Country | Italy |
State | Campania |
Region | LI |
Airspace | Rome Ctr |
Municipality | Naples |
Elevation | 292ft (89m) |
Timezone | GMT +1 |
Coordinates | 40.88445, 14.29083 |
Magnetic var | |
Type | land |
Available since | X-Plane v10.32 |
ICAO code | LIRN |
IATA code | NAP |
FAA code | n/a |
Naples Capodichino ATIS | 135.975 |
Naples Capodichino NAPOLI Ground Control (Clearance DEL) | 121.900 |
Naples Capodichino NAPOLI Tower | 118.500 |
Naples Capodichino NAPOLI ApproachROACH | 124.350 |
Naples Capodichino NAPOLI RADAR | 124.350 |
ILS-cat-I | RW24 | 109.5 | 18.00mi |
ILS-cat-I | RW06 | 110.15 | 18.00mi |
3.5° GS | RW06 | 110.15 | 18.00mi |
3.3° GS | RW24 | 109.5 | 18.00mi |
code | identifier | dist | bearing | frequency |
---|---|---|---|---|
NAP | (NAPLES) DME-ILS | 0.5 | 49° | 110.95 |
POM | DME | 4.9 | 65° | 117.85 |
GRA | GRAZZANISE TACAN | 13.9 | 311° | 117.50 |
GRA | GRAZZANISE NDB | 14 | 310° | 343 |
SOR | SORRENTO NDB | 18.2 | 172° | 426 |
TEA | TEANO VOR/DME | 28.6 | 322° | 112.90 |
PTC | PONTECAGNANO (SALERNO) NDB | 32.2 | 113° | 324 |
FRS | FROSINONE VOR/DME | 64 | 307° | 115.60 |
Transition altitude | 8000ft |
SID end points | distance | outbound heading | |
---|---|---|---|
RW06 | |||
MOLU6J, MOLU6G, MOLU6H | 34mi | 51° | |
GALT6J, GALT6G | 31mi | 112° | |
POLI6J, POLI6G | 51mi | 144° | |
AGNI6J, AGNI6G | 68mi | 157° | |
DELE6J, DELE6G | 43mi | 191° | |
PEVI6J, PEVI6G | 39mi | 206° | |
EDOP6G, EDOP6J | 37mi | 229° | |
MALO6J, MALO6G | 38mi | 244° | |
ISKI6J, ISKI6G | 22mi | 244° | |
TEA6L, TEA6K, TEA6J, TEA6H, TEA6G | 29mi | 322° | |
RW24 | |||
MOLU6G, MOLU6J | 34mi | 51° | |
GALT6G, GALT6J | 31mi | 112° | |
POLI6G, POLI6J | 51mi | 144° | |
AGNI6J, AGNI6G | 68mi | 157° | |
DELE6J, DELE6G | 43mi | 191° | |
PEVI6J, PEVI6G | 39mi | 206° | |
EDOP6G, EDOP6J | 37mi | 229° | |
MALO6J, MALO6G | 38mi | 244° | |
ISKI6J, ISKI6G | 22mi | 244° | |
TEA6G, TEA6J, TEA6K | 29mi | 322° |
STAR starting points | distance | inbound heading | |
---|---|---|---|
RW06 | |||
PNZ1P, PNZ1R, PNZ1S | 60.5 | 91° | |
TEA1S | 28.6 | 142° | |
BENT1P, BENT1S | 19.9 | 245° | |
SOR1P, SOR1R, SOR1S | 18.2 | 352° | |
RW24 | |||
PNZ2W | 60.5 | 91° | |
TEA1M, TEA2W, TEA2Z | 28.6 | 142° | |
IPKA2Z | 24.6 | 230° | |
AMSO2Z | 30.9 | 245° | |
SOR2Z, SOR2Y, SOR2X, SOR2W, SOR1N, SOR1M | 18.2 | 352° |
runway | airway (heading) | route (dist, bearing) |
---|---|---|
RW06 | ISKIA (64°) | ISKIA 5000ft OLEVA (8mi, 67°) 4000ft RN561 (3mi, 62°) 3000ft |
RW06 | OLEVA (63°) | OLEVA 4000ft RN561 (3mi, 62°) 3000ft |
RNAV | RN561 3000ft RN562 (3mi, 62°) 3000ft RN563 (6mi, 62°) 625ft RN564 (5mi, 62°) RN565 (7mi, 271°) 4000ft GEMMA (13mi, 159°) SOR (8mi, 159°) SOR (turn) 6000ft | |
RW24-Y | UNPOP (289°) | UNPOP 8000ft RN513 (9mi, 346°) 4000ft RN512 (4mi, 289°) 2400ft |
RNAV | RN512 2400ft RN511 (3mi, 245°) 1900ft LIRN (5mi, 244°) 274ft LIRN (turn) 750ft GEMMA (10mi, 182°) 4000ft SOR (8mi, 159°) 6000ft SOR (turn) 6000ft | |
RW24-Z | BENTO (245°) | BENTO 7500ft RN516 (3mi, 245°) 5900ft |
RW24-Z | VUNHO (244°) | VUNHO 7000ft RN519 (13mi, 43°) 7000ft RN518 (3mi, 65°) 7000ft BENTO (5mi, 141°) 7000ft RN516 (3mi, 245°) 5900ft |
RNAV | RN516 5900ft RN515 (2mi, 245°) 4800ft RN514 (4mi, 245°) 3770ft LIRN (11mi, 244°) 274ft LIRN (turn) 750ft GEMMA (10mi, 182°) 4000ft SOR (8mi, 159°) 6000ft SOR (turn) 6000ft |
STAR name | hold at | type | turn | heading* | altitude | leg | speed limit |
---|---|---|---|---|---|---|---|
AMSO2Z | BENTO | VHF | right | 55 (235)° | 7500ft - 20000ft | 1.0min timed | 230 |
BENT1P | OLEVA | VHF | right | 231 (51)° | > 4000ft | DME 3.8mi | 210 |
BENT1S | ISKIA | VHF | right | 237 (57)° | > 5000ft | DME 4.2mi | 230 |
IPKA2Z | BENTO | VHF | right | 55 (235)° | 7500ft - 20000ft | 1.0min timed | 230 |
PNZ1P | OLEVA | VHF | right | 231 (51)° | > 4000ft | DME 3.8mi | 210 |
PNZ1R | OLEVA | VHF | right | 231 (51)° | > 4000ft | DME 3.8mi | 210 |
PNZ1S | ISKIA | VHF | right | 237 (57)° | > 5000ft | DME 4.2mi | 230 |
PNZ2W | VUNHO | VHF | left | 200 (20)° | 7000ft - 20000ft | 1.0min timed | 230 |
SOR1M | BENTO | VHF | right | 55 (235)° | 7500ft - 20000ft | 1.0min timed | 230 |
SOR1N | BENTO | VHF | right | 55 (235)° | 7500ft - 20000ft | 1.0min timed | 230 |
SOR1P | OLEVA | VHF | right | 231 (51)° | > 4000ft | DME 3.8mi | 210 |
SOR1R | OLEVA | VHF | right | 231 (51)° | > 4000ft | DME 3.8mi | 210 |
SOR1S | ISKIA | VHF | right | 237 (57)° | > 5000ft | DME 4.2mi | 230 |
SOR2W | VUNHO | VHF | left | 200 (20)° | 7000ft - 20000ft | 1.0min timed | 230 |
SOR2X | BENTO | VHF | right | 55 (235)° | 7500ft - 20000ft | 1.0min timed | 230 |
SOR2Y | UNPOP | VHF | right | 135 (315)° | 8000ft - 20000ft | DME 3.8mi | 200 |
SOR2Z | BENTO | VHF | right | 55 (235)° | 7500ft - 20000ft | 1.0min timed | 230 |
SOR2Z | UNPOP | VHF | right | 135 (315)° | 8000ft - 20000ft | DME 3.8mi | 200 |
TEA1M | BENTO | VHF | right | 55 (235)° | 7500ft - 20000ft | 1.0min timed | 230 |
TEA1S | ISKIA | VHF | right | 237 (57)° | > 5000ft | DME 4.2mi | 230 |
TEA2W | VUNHO | VHF | left | 200 (20)° | 7000ft - 20000ft | 1.0min timed | 230 |
TEA2Z | BENTO | VHF | right | 55 (235)° | 7500ft - 20000ft | 1.0min timed | 230 |
VUNH1P | OLEVA | VHF | right | 231 (51)° | > 4000ft | DME 3.8mi | 210 |
VUNH1S | ISKIA | VHF | right | 237 (57)° | > 5000ft | DME 4.2mi | 230 |
*) magnetic outbound (inbound) holding course |
