Airports for X-Plane

Puerto Madryn - El Tehuelche

Airport details

CountryArgentina
StateChubut Province
RegionSA
AirspaceComodoro Rivadavia Ctr
MunicipalityMunicipio de Puerto Madryn
Elevation423ft (129m)
TimezoneGMT -3
Coordinates-42.75917, -65.10278
Magnetic var
Typeland
Available sinceX-Plane v10.40
ICAO codeSAVY
IATA codePMY
FAA coden/a

Communication

El Tehuelche Tower119.500

Runway info

Runway 05 / 23
 length2498m (8196ft)
 bearing65° / 245°
 width45m (148ft)
 surfaceasphalt
 blast zone10m (33ft) / 10m (33ft)

Airport layout


Parking locations

 Apron  New

Nearby beacons

codeidentifierdistbearingfrequency
DRYMADRYN (PUERTO MADRYN) VOR/DME0113°116.10
YEL TEHUELCHE (PUERTO MADRYN) NDB1.366°300
TTRELEW NDB27.2197°280
TRETRELEW VOR/DME27.3198°115.10

Departure and arrival routes

Transition altitude3000ft
SID end pointsdistanceoutbound heading
RW06
 ORAM2M29mi1°
 LOMU1M128mi38°
 OPSI1M83mi194°
 GATU2M82mi212°
 EKAT2M66mi254°
 SILA2M57mi267°
RW24
 ORAM2G29mi1°
 LOMU1G128mi38°
 OPSI1G83mi194°
 GATU2G82mi212°
 EKAT2G66mi254°
 SILA2G57mi267°

Instrument approach procedures

runwayairway (heading)route (dist, bearing)
RW06PUBAX (85°)PUBAX 3000ft
ILNEL (5mi, 140°) 2100ft
RW06TEPES (41°)TEPES 3000ft
ILNEL (5mi, 320°) 2100ft
RW06UTLEP (65°)UTLEP 3000ft
ILNEL (5mi, 65°) 2100ft
 RNAVILNEL 2100ft
MUNAV (5mi, 65°) 2080ft
SAVY (6mi, 65°) 480ft
VY610 (2mi, 65°)
PUBAX (14mi, 262°) 3000ft
PUBAX (turn) 3000ft
RW24IRINU (262°)IRINU 3000ft
ASUPI (5mi, 300°) 2100ft
RW24LIVUX (226°)LIVUX 3000ft
ASUPI (5mi, 164°) 2100ft
RW24NUEXE (245°)NUEXE 3000ft
ASUPI (5mi, 245°) 2100ft
 RNAVASUPI 2100ft
KOLVA (5mi, 245°) 2080ft
SAVY (6mi, 245°) 483ft
VY620 (2mi, 245°)
LIVUX (15mi, 49°) 3000ft
LIVUX (turn) 3000ft
