Najaf - Najaf Al Ashraf Intl
Airport details
| Country | Iraq |
| State | Al-Najaf Governorate |
| Region | OR |
| Airspace | Baghdad Ctr |
| Municipality | Najaf |
| Elevation | 103ft (31m) |
| Timezone | GMT +3 |
| Coordinates | 31.98984, 44.40433 |
| Magnetic var | |
| Type | land |
| Available since | X-Plane v10.40 |
| ICAO code | ORNI |
| IATA code | NJF |
| FAA code | n/a |
Communication
| Najaf Al Ashraf Intl ATIS | 123.900 |
| Najaf Al Ashraf Intl Al Najaf Ground | 121.700 |
| Najaf Al Ashraf Intl Al Najaf Tower | 119.100 |
Approach frequencies
| ILS-cat-I | RW10 | 108.3 | 18.00mi |
| ILS-cat-I | RW28 | 108.9 | 18.00mi |
| 3° GS | RW10 | 108.3 | 18.00mi |
| 3° GS | RW28 | 108.9 | 18.00mi |
Nearby Points of Interest:
Wadi-us-Salaam
Nearby beacons
| code | identifier | dist | bearing | frequency |
|---|---|---|---|---|
| ALI | AL-ASHRAF (AL NAJAF) NDB | 0.3 | 311° | 275 |
Departure and arrival routes
| Transition altitude | 14000ft |
| SID end points | distance | outbound heading | |
|---|---|---|---|
| RW10 | |||
| SEPT1A | 76mi | 15° | |
| NOLD1A, NOLD1C | 70mi | 49° | |
| ILMA1A | 136mi | 104° | |
| SIGB1A | 122mi | 297° | |
| LAGL1A | 77mi | 353° | |
| RW28 | |||
| SEPT1B | 76mi | 15° | |
| NOLD1B | 70mi | 49° | |
| ILMA1B | 136mi | 104° | |
| SIGB1B | 122mi | 297° | |
| LAGL1B | 77mi | 353° | |
| STAR starting points | distance | inbound heading | |
|---|---|---|---|
| RW10 | |||
| EGPE1A, EGPE1C | 44.7 | 115° | |
| LOVE1A | 26.3 | 215° | |
| ALRI1A | 76.7 | 287° | |
| ALPE1A | 108.3 | 292° | |
| RW28 | |||
| EGPE1B | 44.7 | 115° | |
| LOVE1B | 26.3 | 215° | |
| ALRI1D, ALRI1B | 76.7 | 287° | |
Instrument approach procedures
| runway | airway (heading) | route (dist, bearing) |
|---|---|---|
| RW10 | AMBIG (137°) | AMBIG 5000ft BOPUS (9mi, 196°) 2000ft |
| RW10 | BUBAT (69°) | BUBAT 5000ft BOPUS (9mi, 16°) 2000ft |
| RNAV | BOPUS 2000ft NI103 (5mi, 102°) 2000ft ORNI (7mi, 102°) 166ft NI101 (2mi, 102°) KASIP (18mi, 76°) KASIP (turn) 5000ft | |
| RW28 | BOREM (317°) | BOREM 5000ft DATIN (9mi, 16°) 2000ft |
| RW28 | ELUTA (250°) | ELUTA 5000ft DATIN (9mi, 197°) 2000ft |
| RNAV | DATIN 2000ft NI203 (5mi, 282°) 2000ft ORNI (7mi, 282°) 142ft NI201 (2mi, 282°) GESAL (18mi, 310°) GESAL (turn) 5000ft |
Holding patterns
| STAR name | hold at | type | turn | heading* | altitude | leg | speed limit |
|---|---|---|---|---|---|---|---|
| ALRI1A | KASIP | VHF | right | 72 (252)° | > 5000ft | 1.0min timed | 230 |
| ALRI1B | KASIP | VHF | right | 72 (252)° | > 5000ft | 1.0min timed | 230 |
| EGPE1A | GESAL | VHF | left | 307 (127)° | > 5000ft | 1.0min timed | 230 |
| EGPE1B | GESAL | VHF | left | 307 (127)° | > 5000ft | 1.0min timed | 230 |
| *) magnetic outbound (inbound) holding course | |||||||
