Airports for X-Plane

Tehran - Mehrabad Intl

Airport details

CountryIran
StateTehran Province
RegionOI
AirspaceTehran Ctr
MunicipalityTehran
Elevation3963ft (1208m)
TimezoneGMT +3.5
Coordinates35.68396, 51.32215
Magnetic var
Typeland
Available sinceX-Plane v10.40
ICAO codeOIII
IATA codeTHR
FAA coden/a

Communication

Mehrabad Intl ATIS128.000
Mehrabad Intl Ground Control121.900
Mehrabad Intl Ground Control121.700
Mehrabad Intl Tower118.100
Mehrabad Intl Tower124.450
Mehrabad Intl Approach125.100
Mehrabad Intl Approach119.700
Mehrabad Intl Departure121.850

Approach frequencies

ILS-cat-IRW29L109.918.00mi
ILS-cat-IRW29R110.718.00mi
3.3° GSRW29L109.918.00mi
3.3° GSRW29R110.718.00mi
Nearby Points of Interest:
University of Tehran Main Entrance
-
Senate Palace (Tehran)
-
Ettehadieh House
-
Trans-Iranian Railway
-
Hasanabad
-
Saleh House
-
Anoushiravan Dadgar High School

Runway info

Runway 11L / 29R
 length3998m (13117ft)
 bearing106° / 286°
 width45m (148ft)
 surfaceconcrete
 displ threshold897m (2943ft) / 8m (26ft)
 blast zone255m (837ft) / 114m (374ft)
Runway 11R / 29L
 length4045m (13271ft)
 bearing106° / 286°
 width60m (197ft)
 surfaceasphalt
 displ threshold5m (16ft) / 5m (16ft)
 blast zone255m (837ft) / 80m (262ft)

Airport layout


Taxiway locations

 11L  11R  29L  29R  A  A1  A2  A3
 A4  A5  A6  A7  A8  B1  B2  B3
 B4  B5  B6  B8  B9  C  C1  C2
 C3  C4W  C5  C6  C8  C9  K  U
 V  W  Y
Parking locations

 100  101  102  103  104  105  106  107
 108  109  110  111  112  113  114  115
 116  117  118  119  120  121  201  202
 203  204  205  206  301  302  303  304
 305  306  307  308  310  312  400  401
 402  403  404  405  406  407  408  409
 410  501  502  503  504  505  506  507
 508  509  C1  C2  Cargo  F1  F2  G1
 G2  G3  G4  G5  H1  K1  K2  M1
 M2  M3

Nearby beacons

codeidentifierdistbearingfrequency
TRNTEHRAN VOR/DME2289°115.30
THRTEHRAN TACAN2.2289°113.30
KAZKAHRIZAK NDB10.2165°358
IKAIMAM KHOMAINI NDB17.8206°201
IKAIMAM KHOMAINI VOR/DME17.9208°114.30
PIMPAYAM VOR/DME23.4279°117.50
PIMPAYAM NDB23.5279°306
RUSRUDESHUR VOR/DME24.8240°116.95
VRVARAMIN NDB25.6137°373
NSRNOSHAHR NDB599°260
SAVSAVEH NDB61.3235°408

Departure and arrival routes

Transition altitude9000ft
Transition level11000ft
SID end pointsdistanceoutbound heading
RW11 (ALL)
 NAGM1B21mi4°
 DHN3B73mi107°
 OBRI2B69mi138°
 ELUS1D, ELUS1B70mi178°
 EGVE2B71mi220°
 SAV3C, SAV2B61mi235°
 RUS2B25mi240°
 DAXI1B99mi245°
 PAVE3C, PAVE2B72mi261°
 PARO4C, PARO3B72mi291°
 PAXI3B60mi301°
RW29 (ALL)
 NAGM1A21mi4°
 DHN2C, DHN3A73mi107°
 OBRI2C, OBRI2A69mi138°
 ELUS1C, ELUS1A70mi178°
 EGVE2A71mi220°
 SAV2A61mi235°
 RUS2A25mi240°
 DAXI1A99mi245°
 PAVE2A72mi261°
 PARO3A72mi291°
 PAXI3A60mi301°

STAR starting pointsdistanceinbound heading
ALL
 SAV1Z, SAV1R, SAV1N61.355°
 RUS1Z, RUS1V24.860°
 PAVE2R71.781°
 MIVA3R, MIVA3N, MIVA1Y, MIVA2Z72.0102°
 PAXI1Y, PAXI2Z, PAXI2R, PAXI2N59.8121°
 NAGM2R, NAGM1V21.2184°
 MUXO1N, MUXO2Z, MUXO2P, MUXO1V68.1278°
 RADA2V, RADA2R, RADA2P, RADA1N68.3307°
 BOXA1P, BOXA2V, BOXA2N, BOXA1Z, BOXA1R68.6333°
RW11 (ALL)
 SAV1V61.355°
 PAVE1S71.781°
 MIVA1S72.0102°
 PAXI1S59.8121°
RW29 (ALL)
 MUXO1S68.1278°
 RADA1S68.3307°
 BOXA1S68.6333°

Holding patterns

STAR namehold attypeturnheading*altitudelegspeed limit
BOXA1PPARIRVHFleft105 (285)°> 11000ft1.0min timed220
BOXA1RRUSNDBleft227 (47)°> 9000ft1.0min timed220
BOXA1SKAZFIXright276 (96)°> 8000ft1.0min timed220
BOXA1SVRFIXright181 (1)°> 9000ft1.0min timed220
BOXA1ZKAZFIXright276 (96)°> 8000ft1.0min timed220
BOXA2NRUSNDBleft227 (47)°> 9000ft1.0min timed220
BOXA2NVRFIXright181 (1)°> 9000ft1.0min timed220
BOXA2VVRFIXright181 (1)°> 9000ft1.0min timed220
MIVA1SKAZFIXright276 (96)°> 8000ft1.0min timed220
MIVA1SRUSNDBleft227 (47)°> 9000ft1.0min timed220
MIVA1YD273TVHFleft273 (93)°> 9000ft1.0min timedICAO rules
MIVA2ZKAZFIXright276 (96)°> 8000ft1.0min timed220
MIVA3NKAZFIXright276 (96)°> 8000ft1.0min timed220
MIVA3NRUSNDBleft227 (47)°> 9000ft1.0min timed220
MIVA3RRUSNDBleft227 (47)°> 9000ft1.0min timed220
MUXO1NRUSNDBleft227 (47)°> 9000ft1.0min timed220
MUXO1NVRFIXright181 (1)°> 9000ft1.0min timed220
MUXO1SKAZFIXright276 (96)°> 8000ft1.0min timed220
MUXO1SVRFIXright181 (1)°> 9000ft1.0min timed220
MUXO1VVRFIXright181 (1)°> 9000ft1.0min timed220
MUXO2PPARIRVHFleft105 (285)°> 11000ft1.0min timed220
MUXO2ZKAZFIXright276 (96)°> 8000ft1.0min timed220
NAGM1VVRFIXright181 (1)°> 9000ft1.0min timed220
NAGM2RRUSNDBleft227 (47)°> 9000ft1.0min timed220
PAVE1SKAZFIXright276 (96)°> 8000ft1.0min timed220
PAVE1SRUSNDBleft227 (47)°> 9000ft1.0min timed220
PAVE2RRUSNDBleft227 (47)°> 9000ft1.0min timed220
PAXI1SKAZFIXright276 (96)°> 8000ft1.0min timed220
PAXI1SRUSNDBleft227 (47)°> 9000ft1.0min timed220
PAXI1YD273TVHFleft273 (93)°> 9000ft1.0min timedICAO rules
PAXI2NKAZFIXright276 (96)°> 8000ft1.0min timed220
PAXI2NRUSNDBleft227 (47)°> 9000ft1.0min timed220
PAXI2RRUSNDBleft227 (47)°> 9000ft1.0min timed220
PAXI2ZKAZFIXright276 (96)°> 8000ft1.0min timed220
RADA1NRUSNDBleft227 (47)°> 9000ft1.0min timed220
RADA1NVRFIXright181 (1)°> 9000ft1.0min timed220
RADA1SKAZFIXright276 (96)°> 8000ft1.0min timed220
RADA1SVRFIXright181 (1)°> 9000ft1.0min timed220
RADA2PPARIRVHFleft105 (285)°> 11000ft1.0min timed220
RADA2RRUSNDBleft227 (47)°> 9000ft1.0min timed220
RADA2VVRFIXright181 (1)°> 9000ft1.0min timed220
RUS1VRUSNDBleft227 (47)°> 9000ft1.0min timed220
RUS1VVRFIXright181 (1)°> 9000ft1.0min timed220
RUS1ZKAZFIXright276 (96)°> 8000ft1.0min timed220
RUS1ZRUSNDBleft227 (47)°> 9000ft1.0min timed220
SAV1NKAZFIXright276 (96)°> 8000ft1.0min timed220
SAV1NRUSNDBleft227 (47)°> 9000ft1.0min timed220
SAV1RRUSNDBleft227 (47)°> 9000ft1.0min timed220
SAV1VKAZFIXright276 (96)°> 8000ft1.0min timed220
SAV1VRUSNDBleft227 (47)°> 9000ft1.0min timed220
SAV1ZKAZFIXright276 (96)°> 8000ft1.0min timed220
VR1RRUSNDBleft227 (47)°> 9000ft1.0min timed220
VR1RVRFIXright181 (1)°> 9000ft1.0min timed220
VR1ZKAZFIXright276 (96)°> 8000ft1.0min timed220
VR1ZVRFIXright181 (1)°> 9000ft1.0min timed220
*) magnetic outbound (inbound) holding course

Disclaimer

The information on this website is not for real aviation. Use this data with the X-Plane flight simulator only! Data taken with kind consent from X-Plane 12 source code and data files. Content is subject to change without notice.
