Havana - Playa Baracoa

Airport details

CountryCuba
StateArtemisa
RegionMU
AirspaceHavana Ctr
MunicipalityCaimito
Elevation102ft (31m)
TimezoneGMT -5
Coordinates23.03278, -82.57944
Magnetic var
Typeland
Available sinceX-Plane v10.40
ICAO codeMUPB
IATA codeUPB
FAA coden/a

Communication

Playa Baracoa Tower128.800
Nearby Points of Interest:
Old Havana

Runway info

Runway 03 / 21
 length2314m (7592ft)
 bearing24° / 204°
 width45m (148ft)
 surfaceasphalt
 displ threshold229m (751ft) / 223m (732ft)

Airport layout


Parking locations

Nearby beacons

codeidentifierdistbearingfrequency
UBPPLAYA BARACOA (HAVANA) NDB0.5188°250
UPBPLAYA BARACOA (HAVANA) VOR/DME0.5194°109.20
UHAHAVANA VOR/DME9109°116.10
UCYCAYABO (CAYAJABO) NDB18.4237°380
UZGZARAGO NDB30.4100°283

Departure and arrival routes

Transition altitude3000ft
STAR starting pointsdistanceinbound heading
RW21
 TEMBO221.5229°

Instrument approach procedures

runwayairway (heading)route (dist, bearing)
RW03PB700 (50°)PB700 3000ft
RABUP (6mi, 92°) 2000ft
RW03PB701 (356°)PB701 3000ft
RABUP (6mi, 310°) 2000ft
 RNAVRABUP 2000ft
PB705 (5mi, 23°) 1500ft
MUPB (5mi, 23°) 152ft
(4995mi, 106°) 1500ft
PB710 (5007mi, 286°)
PB710 (turn)
RW21PB711 (179°)PB711 3000ft
AXABI (6mi, 130°) 1500ft
RW21PB712 (227°)PB712 3000ft
AXABI (6mi, 272°) 1500ft
 RNAVAXABI 1500ft
PB720 (7mi, 204°) 1500ft
MUPB (5mi, 204°) 80ft
(4995mi, 106°) 1000ft
PB710 (5007mi, 286°)
PB710 (turn)
