Airports for X-Plane

Philadelphia - Philadelphia Intl

Airport details

CountryUnited States of America
StatePennsylvania
RegionK6
AirspaceWashington Ctr
MunicipalityTinicum Township
Elevation36ft (11m)
TimezoneGMT -5
Coordinates39.87225, -75.24087
Magnetic var
Typeland
Available sinceX-Plane v10.40
ICAO codeKPHL
IATA codePHL
FAA codePHL

Communication

Philadelphia Intl ATIS-D135.925
Philadelphia Intl ATIS-A133.400
Philadelphia Intl UNICOM122.950
Philadelphia Intl Clearance DEL118.850
Philadelphia Intl Ground Control121.900
Philadelphia Intl Ground Control121.650
Philadelphia Intl Tower118.500
Philadelphia Intl Tower135.100
Philadelphia Intl PRM123.600
Philadelphia Intl Approach126.850
Philadelphia Intl Approach123.800
Philadelphia Intl Approach124.350
Philadelphia Intl PRM120.425
Philadelphia Intl Approach126.600
Philadelphia Intl Departure119.750
Philadelphia Intl Departure124.350

Approach frequencies

ILS-cat-IIIRW09R109.318.00mi
ILS-cat-IIRW27R108.9518.00mi
ILS-cat-IRW09L108.9518.00mi
ILS-cat-IRW27L109.318.00mi
ILS-cat-IRW17108.7518.00mi
ILS-cat-IRW26111.5518.00mi
3.1° GSRW26111.5518.00mi
3° GSRW09L108.9518.00mi
3° GSRW27L109.318.00mi
3° GSRW09R109.318.00mi
3° GSRW17108.7518.00mi
3° GSRW27R108.9518.00mi
Nearby Points of Interest:
George Wolf School
-
James Whitall, Jr. House
-
Philadelphia Lazaretto
-
The Printzhof
-
William T. Tilden Middle School
-
Philadelphia Naval Shipyard
-
Morton Homestead
-
C. A. Nothnagle Log House
-
Middishade Clothing Factory
-
Edgar Allan Poe School
-
Charles Y. Audenried Junior High School
-
Anthony Wayne School
-
Regent-Rennoc Court
-
Twentieth Century Club of Lansdowne
-
Lansdowne Park Historic District
-
Thompson House
-
St. Peter's Episcopal Church
-
Henry Albertson Subdivision Historic District
-
Baptist Institute for Christian Workers
-
Lower Swedish Cabin
-
G. G. Green's Block
-
Hunter-Lawrence-Jessup House
-
Woodbury Friends' Meetinghouse
-
Hanson Haines House
-
Francis M. Drexel School

Runway info

Runway 9R / 27L
 length3653m (11985ft)
 bearing79° / 259°
 width61m (200ft)
 surfaceasphalt
 displ threshold0m (0ft) / 583m (1913ft)
 blast zone90m (295ft) / 122m (400ft)
Runway 9L / 27R
 length2888m (9475ft)
 bearing79° / 259°
 width46m (151ft)
 surfaceasphalt
 blast zone126m (413ft) / 123m (404ft)
Runway 17 / 35
 length1981m (6499ft)
 bearing154° / 334°
 width46m (151ft)
 surfaceasphalt
 blast zone63m (207ft) / 61m (200ft)
Runway 8 / 26
 length1520m (4987ft)
 bearing79° / 259°
 width46m (151ft)
 surfaceasphalt
 blast zone61m (200ft) / 8m (26ft)

Airport layout


Taxiway locations

 A  A1  A2  A3  B  C  D  D1
 D2  D4  E  E1  E2  E4  F  G
 H  J  K  K1  K3  K4  K5  K6
 K7  K8  L  M  N  P  P2  P3
 P4  P5  Q  R  S  S1  S11  S12
 S13  S2  S3  S4  S5  S6  S7  SS1
 SS3  T  TA  U  V  W  Y  Z
Parking locations

 A10  A11A  A11B  A12  A13  A14  A16  A17
 A18  A19  A2  A20  A21  A22  A23  A24
 A25  A26  A3  A4  A6  A7  A8  A9A
 A9B  AAL  Atlantic  B1  B10  B11  B13  B14
 B15  B16  B2  B3  B4  B5  B6  B7
 B8  B9  Berwind  C17  C18  C19  C20  C21
 C22  C23  C24  C25  C26  C27  C28  C29
 C30  C31  Cargo  D10A  D10B  D11C  D11L  D11R
 D12A  D12B  D13  D14A  D14B  D15  D16  D1C
 D2  D3X  D4  D5  D6  D7  D8A  D8B
 D9  E1  E10  E11  E12  E13  E14  E15
 E16  E17  E2  E3  E4  E5  E6  E7
 E8  E9  F1  F11  F12  F13  F14  F15
 F16  F17  F18  F19  F2  F20  F21  F22
 F23  F24  F25  F26  F27  F28  F29  F3
 F30  F31  F32  F33  F34  F35  F36  F37
 F38  F39  F4  F5  F6  F7  F9  FedEx
 GA  S  Spectacor  UPS

Nearby beacons

codeidentifierdistbearingfrequency
OODWOODSTOWN VORTAC14.4195°112.80
INGAMBLER NDB15.3350°275
MXEMODENA VORTAC20276°113.20
DQODUPONT (WILMINGTON) VORTAC20.5242°114
VCNCEDAR LAKE (MILLVILLE) VOR/DME23.7141°115.20
ILHADIN (WILMINGTON) NDB24.5232°248
PTWPOTTSTOWN VORTAC25.6318°116.50
ARDYARDLEY VOR/DME27.541°108.20
RNBRAINBOW (MILLVILLE) NDB27.7167°363
GXUMC GUIRE (WRIGHTSTOWN) VORTAC30.778°110.60
CYNCOYLE VORTAC37.494°113.40
ACYATLANTIC CITY VORTAC39.6122°108.60
RBVROBBINSVILLE VORTAC39.666°113.80
ENOSMYRNA (KENTON) VORTAC40.5203°111.40
NELLAKEHURST TACAN4279°111.80
NELLAKEHURST NDB42.979°396
DOVDOVER TACAN45.6197°110
ETXEAST TEXAS VOR/DME47.1328°110.20
SBJSOLBERG VOR/DME48.435°112.90
SIESEA ISLE VORTAC50.9150°114.80
FJCALLENTOWN VORTAC52.2346°117.50
BWZBROADWAY (SCHOOLEY'S MT) VOR/DME58.824°114.20
CATCHATHAM NDB6443°254

Departure and arrival routes

Transition altitude18000ft
Transition level18000ft
STAR starting pointsdistanceinbound heading
ALL
 BUNTS287.9103°
 SLATT486.5162°
 VCN923.7321°
RW09 (ALL)
 PAATS332.634°
 BOJID214.2137°
 SPUDS423.9168°
 JIIMS323.7321°
RW17
 PAATS332.634°
 JIIMS323.7321°
RW26
 PAATS332.634°
 SPUDS423.9168°
 JIIMS323.7321°
RW27 (ALL)
 PAATS332.634°
 BOJID214.2137°
 SPUDS423.9168°
 JIIMS323.7321°
RW35
 PAATS332.634°
 JIIMS323.7321°

Instrument approach procedures

runwayairway (heading)route (dist, bearing)
RW09LYDQO (62°)DQO
QWEST (8mi, 20°) 4000ft
RW09LYMXE (96°)MXE
QWEST (8mi, 135°) 4000ft
 RNAVQWEST 4000ft
OBEKE (4mi, 79°) 3000ft
ANNET (4mi, 79°) 2100ft
LANDI (4mi, 79°) 760ft
KPHL (3mi, 78°) 71ft
(4728mi, 118°) 263ft
JALTO (4722mi, 298°)
ZURKU (11mi, 179°)
OOD (11mi, 247°) 3000ft
OOD (turn)
RW09LZDQO (62°)DQO
DUWEE (6mi, 50°) 4000ft
CHETM (4mi, 50°) 3000ft
 RNAVCHETM 3000ft
HEPKA (6mi, 67°) 1500ft
KPHL (5mi, 78°) 71ft
CUBUT (11mi, 79°)
FIDAX (10mi, 156°)
OOD (18mi, 252°) 3000ft
OOD (turn)
RW09RYDQO (62°)DQO
BWINE (8mi, 21°) 4000ft
RW09RYMXE (96°)MXE
BWINE (9mi, 135°) 4000ft
 RNAVBWINE 4000ft
ASOCI (4mi, 79°) 3000ft
KELEE (4mi, 79°) 1800ft
BALDN (3mi, 79°) 740ft
KPHL (4mi, 76°) 78ft
(4728mi, 118°) 1500ft
OOD (4728mi, 298°) 3000ft
OOD (turn)
RW09RZDQO (62°)DQO
DUWEE (6mi, 50°) 4000ft
CHETM (4mi, 50°) 3000ft
 RNAVCHETM 3000ft
ANDHW (5mi, 66°) 1500ft
KPHL (6mi, 77°) 78ft
ASGEW (8mi, 80°)
CIPOK (10mi, 151°)
OOD (17mi, 251°) 3000ft
OOD (turn)
RW17ARD (221°)ARD
COWAD (22mi, 249°) 3000ft
RW17PTW (138°)PTW
COWAD (13mi, 121°) 3000ft
 RNAVCOWAD 3000ft
HYILL (7mi, 153°) 2000ft
WENTO (4mi, 154°) 780ft
KPHL (3mi, 166°) 58ft
(4728mi, 118°) 260ft
JEPUG (4721mi, 298°) 3000ft
JEPUG (turn)
RW26ALBEK (286°)ALBEK
CIBOP (5mi, 6°) 3300ft
FERIN (5mi, 318°) 3300ft
RW26ENZEW (259°)ENZEW
FERIN (4mi, 262°) 3300ft
RW26MENGE (244°)MENGE
FERIN (5mi, 177°) 3300ft
 RNAVFERIN 3300ft
KANKE (6mi, 259°) 2000ft
ZOKAR (3mi, 259°) 1040ft
KPHL (4mi, 256°) 86ft
(4728mi, 118°) 800ft
FROSE (4740mi, 298°) 3000ft
FROSE (turn)
RW27LCYN (274°)CYN
ORANE (24mi, 283°) 3500ft
RW27LENZEW (259°)ENZEW
ORANE (3mi, 256°) 3500ft
 RNAVORANE 3500ft
FESTI (3mi, 259°) 3000ft
TORNE (2mi, 259°) 3000ft
GLOUS (3mi, 259°) 2060ft
KPHL (6mi, 261°) 67ft
(4728mi, 118°) 1500ft
OOD (4728mi, 298°) 3000ft
OOD (turn)
RW27RENZEW (259°)ENZEW
DUCVA (3mi, 260°) 3500ft
 RNAVDUCVA 3500ft
MRTIN (3mi, 259°) 3000ft
JALTO (5mi, 259°) 2100ft
KPHL (7mi, 259°) 64ft
(4728mi, 118°) 267ft
LANDI (4731mi, 298°)
MXE (17mi, 279°) 3000ft
MXE (turn)
RW35ALBEK (286°)ALBEK
KUSLE (6mi, 206°) 4700ft
JEPUG (8mi, 269°) 3000ft
RW35JIIMS (321°)JIIMS
BDAWK (7mi, 297°) 3000ft
JEPUG (5mi, 334°) 3000ft
RW35WIKAV (6°)WIKAV
JEPUG (8mi, 56°) 3000ft
 RNAVJEPUG 3000ft
HARLU (6mi, 334°) 2000ft
CEMEK (4mi, 334°) 900ft
KPHL (3mi, 321°) 68ft
(4728mi, 118°) 436ft
WERDI (4730mi, 298°)
MUDNE (11mi, 313°) 3000ft
MUDNE (turn)

Holding patterns

STAR namehold attypeturnheading*altitudelegspeed limit
BOJID2BUNTSVHFleft284 (104)°6001ft - 14000ftDME 4.0mi210
BOJID2MIROYVHFright276 (96)°1.5min timedICAO rules
BUNTS2BUNTSVHFleft284 (104)°6001ft - 14000ftDME 4.0mi210
BUNTS2MIROYVHFright276 (96)°1.5min timedICAO rules
JIIMS3JIIMSVHFleft228 (48)°6001ft - 14000ftDME 4.0mi210
PAATS3BUKYYVHFright248 (68)°DME 10.0miICAO rules
PAATS3GAREDVHFleft226 (46)°1.0min timedICAO rules
PAATS3PAATSVHFleft231 (51)°6001ft - 14000ftDME 5.0mi210
SLATT4SPUDSVHFright313 (133)°6001ft - 14000ft1.0min timed210
SPUDS4SPUDSVHFright313 (133)°6001ft - 14000ft1.0min timed210
VCN9VCNNDBleft226 (46)°6001ft - 14000ft1.0min timed210
*) magnetic outbound (inbound) holding course
