Airports for X-Plane

Ushuahia - Ushuaia Malvinas Intl

Airport details

CountryArgentina
StateTierra del Fuego Province
RegionSA
AirspaceComodoro Rivadavia Ctr
MunicipalityUshuaia
Elevation102ft (31m)
TimezoneGMT -3
Coordinates-54.84333, -68.29556
Magnetic var
Typeland
Available sinceX-Plane v10.40
ICAO codeSAWH
IATA codeUSH
FAA coden/a

Communication

Ushuaia Malvinas Intl Ushuaia Torre118.100
Ushuaia Malvinas Intl AUX122.100

Approach frequencies

ILS-cat-IRW25111.318.00mi
3.5° GSRW25111.318.00mi
Nearby Points of Interest:
Casa Ramos
-
Ushuaia Prison

Runway info

Runway 07 / 25
 length2796m (9173ft)
 bearing88° / 268°
 width45m (147ft)
 surfaceconcrete
 displ threshold180m (591ft) / 162m (531ft)
 blast zone84m (276ft) / 138m (453ft)

Airport layout


Taxiway locations

 A  B  C
Parking locations

 1  2  3

Nearby beacons

codeidentifierdistbearingfrequency
USUUSHUAIA VOR0.565°113.70
PWLPUERTO WILLIAMS VOR/DME23.897°114.90

Departure and arrival routes

Transition altitude8000ft
SID end pointsdistanceoutbound heading
RW07
 USU2A21mi356°
RW25
 USU2B21mi356°

STAR starting pointsdistanceinbound heading
RW25
 DABLI230.0241°

Instrument approach procedures

runwayairway (heading)route (dist, bearing)
RW25-YMIBOK (268°)MIBOK 6500ft
WH768 (5mi, 199°) 6000ft
WH064 (4mi, 276°) 5000ft
RENEN (7mi, 277°) 2700ft
 RNAVRENEN 2700ft
WH876 (4mi, 280°) 1800ft
TOBTO (2mi, 280°) 1200ft
FTP (3mi, 271°) 121ft
WH792 (1mi, 271°)
WH292 (5mi, 128°)
WH488 (10mi, 85°)
USU (12mi, 277°) 8000ft
USU (turn) 8000ft
RW25-ZMIBOK (268°)MIBOK 6500ft
WH087 (2mi, 268°) 5800ft
MUGUM (2mi, 268°) 5300ft
 RNAVMUGUM 5300ft
UGSIN (5mi, 268°) 4100ft
WH092 (3mi, 268°) 2950ft
WH192 (3mi, 268°) 1700ft
SAWH (5mi, 268°) 121ft
WH588 (turn)
WH292 (5mi, 126°)
WH488 (10mi, 85°)
USU (12mi, 277°) 8000ft
USU (turn) 8000ft

Holding patterns

STAR namehold attypeturnheading*altitudelegspeed limit
DABLI2EDPANVHFleft344 (164)°10000ft - 60000ft1.0min timedICAO rules
*) magnetic outbound (inbound) holding course

Disclaimer

The information on this website is not for real aviation. Use this data with the X-Plane flight simulator only! Data taken with kind consent from X-Plane 12 source code and data files. Content is subject to change without notice.
