Airports for X-Plane

Naga

Airport details

CountryPhilippines
StateCamarines Sur
RegionRP
AirspaceManila Ctr
Elevation142ft (43m)
TimezoneGMT +8
Coordinates13.58106, 123.26197
Magnetic var
Typeland
Available sinceX-Plane v10.40
ICAO codeRPUN
IATA codeWNP
FAA coden/a

Communication

Naga CTAF121.900
Naga Tower122.100
Nearby Points of Interest:
Tabaco Church

Runway info

Runway 04 / 22
 length1406m (4613ft)
 bearing46° / 226°
 width30m (98ft)
 surfaceasphalt

Airport layout


Parking locations

 Terminal

Nearby beacons

codeidentifierdistbearingfrequency
NGANAGA (PILI) VOR/DME0.481°114.70
LPLEGAZPI VOR/DME37.5133°112.20
VCVIRAC NDB55.587°268

Departure and arrival routes

Transition altitude11000ft
Transition level13000ft
SID end pointsdistanceoutbound heading
RW04
 MASB1P, MASB3P76mi163°
 MECA1P32mi296°
RW22
 MASB1N76mi163°
 MECA1N32mi296°

STAR starting pointsdistanceinbound heading
RW04
 RAGA2P, RAGA4P40.5102°
 MASB2P75.9343°

Instrument approach procedures

runwayairway (heading)route (dist, bearing)
RW04EMBAW (73°)EMBAW 3800ft
UN04A (6mi, 134°) 2500ft
RW04PENIA (45°)PENIA 3000ft
UN04A (6mi, 45°) 2500ft
RW04SAROG (20°)SAROG 3000ft
UN04A (5mi, 314°) 2500ft
 RNAVUN04A 2500ft
UN04B (4mi, 45°) 2500ft
RPUN (7mi, 44°) 178ft
LABAC (7mi, 178°)
SAROG (6mi, 226°) 3000ft
SAROG (turn) 3000ft

Holding patterns

STAR namehold attypeturnheading*altitudelegspeed limit
LP2PSAROGVHFleft136 (316)°3000ft - 7000ft1.0min timed170
MASB2PPENIAVHFleft226 (46)°3000ft - 7000ft1.0min timed170
RAGA2PPENIAVHFleft226 (46)°3000ft - 7000ft1.0min timed170
RAGA4PEMBAWVHFright316 (136)°3800ft - 7000ft1.0min timed170
*) magnetic outbound (inbound) holding course
