Country | Brazil |
State | Minas Gerais |
Region | SB |
Airspace | Brasilia Ctr |
Municipality | Santana do Paraíso |
Elevation | 784ft (239m) |
Timezone | GMT -3 |
Coordinates | -19.47056, -42.48778 |
Magnetic var | |
Type | land |
Available since | X-Plane v10.40 |
ICAO code | SBIP |
IATA code | IPN |
FAA code | n/a |
Usiminas RDO | 130.000 |
code | identifier | dist | bearing | frequency |
---|---|---|---|---|
YPT | DME-ILS | 0.2 | 182° | 110.90 |
YPT | IPATINGA NDB | 0.6 | 48° | 16.180 |
Transition altitude | 5000ft |
SID end points | distance | outbound heading | |
---|---|---|---|
RW05 | |||
ALDU1A | 59mi | 129° | |
OMNI | 84mi | 263° | |
RW23 | |||
ISIT1A | 59mi | 129° | |
OMNI | 84mi | 263° |
runway | airway (heading) | route (dist, bearing) |
---|---|---|
RW05-Z | IP009 (22°) | IP009 6000ft IP006 (5mi, 16°) 4000ft |
RW05-Z | IP011 (49°) | IP011 6000ft IP006 (5mi, 105°) 4000ft |
RW05-Z | IP012 (356°) | IP012 6000ft IP006 (5mi, 285°) 4000ft |
RNAV | IP006 4000ft IP007 (5mi, 16°) 2430ft IP008 (3mi, 32°) 1630ft SBIP (3mi, 31°) 833ft (2760mi, 65°) 2200ft IP012 (2763mi, 245°) 6000ft IP012 (turn) 6000ft | |
RW23-Y | IP016 (237°) | IP016 6000ft IP013 (5mi, 299°) 4000ft |
RW23-Y | IP017 (212°) | IP017 6000ft IP013 (5mi, 212°) 4000ft |
RW23-Y | IP018 (185°) | IP018 6000ft IP013 (5mi, 119°) 4000ft |
RNAV | IP013 4000ft IP014 (5mi, 212°) 2430ft SBIP (6mi, 212°) 836ft (2760mi, 65°) 2200ft IP016 (2748mi, 245°) 6000ft IP016 (turn) 6000ft |
