Tocumen - Tocumen Intl
Airport details
| Country | Panama |
| State | Panamá |
| Region | MP |
| Airspace | Panama Ctr |
| Municipality | Tocumen |
| Elevation | 133ft (41m) |
| Timezone | GMT -5 |
| Coordinates | 9.07139, -79.38333 |
| Magnetic var | |
| Type | land |
| Available since | X-Plane v10.40 |
| ICAO code | MPTO |
| IATA code | PTY |
| FAA code | n/a |
Communication
| Tocumen Intl Clearance DEL | 129.800 |
| Tocumen Intl Ground Control | 121.900 |
| Tocumen Intl Tower | 118.100 |
| Tocumen Intl PANAMA Approach | 119.700 |
Approach frequencies
| ILS-cat-I | RW03R | 110.7 | 18.00mi |
| 3° GS | RW03R | 110.7 | 18.00mi |
Nearby Points of Interest:
Panamá Viejo Cathedral
-Hospital Santo Tomas
-Instituto Conmemorativo Gorgas de Estudios de la Salud
-Embassy of Spain in Panama
-Former Panama Canal Railway station
-Casco Viejo
-Palacio Justo Arosemena
-Municipal Palace of Panama
-Gorgas Hospital
-Panama Bay
-Portobelo
-Fortifications on the Caribbean Side of Panama: Portobelo-San Lorenzo
Runway info
Runway 03R / 21L  | ||
| length | 3064m (10052ft) | |
| bearing | 30° / 210° | |
| width | 46m (151ft) | |
| surface | concrete | |
| blast zone | 58m (190ft) / 210m (689ft) | |
| Runway 03L / 21R | ||
| length | 2456m (8058ft) | |
| bearing | 31° / 211° | |
| width | 46m (151ft) | |
| surface | asphalt | |
| blast zone | 255m (837ft) / 61m (200ft) | |
Nearby beacons
| code | identifier | dist | bearing | frequency |
|---|---|---|---|---|
| TUM | TOCUMEN VOR/DME | 1.5 | 220° | 117.10 |
| TBG | TABOGA ISLAND VOR/DME | 20 | 212° | 110 |
| FNC | FRANCE VOR/DME | 33.5 | 300° | 109 |
| RHT | RIO HATO VOR/DME | 60.7 | 227° | 116.50 |
Departure and arrival routes
| Transition altitude | 18000ft |
| Transition level | 18000ft |
| SID end points | distance | outbound heading | |
|---|---|---|---|
| RW03L | |||
| EGET2B | 30mi | 38° | |
| RNP03L | 11mi | 64° | |
| SIMA2B | 34mi | 301° | |
| RW03R | |||
| EGET2A | 30mi | 38° | |
| RNP03R | 10mi | 70° | |
| SIMA2A | 34mi | 301° | |
| STAR starting points | distance | inbound heading | |
|---|---|---|---|
| RW03 (ALL) | |||
| SIRIL1 | 60.3 | 10° | |
| VUMA1A | 59.9 | 89° | |
| OSUP1B | 48.0 | 171° | |
| ISOKO1 | 60.2 | 326° | |
| RW03L | |||
| SIRIL2 | 60.3 | 10° | |
| VALIS1 | 29.5 | 107° | |
| AKRIN1 | 28.0 | 221° | |
| BUSUN1 | 33.8 | 276° | |
| ITEDO1 | 34.9 | 329° | |
| RW03R | |||
| SIRIL2 | 60.3 | 10° | |
| VALIS1 | 29.5 | 107° | |
| AKRIN1 | 28.0 | 221° | |
| BUSUN1 | 33.8 | 276° | |
| ITEDO1 | 34.9 | 329° | |
| RW21R | |||
| SIRIL2 | 60.3 | 10° | |
| VALIS1 | 29.5 | 107° | |
| OSUP1A | 48.0 | 171° | |
| AKRIN1 | 28.0 | 221° | |
| BUSUN1 | 33.8 | 276° | |
| ITEDO1 | 34.9 | 329° | |
Instrument approach procedures
| runway | airway (heading) | route (dist, bearing) |
|---|---|---|
| RW03LY | ISUMI (12°) | ISUMI 11000ft ILVOM (16mi, 358°) 7000ft TC182 (10mi, 358°) 5000ft TC181 (7mi, 31°) 3000ft |
| RW03LY | MEVID (233°) | MEVID 14000ft TC103 (8mi, 212°) 12000ft TC191 (7mi, 196°) 10000ft ENSIK (12mi, 196°) 7000ft TC189 (7mi, 254°) 5000ft TC187 (6mi, 301°) 3300ft TC181 (3mi, 10°) 3000ft |
| RW03LY | ROBOD (282°) | ROBOD 12000ft DOKNA (11mi, 253°) 9000ft ENSIK (10mi, 239°) 7000ft TC189 (7mi, 254°) 5000ft TC187 (6mi, 301°) 3300ft TC181 (3mi, 10°) 3000ft |
| RW03LY | TC105 (91°) | TC105 9000ft SIPIL (8mi, 134°) 7000ft TC185 (8mi, 134°) 4400ft TC184 (4mi, 104°) 3300ft TC181 (3mi, 52°) 3000ft |
| RW03LY | TC110 (345°) | TC110 7000ft GILDU (5mi, 301°) 6000ft TC188 (7mi, 301°) 4000ft TC187 (3mi, 325°) 3300ft TC181 (3mi, 10°) 3000ft |
| RNAV | TC181 3000ft TC180 (3mi, 31°) 2700ft MPTO (8mi, 33°) 151ft TC179 (2mi, 25°) TC178 (4mi, 55°) TC177 (5mi, 116°) DOKNA (11mi, 154°) 4000ft DOKNA (turn) 4000ft | |
| RW03L | BOBUD (3°) | BOBUD 3000ft MIPAR (7mi, 299°) 2000ft |
| RW03L | IRUSO (53°) | IRUSO 3000ft MIPAR (6mi, 101°) 2000ft |
| RW03L | NELEX (32°) | NELEX 3000ft MIPAR (6mi, 31°) 2000ft |
| RNAV | MIPAR 2000ft DILAK (7mi, 31°) 2000ft SD03L (3mi, 31°) 1050ft MIGOR (2mi, 31°) 469ft (4776mi, 97°) 535ft BOBUD (4776mi, 276°) 2000ft BOBUD (turn) | |
| RW03R | ISUMI (12°) | ISUMI 10000ft TISDA (20mi, 5°) 5000ft TC207 (10mi, 5°) 2300ft TC206 (3mi, 30°) 2000ft |
| RW03R | MEVID (233°) | MEVID 12000ft TC103 (8mi, 212°) 10000ft ISENI (12mi, 206°) 7000ft TC216 (7mi, 206°) 5000ft TC212 (8mi, 281°) 2300ft TC206 (2mi, 13°) 2000ft |
| RW03R | ROBOD (282°) | ROBOD 11000ft DOKNA (11mi, 253°) 8000ft ILSUS (7mi, 247°) 6000ft TC214 (7mi, 247°) 4000ft TC212 (7mi, 302°) 2300ft TC206 (2mi, 13°) 2000ft |
| RW03R | TC105 (91°) | TC105 8000ft SAMSU (12mi, 145°) 5000ft TC210 (6mi, 122°) 4000ft TC207 (6mi, 76°) 2300ft TC206 (3mi, 30°) 2000ft |
| RW03R | TC110 (345°) | TC110 6000ft KONSI (7mi, 310°) 4000ft TC213 (5mi, 310°) 3000ft TC212 (3mi, 333°) 2300ft TC206 (2mi, 13°) 2000ft |
| RNAV | TC206 2000ft TC205 (3mi, 30°) 1700ft MPTO (7mi, 28°) 71ft TC204 (turn) TC203 (5mi, 69°) TC202 (5mi, 155°) ISENI (2mi, 202°) 4000ft ISENI (turn) | |
| RW21RZ | AKRIN (221°) | AKRIN 8000ft MEVID (11mi, 200°) 5000ft TC148 (5mi, 217°) 4200ft TC147 (1mi, 217°) 3800ft TC146 (3mi, 245°) 2900ft |
| RW21RZ | ISUMI (12°) | ISUMI 14000ft ILTEL (41mi, 25°) 5000ft TC151 (5mi, 25°) 3900ft TC146 (6mi, 329°) 2900ft |
| RW21RZ | ROBOD (282°) | ROBOD 7000ft ENSEK (9mi, 304°) 5000ft TC149 (7mi, 304°) 3300ft TC146 (3mi, 288°) 2900ft |
| RW21RZ | TC105 (91°) | TC105 14000ft TC153 (25mi, 109°) 8000ft ILTEL (9mi, 68°) 5000ft TC151 (5mi, 25°) 3900ft TC146 (6mi, 329°) 2900ft |
| RW21RZ | TC110 (345°) | TC110 9000ft OTADU (18mi, 13°) 5000ft TC150 (5mi, 13°) 3700ft TC146 (5mi, 323°) 2900ft |
| RW21RZ | UREMO (256°) | UREMO 5000ft TC146 (10mi, 272°) 2900ft |
| RNAV | TC146 2900ft TC145 (2mi, 272°) 2600ft TC144 (2mi, 272°) TC143 (2mi, 242°) MPTO (5mi, 208°) 184ft TIRNU (10mi, 212°) 3100ft TIRNU (turn) | |
| RW21R | MUDEN (243°) | MUDEN 5000ft LOGAD (6mi, 296°) 3500ft |
| RW21R | UGIBA (224°) | UGIBA 5000ft LOGAD (6mi, 226°) 3500ft |
| RW21R | USANI (204°) | USANI 5000ft LOGAD (6mi, 156°) 3500ft |
| RNAV | LOGAD 3500ft GEMUG (6mi, 226°) 2300ft SD21R (3mi, 226°) 1350ft OSAVI (3mi, 226°) 419ft (4775mi, 97°) 535ft (turn) ERUMO (4805mi, 276°) 4000ft ERUMO (turn) |
Holding patterns
| STAR name | hold at | type | turn | heading* | altitude | leg | speed limit |
|---|---|---|---|---|---|---|---|
| ISOKO1 | UGETO | VHF | right | 138 (318)° | 5000ft - 60000ft | 1.0min timed | 230 |
| OSUP1A | IROLU | VHF | right | 337 (157)° | 5000ft - 60000ft | 1.0min timed | 230 |
| OSUP1B | IROLU | VHF | right | 337 (157)° | 5000ft - 60000ft | 1.0min timed | 230 |
| SIRIL1 | REPAL | VHF | right | 182 (2)° | 5000ft - 60000ft | 1.0min timed | 230 |
| VUMA1A | ERUMO | VHF | right | 282 (102)° | 5000ft - 60000ft | 1.0min timed | 230 |
| *) magnetic outbound (inbound) holding course | |||||||
Disclaimer
The information on this website is not for real aviation. Use this data with the X-Plane flight simulator only! Data taken with kind consent from X-Plane 12 source code and data files. Content is subject to change without notice.
