Elazığ - Elazig
Airport details
| Country | Turkey |
| State | Elazığ Province |
| Region | LT |
| Airspace | Ankara Ctr |
| Municipality | Elazığ |
| Elevation | 2924ft (891m) |
| Timezone | GMT +3 |
| Coordinates | 38.59778, 39.28139 |
| Magnetic var | |
| Type | land |
| Available since | X-Plane v10.40 |
| ICAO code | LTCA |
| IATA code | EZS |
| FAA code | n/a |
Communication
| Elazig Tower | 118.100 |
| Elazig Approach | 118.100 |
Approach frequencies
| ILS-cat-I | RW25 | 110.3 | 18.00mi |
| 3.5° GS | RW25 | 110.3 | 18.00mi |
Nearby beacons
| code | identifier | dist | bearing | frequency |
|---|---|---|---|---|
| ELG | KEBAN NDB | 0.1 | 111° | 338 |
| EZS | ELAZIG VOR/DME | 7.1 | 333° | 114.70 |
| DIY | DIYARBAKIR TACAN | 60.1 | 127° | 110 |
| DYB | DIYARBAKIR NDB | 61.6 | 128° | 330 |
| KHD | ADIYAMAN NDB | 65.3 | 223° | 381 |
Departure and arrival routes
| Transition altitude | 10000ft |
| SID end points | distance | outbound heading | |
|---|---|---|---|
| RW07 | |||
| ERTE1B | 22mi | 3° | |
| FILI1B | 18mi | 35° | |
| PALU1B | 13mi | 69° | |
| SORA1B | 11mi | 83° | |
| ERGA1B | 13mi | 252° | |
| BULU1B | 20mi | 293° | |
| ARPU1B | 22mi | 306° | |
| RW25 | |||
| ERTE1C | 22mi | 3° | |
| FILI1C | 18mi | 35° | |
| PALU1C | 13mi | 69° | |
| SORA1C | 11mi | 83° | |
| ERGA1C | 13mi | 252° | |
| BULU1C, BULU1D | 20mi | 293° | |
| ARPU1D, ARPU1C | 22mi | 306° | |
| STAR starting points | distance | inbound heading | |
|---|---|---|---|
| ALL | |||
| ERGA1E | 12.9 | 72° | |
| BULU1E | 20.1 | 113° | |
| ARPU1E | 21.6 | 126° | |
| ERTE1E | 21.5 | 183° | |
| FILI1E | 18.3 | 215° | |
| PALU1E | 13.1 | 249° | |
| SORA1E | 10.9 | 263° | |
| RW25 | |||
| BULU1F, BULU1A | 20.1 | 113° | |
| ARPU1F, ARPU1A | 21.6 | 126° | |
Holding patterns
| STAR name | hold at | type | turn | heading* | altitude | leg | speed limit |
|---|---|---|---|---|---|---|---|
| ARPU1A | ALFES | VHF | left | 340 (160)° | > 8000ft | 1.0min timed | ICAO rules |
| ARPU1E | EZS | NDB | right | 332 (152)° | > 8500ft | 1.0min timed | ICAO rules |
| ARPU1F | ALFES | VHF | left | 340 (160)° | > 8000ft | 1.0min timed | ICAO rules |
| BULU1A | ALFES | VHF | left | 340 (160)° | > 8000ft | 1.0min timed | ICAO rules |
| BULU1E | EZS | NDB | right | 332 (152)° | > 8500ft | 1.0min timed | ICAO rules |
| BULU1F | ALFES | VHF | left | 340 (160)° | > 8000ft | 1.0min timed | ICAO rules |
| ERGA1E | EZS | NDB | right | 332 (152)° | > 8500ft | 1.0min timed | ICAO rules |
| ERTE1E | EZS | NDB | right | 332 (152)° | > 8500ft | 1.0min timed | ICAO rules |
| EZS1A | ALFES | VHF | left | 340 (160)° | > 8000ft | 1.0min timed | ICAO rules |
| EZS1A | EZS | NDB | right | 332 (152)° | > 8500ft | 1.0min timed | ICAO rules |
| EZS1F | ALFES | VHF | left | 340 (160)° | > 8000ft | 1.0min timed | ICAO rules |
| EZS1F | EZS | NDB | right | 332 (152)° | > 8500ft | 1.0min timed | ICAO rules |
| FILI1E | EZS | NDB | right | 332 (152)° | > 8500ft | 1.0min timed | ICAO rules |
| HAZA1E | EZS | NDB | right | 332 (152)° | > 8500ft | 1.0min timed | ICAO rules |
| PALU1E | EZS | NDB | right | 332 (152)° | > 8500ft | 1.0min timed | ICAO rules |
| SORA1E | EZS | NDB | right | 332 (152)° | > 8500ft | 1.0min timed | ICAO rules |
| *) magnetic outbound (inbound) holding course | |||||||
Disclaimer
The information on this website is not for real aviation. Use this data with the X-Plane flight simulator only! Data taken with kind consent from X-Plane 12 source code and data files. Content is subject to change without notice.
