Airports for X-Plane

Santa Clara - El Salvador Intl

Airport details

CountryEl Salvador
StateDepartamento de La Paz
RegionMS
AirspaceCentral American Ctr
MunicipalitySan Luis Talpa
Elevation101ft (31m)
TimezoneGMT -6
Coordinates13.44094, -89.05576
Magnetic var
Typeland
Available sinceX-Plane v10.40
ICAO codeMSLP
IATA codeSAL
FAA coden/a

Communication

El Salvador Intl ATIS127.600
El Salvador Intl Clearance DEL121.250
El Salvador Intl Ground Control121.700
El Salvador Intl Tower118.000
El Salvador Intl Approach119.900

Approach frequencies

ILS-cat-IRW07110.318.00mi
ILS-cat-IRW25109.918.00mi
3° GSRW25109.918.00mi
2.5° GSRW07110.318.00mi
Nearby Points of Interest:
Catedral de Zacatecoluca
-
Hospital Nacional Rosales

Runway info

Runway 07 / 25
 length3203m (10509ft)
 bearing70° / 250°
 width46m (151ft)
 surfaceasphalt
 blast zone61m (200ft) / 61m (200ft)
Runway 17 / 35
 length811m (2661ft)
 bearing180° / 360°
 width25m (82ft)
 surfaceasphalt
 blast zone35m (115ft) / 0m (0ft)

Airport layout


Taxiway locations

 A  A1  AF  B  C  CARGO  D  E
 F  F1  FBO  M  N  O1  O2
Parking locations

 Gate

Nearby beacons

codeidentifierdistbearingfrequency
CATEL SALVADOR (SAN SALVADOR VOR/DME0.487°117.50
YSVILOPANGO (SAN SALVADOR) VOR/DME15.4346°116.50

Departure and arrival routes

Transition altitude19500ft
Transition level20000ft
SID end pointsdistanceoutbound heading
RW07
 MORAM3, MORA3C, MORA3A, MORA3B, MORA2F40mi4°
 URNOSE53mi7°
 ATUMA3, ATUM3C, ATUM3A, ATUM2F, ATUM3B40mi30°
 NAGELE56mi30°
 IMIM2F40mi58°
 MUTA2B, MUTA3A, MUTA3C, MUTAL3, MUTA3H40mi72°
 VITANE80mi72°
 UMIP3G40mi114°
 TUKORE80mi114°
 AMUV3H40mi128°
 ALTEGE82mi129°
 AMESA3, AMES3A40mi286°
 DUNELN, DUNELS64mi286°
 OBRASN, OBRASS62mi300°
 OLISU3, OLIS3A40mi308°
 KAPANN, KAPANS60mi308°
 IMAL2F40mi318°
 RELT3B, RELT2F, RELT3A, RELTA3, RELT3C40mi352°
 NOVOGE55mi353°
RW25
 MORAM3, MORA2D, MORA3A, MORA2F, MORA2E40mi4°
 URNOSW53mi7°
 NAGELW56mi30°
 ATUM3A, ATUMA3, ATUM2F, ATUM2E, ATUM2D40mi30°
 IMIM2F40mi58°
 MUTA3H, MUTA3A, MUTAL340mi72°
 VITANW80mi72°
 TUKORW80mi114°
 UMIP2D, UMIP2E, UMIP3G40mi114°
 AMUV2D, AMUV2E, AMUV3H40mi128°
 ALTEGW82mi129°
 ILOT2E, ILOT2D40mi145°
 AMES2D, AMES2E, AMES3A, AMESA340mi286°
 DUNELW64mi286°
 OBRASW62mi300°
 OLIS3A, OLISU3, OLIS2E, OLIS2D40mi308°
 KAPANW60mi308°
 IMAL2F40mi318°
 RELTA3, RELT3A, RELT2F, RELT2E, RELT2D40mi352°
 NOVOGW55mi353°

STAR starting pointsdistanceinbound heading
ALL
 AMES1M39.5106°
 DUNEL63.5106°
 OBRAS62.2120°
 OLIS1M39.7128°
 KAPAN59.5128°
 RELT1M40.1172°
 NOVOG55.1173°
 MORA1M40.2184°
 URNOS53.0187°
 NAGEL56.0210°
 ATUM1M40.4210°
 VITAN80.2252°
 MUTA1M40.4252°
 TUKOR79.7294°
 UMIP1M40.4294°
 AMUV1M40.4308°
 ALTEG81.7309°
 ILOT1M40.3325°
RW07
 RELT2L, RELT2K40.1172°
 MORA2L, MORA2K40.2184°
 ATUM2L, ATUM2K40.4210°

Instrument approach procedures

runwayairway (heading)route (dist, bearing)
RW07-WATUMA (210°)ATUMA 8000ft
LP584 (5mi, 209°)
LP582 (4mi, 228°)
LP580 (15mi, 246°) 8000ft
LP564 (6mi, 221°)
LP562 (2mi, 196°)
LP560 (2mi, 196°)
LP559 (3mi, 205°) 6000ft
LP558 (2mi, 220°)
LP556 (2mi, 226°) 4000ft
LP554 (7mi, 226°)
LP536 (7mi, 147°) 3000ft
RW07-WMORAM (184°)MORAM 8000ft
LP572 (14mi, 194°)
LP570 (1mi, 195°)
LP568 (1mi, 196°) 8000ft
LP564 (7mi, 196°)
LP562 (2mi, 196°)
LP560 (2mi, 196°)
LP559 (3mi, 205°) 6000ft
LP558 (2mi, 220°)
LP556 (2mi, 226°) 4000ft
LP554 (7mi, 226°)
LP536 (7mi, 147°) 3000ft
RW07-WRELTA (172°)RELTA 9200ft
LP664 (2mi, 176°)
LP578 (4mi, 160°)
LP574 (3mi, 143°)
LP570 (7mi, 170°)
LP568 (1mi, 196°) 8000ft
LP564 (7mi, 196°)
LP562 (2mi, 196°)
LP560 (2mi, 196°)
LP559 (3mi, 205°) 6000ft
LP558 (2mi, 220°)
LP556 (2mi, 226°) 4000ft
LP554 (7mi, 226°)
LP536 (7mi, 147°) 3000ft
 RNAVLP536 3000ft
MSLP (10mi, 70°) 118ft
LP602 (4mi, 70°)
LP590 (8mi, 125°)
LP533 (23mi, 182°) 3000ft
LP533 (turn) 3000ft
RW07-XATUMA (210°)ATUMA 8000ft
LP584 (5mi, 209°)
LP582 (4mi, 228°)
LP580 (15mi, 246°) 4100ft
LP564 (6mi, 221°) 3700ft
LP562 (2mi, 196°)
LP560 (2mi, 196°)
LP526 (10mi, 196°) 3500ft
RW07-XMORAM (184°)MORAM 8000ft
LP572 (14mi, 194°)
LP570 (1mi, 195°) 3900ft
LP568 (1mi, 196°)
LP564 (7mi, 196°) 3700ft
LP562 (2mi, 196°)
LP560 (2mi, 196°)
LP526 (10mi, 196°) 3500ft
RW07-XRELTA (172°)RELTA 9200ft
LP664 (2mi, 176°)
LP578 (4mi, 160°)
LP574 (3mi, 143°)
LP570 (7mi, 170°) 3900ft
LP568 (1mi, 196°)
LP564 (7mi, 196°) 3700ft
LP562 (2mi, 196°)
LP560 (2mi, 196°)
LP526 (10mi, 196°) 3500ft
 RNAVLP526 3500ft
LP504 (turn)
LP502 (5mi, 132°)
MSLP (4mi, 70°) 118ft
LP602 (4mi, 70°)
LP590 (8mi, 125°)
LP533 (23mi, 182°) 3000ft
LP533 (turn) 3000ft
RW07-YLP533 (339°)LP533 3000ft
LP528 (9mi, 2°)
LP524 (10mi, 325°)
LP518 (9mi, 288°)
LP516 (1mi, 301°) 3000ft
RW07-YLP544 (307°)LP544 3000ft
LP532 (24mi, 312°)
LP530 (3mi, 300°)
LP524 (21mi, 288°)
LP518 (9mi, 288°)
LP516 (1mi, 301°) 3000ft
RW07-YLP555 (296°)LP555 3000ft
LP530 (26mi, 289°)
LP524 (21mi, 288°)
LP518 (9mi, 288°)
LP516 (1mi, 301°) 3000ft
RW07-YLP566 (251°)LP566 7500ft
LP542 (4mi, 255°) 7500ft
LP540 (5mi, 249°) 6500ft
LP538 (33mi, 244°) 3300ft
LP534 (9mi, 244°)
LP520 (9mi, 244°)
LP518 (2mi, 266°)
LP516 (1mi, 301°) 3000ft
RW07-YMORAM (184°)MORAM 8000ft
LP552 (2mi, 194°)
LP550 (7mi, 165°)
LP548 (20mi, 136°) 8000ft
LP538 (16mi, 190°) 3300ft
LP534 (9mi, 244°)
LP520 (9mi, 244°)
LP518 (2mi, 266°)
LP516 (1mi, 301°) 3000ft
 RNAVLP516 3000ft
LP502 (5mi, 12°)
MSLP (4mi, 70°) 118ft
LP602 (4mi, 70°)
LP590 (8mi, 125°)
LP533 (23mi, 182°) 3000ft
LP533 (turn) 3000ft
RW07-ZAMESA (106°)AMESA 3300ft
LP512 (10mi, 105°)
LP510 (4mi, 118°) 3200ft
LP508 (8mi, 130°)
LP506 (11mi, 111°) 3000ft
RW07-ZLP522 (113°)LP522 8100ft
LP510 (15mi, 130°) 3200ft
LP508 (8mi, 130°)
LP506 (11mi, 111°) 3000ft
 RNAVLP506 3000ft
LP502 (6mi, 81°)
MSLP (4mi, 70°) 118ft
LP602 (4mi, 70°)
LP590 (8mi, 125°)
LP533 (23mi, 182°) 3000ft
LP533 (turn) 3000ft
RW25-WATUMA (210°)ATUMA 8000ft
LP584 (5mi, 209°)
LP686 (15mi, 209°) 4100ft
LP684 (2mi, 209°)
LP672 (2mi, 202°)
LP636 (6mi, 195°) 3500ft
RW25-WMORAM (184°)MORAM 8000ft
LP552 (2mi, 194°)
LP678 (4mi, 177°)
LP676 (14mi, 160°)
LP674 (3mi, 160°) 3800ft
LP672 (4mi, 178°)
LP636 (6mi, 195°) 3500ft
RW25-WRELTA (172°)RELTA 9200ft
LP664 (2mi, 176°)
LP682 (4mi, 159°)
LP680 (18mi, 142°)
LP674 (2mi, 151°) 3800ft
LP672 (4mi, 178°)
LP636 (6mi, 195°) 3500ft
 RNAVLP636 3500ft
LP634 (5mi, 195°)
LP602 (3mi, 223°)
MSLP (4mi, 250°) 151ft
LP502 (4mi, 250°)
LP690 (8mi, 194°)
LP533 (23mi, 137°) 3000ft
LP533 (turn) 3000ft
RW25-XATUMA (210°)ATUMA 8000ft
LP670 (2mi, 209°)
LP668 (5mi, 189°)
LP648 (15mi, 169°) 4100ft
LP632 (9mi, 210°)
LP626 (8mi, 250°) 3000ft
RW25-XLP566 (251°)LP566 7500ft
LP542 (4mi, 255°) 7500ft
LP642 (2mi, 253°)
LP640 (10mi, 251°) 6500ft
LP638 (20mi, 250°) 3100ft
LP632 (3mi, 250°)
LP626 (8mi, 250°) 3000ft
RW25-XMORAM (184°)MORAM 8000ft
LP552 (2mi, 194°)
LP658 (7mi, 163°)
LP654 (10mi, 133°) 8000ft
LP652 (10mi, 133°)
LP648 (4mi, 151°) 4100ft
LP632 (9mi, 210°)
LP626 (8mi, 250°) 3000ft
RW25-XRELTA (172°)RELTA 9200ft
LP664 (2mi, 176°)
LP662 (7mi, 147°)
LP660 (13mi, 119°)
LP654 (2mi, 126°) 8000ft
LP652 (10mi, 133°)
LP648 (4mi, 151°) 4100ft
LP632 (9mi, 210°)
LP626 (8mi, 250°) 3000ft
 RNAVLP626 3000ft
MSLP (10mi, 250°) 151ft
LP502 (4mi, 250°)
LP690 (8mi, 194°)
LP533 (23mi, 137°) 3000ft
LP533 (turn) 3000ft
RW25-YLP533 (339°)LP533 3000ft
LP622 (22mi, 2°)
LP616 (4mi, 337°) 3000ft
RW25-YLP544 (307°)LP544 3000ft
LP628 (28mi, 312°)
LP616 (22mi, 312°) 3000ft
RW25-YLP555 (296°)LP555 3000ft
LP630 (23mi, 289°)
LP628 (3mi, 300°)
LP616 (22mi, 312°) 3000ft
 RNAVLP616 3000ft
LP614 (3mi, 312°)
LP602 (3mi, 281°)
MSLP (4mi, 250°) 151ft
LP502 (4mi, 250°)
LP690 (8mi, 194°)
LP533 (23mi, 137°) 3000ft
LP533 (turn) 3000ft
RW25-ZAMESA (106°)AMESA 3300ft
LP619 (14mi, 106°)
LP618 (4mi, 106°) 3300ft
LP612 (4mi, 96°)
LP608 (19mi, 86°)
LP606 (3mi, 111°) 3000ft
RW25-ZLP522 (113°)LP522 8100ft
LP620 (11mi, 130°)
LP619 (4mi, 118°)
LP618 (4mi, 106°) 3300ft
LP612 (4mi, 96°)
LP608 (19mi, 86°)
LP606 (3mi, 111°) 3000ft
 RNAVLP606 3000ft
LP602 (5mi, 194°)
MSLP (4mi, 250°) 151ft
LP502 (4mi, 250°)
LP690 (8mi, 194°)
LP533 (23mi, 137°) 3000ft
LP533 (turn) 3000ft
