Airports for X-Plane

São Gabriel Da Cachoeira - Sao Gabriel Da Cachoeira

Airport details

CountryBrazil
StateAmazonas
RegionSB
AirspaceAmazonica Ctr
MunicipalitySão Gabriel da Cachoeira
Elevation249ft (76m)
TimezoneGMT -4
Coordinates-0.14806, -66.98583
Magnetic var
Typeland
Available sinceX-Plane v10.40
ICAO codeSBUA
IATA codeSJL
FAA coden/a

Communication

Sao Gabriel da Cachoeira GABRIEL RDO125.700

Runway info

Runway 05 / 23
 length2611m (8566ft)
 bearing42° / 222°
 width45m (148ft)
 surfaceasphalt

Airport layout


Taxiway locations

 A  B
Parking locations

 Gate

Nearby beacons

codeidentifierdistbearingfrequency
GBRSAO GABRIEL DA CACHOEIRA VOR/DME0.3245°116.60

Departure and arrival routes

Transition altitude3000ft
SID end pointsdistanceoutbound heading
RW05
 DEXE1A, EDPI1A27mi185°
RW23
 EPDO1A27mi113°
 ASGU1A, KUBK1A27mi185°

Instrument approach procedures

runwayairway (heading)route (dist, bearing)
RW05UA003 (59°)UA003 4000ft
UA002 (5mi, 113°) 2500ft
RW05UA004 (42°)UA004 4000ft
UA002 (5mi, 42°) 2500ft
RW05UA006 (25°)UA006 4000ft
UA002 (5mi, 333°) 2500ft
 RNAVUA002 2500ft
UA001 (8mi, 42°) 1890ft
SD05 (3mi, 42°) 980ft
SBUA (3mi, 42°) 298ft
(4023mi, 90°) 2000ft
UA003 (4037mi, 270°) 4000ft
UA003 (turn) 4000ft
RW23UA009 (243°)UA009 4000ft
UA008 (5mi, 293°) 2500ft
RW23UA011 (202°)UA011 4000ft
UA008 (5mi, 153°) 2500ft
RW23UA012 (222°)UA012 4000ft
UA008 (5mi, 222°) 2500ft
 RNAVUA008 2500ft
DEXEG (5mi, 222°) 1890ft
UA018 (3mi, 222°) 986ft
SBUA (3mi, 223°) 295ft
(4023mi, 90°) 2000ft
UA011 (4018mi, 270°) 4000ft
UA011 (turn) 4000ft
