Airports for X-Plane

Santiago - Santiago Cibao Intl

Airport details

CountryDominican Republic
StateSantiago
RegionMD
AirspaceSanto Domingo Ctr
MunicipalityLicey Al Medio
Elevation562ft (171m)
TimezoneGMT -4
Coordinates19.40330, -70.60436
Magnetic var
Typeland
Available sinceX-Plane v10.40
ICAO codeMDST
IATA codeSTI
FAA coden/a

Communication

Santiago Cibao Intl Ground Control121.900
Santiago Cibao Intl SANTIAGO Tower118.300
Santiago Cibao Intl PUERTO PLATA Approach119.000

Approach frequencies

ILS-cat-IRW11109.318.00mi
2.8° GSRW11109.318.00mi

Runway info

Runway 11 / 29
 length2622m (8602ft)
 bearing102° / 282°
 width46m (151ft)
 surfaceasphalt
 displ threshold0m (0ft) / 31m (102ft)
 blast zone61m (200ft) / 60m (197ft)

Airport layout


Taxiway locations

 A  B  R
Parking locations

 Gate

Nearby beacons

codeidentifierdistbearingfrequency
SGOSANTIAGO VOR/DME0.28°114.90
PTAPUERTO PLATA VOR/DME21.45°115.10
DCYEL CATEY (SAMANA) VOR/DME49.599°115.80
DHGHIGUERO VOR/DME61.1143°116.60
LASGUERRA NDB70.3133°200
HIJSAN ISIDRO NDB71.5137°220
SISSAN ISIDRO VOR/DME72137°112.40

Departure and arrival routes

Transition altitude17000ft
SID end pointsdistanceoutbound heading
RW11
 PEKSA121mi5°
 LERE2U60mi9°
 KOBE2U50mi86°
 KODI2U31mi120°
 PIXO2U13mi205°
 PEKSA2, RETA2U78mi306°
 MALV2U75mi322°
RW29
 PEMPO221mi5°
 LERE2V60mi9°
 KOBE2V50mi86°
 KODI2V31mi120°
 PIXO2V13mi205°
 PEMPO1, RETA2V78mi306°
 MALV2V75mi322°

STAR starting pointsdistanceinbound heading
RW11
 BEPA2P48.163°
 RETA2P77.6126°
 JUEL2P67.4153°
 SEKA2P61.8169°
 POKE2P55.7215°
 PETR2P51.4279°
 RIBE2P39.3285°
RW29
 BEPA2R48.163°
 RETA2R77.6126°
 JUEL2R67.4153°
 SEKA2R61.8169°
 POKE2R55.7215°
 PETR2R51.4279°
 RIBE2R39.3285°

Instrument approach procedures

runwayairway (heading)route (dist, bearing)
RW11DELTI (103°)DELTI 4000ft
ST555 (5mi, 102°) 3500ft
 RNAVST555 3500ft
DAVBO (4mi, 102°) 3000ft
50THR (2mi, 102°) 2210ft
20THR (3mi, 102°) 1260ft
MDST (3mi, 105°) 615ft
ST556 (3mi, 100°)
ST557 (3mi, 160°)
ST558 (4mi, 219°)
ST559 (20mi, 280°)
DELTI (7mi, 13°) 4000ft
RW29KERDA (299°)KERDA 4000ft
ST560 (4mi, 14°) 3500ft
RW29VIPNA (265°)VIPNA 4000ft
ST560 (4mi, 194°) 3500ft
 RNAVST560 3500ft
URLUN (4mi, 282°) 3000ft
40THR (4mi, 282°) 1880ft
MDST (5mi, 281°) 612ft
ST565 (3mi, 285°)
ST566 (3mi, 195°)
KERDA (16mi, 105°) 4000ft

Holding patterns

STAR namehold attypeturnheading*altitudelegspeed limit
BEPA2PDELTIVHFleft294 (114)°4000ft - 60000ft1.0min timedICAO rules
BEPA2RKERDAVHFright204 (24)°4000ft - 60000ft1.0min timedICAO rules
JUEL2PDELTIVHFleft294 (114)°4000ft - 60000ft1.0min timedICAO rules
JUEL2RKERDAVHFright204 (24)°4000ft - 60000ft1.0min timedICAO rules
PETR2PDELTIVHFleft294 (114)°4000ft - 60000ft1.0min timedICAO rules
PETR2RVIPNAVHFleft24 (204)°4000ft - 60000ft1.0min timedICAO rules
POKE2PDELTIVHFleft294 (114)°4000ft - 60000ft1.0min timedICAO rules
POKE2RVIPNAVHFleft24 (204)°4000ft - 60000ft1.0min timedICAO rules
RETA2PDELTIVHFleft294 (114)°4000ft - 60000ft1.0min timedICAO rules
RETA2RKERDAVHFright204 (24)°4000ft - 60000ft1.0min timedICAO rules
RIBE2PDELTIVHFleft294 (114)°4000ft - 60000ft1.0min timedICAO rules
RIBE2RKERDAVHFright204 (24)°4000ft - 60000ft1.0min timedICAO rules
SEKA2PDELTIVHFleft294 (114)°4000ft - 60000ft1.0min timedICAO rules
SEKA2RKERDAVHFright204 (24)°4000ft - 60000ft1.0min timedICAO rules
*) magnetic outbound (inbound) holding course
