

CountryUnited States of America
StateCalifornia
RegionK2
AirspaceOakland Ctr
MunicipalityMerced County
Elevation188ft (57m)
TimezoneGMT -8
Coordinates37.38047, -120.56819
Magnetic var
Typeland
Available sinceX-Plane v10.40
ICAO codeKMER
IATA codeMER
FAA codeMER

Communication

Castle ATIS124.475
Castle CTAF118.175
Castle Ground Control133.575
Castle Tower118.175
Castle NORCAL Approach/Departure120.950

Approach frequencies

ILS-cat-IRW31109.518.00mi
3° GSRW31109.518.00mi
Nearby Points of Interest:
Bloss Mansion
-
Merced County High School
-
Kaehler-Rector House
-
Bank of Italy
-
Leggett House
-
Maj. George Beecher Cook House
-
Thomas H. Leggett House
-
United States Post Office (Merced, California)
-
Hornitos Masonic Hall No. 98
-
Old La Grange Schoolhouse
-
Odd Fellows Hall
-
Old Adobe Barn
-
Bank of Los Banos Building
-
Church of St. Joseph
-
El Viejo Post Office
-
McHenry Mansion

Runway info

Runway 13 / 31
 length3599m (11808ft)
 bearing135° / 315°
 width46m (151ft)
 surfaceasphalt
 blast zone255m (837ft) / 255m (837ft)

Airport layout


Taxiway locations

 A  A1  A2  C  D  E  G  J
 K  L
Parking locations

 North  Operations  South

Nearby beacons

codeidentifierdistbearingfrequency
HYPEL NIDO (MERCED) VOR/DME12.5134°114.20
MODMODESTO VOR/DME23.7302°114.60
PXNPANOCHE VORTAC41.1198°112.60
LINLINDEN VOR/DME46.5328°114.80
CZQCLOVIS (FRESNO) VORTAC46.7123°112.90
FRAFRIANT VORTAC49.3106°115.60
UADCHUALAR (SALINAS) NDB68.9226°263

Instrument approach procedures

runwayairway (heading)route (dist, bearing)
RW13AWALI (184°)AWALI
GANQA (10mi, 237°) 2000ft
RW13PATYY (103°)PATYY
DIGQY (10mi, 102°) 2000ft
GANQA (8mi, 62°) 2000ft
RW13VOLTA (75°)VOLTA
DIGQY (12mi, 34°) 2000ft
GANQA (8mi, 62°) 2000ft
 RNAVGANQA 2000ft
RILRE (6mi, 135°) 1700ft
KMER (6mi, 135°) 245ft
(6837mi, 107°) 600ft
TURLO (6826mi, 287°) 4000ft
TURLO (turn) 4000ft
RW31EBTUW (280°)EBTUW
CUMLO (10mi, 240°) 2000ft
RW31PXN (18°)PXN
UNIGE (11mi, 29°) 4500ft
NUPUZ (15mi, 29°) 2000ft
CUMLO (10mi, 52°) 2000ft
RW31VOLTA (75°)VOLTA
NUPUZ (22mi, 111°) 2000ft
CUMLO (10mi, 52°) 2000ft
 RNAVCUMLO 2000ft
SARNE (6mi, 315°) 1800ft
KMER (6mi, 315°) 233ft
(6837mi, 107°) 381ft
WENIG (6838mi, 287°)
NEBBY (10mi, 53°) 4000ft
NEBBY (turn) 4000ft
