Two Harbors - Richard B Helgeson

Airport details

CountryUnited States of America
StateMinnesota
RegionK3
AirspaceMinneapolis Ctr
MunicipalityLake County
Elevation1080ft (329m)
TimezoneGMT -6
Coordinates47.04914, -91.74522
Magnetic var
Typeland
Available sinceX-Plane v10.40
ICAO codeKTWM
IATA coden/a
FAA codeTWM

Communication

Richard B Helgeson AWOS 3119.325
Richard B Helgeson CTAF122.900
Richard B Helgeson DULUTH Approach/Departure125.450

Runway info

Runway 6 / 24
 length1338m (4390ft)
 bearing70° / 250°
 width23m (75ft)
 surfaceasphalt
Runway 15 / 33
 length786m (2579ft)
 bearing138° / 318°
 width48m (157ft)
 surfacegrass

Airport layout


Taxiway locations

 A
Parking locations

 Ramp

Nearby beacons

codeidentifierdistbearingfrequency
LKILAKESIDE (DULUTH) TACAN21.8245°135.40
DLHDULUTH VORTAC23.9242°112.60
DLPYKLA (DULUTH) NDB27.8252°379
HIBHIBBING VOR/DME41.9285°110.80
ELODME46.5354°109.60

Instrument approach procedures

runwayairway (heading)route (dist, bearing)
RW06FOSUP (89°)FOSUP
TARUE (7mi, 131°) 3100ft
 RNAVTARUE 3100ft
ZENKU (5mi, 70°) 3100ft
GIBEY (1mi, 70°) 3000ft
WIZNU (3mi, 70°) 1900ft
KTWM (3mi, 71°) 1113ft
(5477mi, 117°) 1420ft
WARIL (5466mi, 297°) 3000ft
WARIL (turn)
RW24SUZLI (241°)SUZLI
WARIL (13mi, 233°) 3000ft
RW24WARIL (250°)WARIL 3000ft
 RNAVWARIL 3000ft
ANATE (6mi, 250°) 2700ft
WIPAD (3mi, 250°) 1680ft
KTWM (2mi, 249°) 1110ft
(5477mi, 117°) 1320ft
GIBEY (5482mi, 297°)
FOSUP (10mi, 281°) 3600ft
FOSUP (turn)
