Varadero - Juan Gualberto Gomez Intl
Airport details
| Country | Cuba |
| State | Matanzas |
| Region | MU |
| Airspace | Havana Ctr |
| Elevation | 208ft (63m) |
| Timezone | GMT -5 |
| Coordinates | 23.03444, -81.43528 |
| Magnetic var | |
| Type | land |
| Available since | X-Plane v10.40 |
| ICAO code | MUVR |
| IATA code | VRA |
| FAA code | n/a |
Communication
| Juan Gualberto Gomez Intl VARADERO Tower | 118.400 |
| Juan Gualberto Gomez Intl VARADERO RDO | 126.900 |
| Juan Gualberto Gomez Intl VARADERO Approach | 119.600 |
Approach frequencies
| ILS-cat-I | RW06 | 111.3 | 18.00mi |
| 3° GS | RW06 | 111.3 | 18.00mi |
Nearby beacons
| code | identifier | dist | bearing | frequency |
|---|---|---|---|---|
| UVA | VARDER VOR/DME | 1.1 | 242° | 114.80 |
| UVR | VARDER NDB | 5 | 51° | 272 |
| UZG | ZARAGO NDB | 33.8 | 261° | 283 |
| UHA | HAVANA VOR/DME | 54.9 | 267° | 116.10 |
Departure and arrival routes
| Transition altitude | 3000ft |
| SID end points | distance | outbound heading | |
|---|---|---|---|
| RW06 | |||
| IMUPA1 | 59mi | 12° | |
| OKUGI1 | 21mi | 38° | |
| TASL1A | 193mi | 124° | |
| IKUT1A | 30mi | 266° | |
| RW24 | |||
| PESBI3 | 121mi | 62° | |
| TARG1B | 86mi | 184° | |
| TILIT1 | 30mi | 266° | |
| STAR starting points | distance | inbound heading | |
|---|---|---|---|
| RW06 | |||
| TARG1A | 18.5 | 7° | |
| LETOV1 | 30.0 | 206° | |
| EBLEM1 | 15.1 | 282° | |
| RW24 | |||
| OKUGI1 | 21.3 | 218° | |
| TASL1B | 22.0 | 294° | |
Instrument approach procedures
| runway | airway (heading) | route (dist, bearing) |
|---|---|---|
| RW06 | VR510 (84°) | VR510 3000ft TILIT (6mi, 143°) 2500ft |
| RW06 | VR511 (30°) | VR511 3000ft TILIT (6mi, 324°) 2500ft |
| RNAV | TILIT 2500ft VILBA (5mi, 58°) 2000ft MUVR (6mi, 58°) 260ft (4932mi, 106°) 1500ft HIGOS (4923mi, 286°) HIGOS (turn) | |
| RW24 | VR520 (210°) | VR520 3000ft DASBA (6mi, 144°) 2000ft |
| RW24 | VR521 (264°) | VR521 3000ft DASBA (6mi, 324°) 2000ft |
| RNAV | DASBA 2000ft VR525 (5mi, 238°) 2000ft MUVR (6mi, 238°) 260ft (4932mi, 106°) 1500ft HIGOS (4923mi, 286°) HIGOS (turn) |
Holding patterns
| STAR name | hold at | type | turn | heading* | altitude | leg | speed limit |
|---|---|---|---|---|---|---|---|
| EBLEM1 | EBLEM | VHF | left | 75 (255)° | 7000ft - 14000ft | DME 4.4mi | 230 |
| LETOV1 | VR509 | VHF | right | 34 (214)° | 7000ft - 14000ft | DME 4.4mi | 230 |
| OKUGI1 | OKUGI | VHF | right | 54 (234)° | 4000ft - 14000ft | DME 4.2mi | 230 |
| TARG1A | TARGO | VHF | right | 155 (335)° | 5000ft - 14000ft | DME 4.2mi | 230 |
| TASL1B | TASLI | VHF | right | 154 (334)° | 4000ft - 14000ft | DME 4.2mi | 230 |
| *) magnetic outbound (inbound) holding course | |||||||
