Airports for X-Plane

Cali - Alfonso Bonilla Aragón Intl

Airport details

CountryColombia
StateValle del Cauca
RegionSK
AirspaceBogota Ctr
MunicipalityPalmira
Elevation3162ft (964m)
TimezoneGMT -5
Coordinates3.54359, -76.38575
Magnetic var
Typeland
Available sinceX-Plane v10.30
ICAO codeSKCL
IATA codeCLO
FAA coden/a

Communication

Alfonso Bonilla Aragón Intl MET127.675
Alfonso Bonilla Aragón Intl CALI INFORMACION115.500
Alfonso Bonilla Aragón Intl CALI CONTROL126.700
Alfonso Bonilla Aragón Intl CALI CONTROL EMERGENCY121.500
Alfonso Bonilla Aragón Intl ALFONSO BONILLA ARAGON Tower118.100
Alfonso Bonilla Aragón Intl ALFONSO BONILLA ARAGON Tower SMC121.900
Alfonso Bonilla Aragón Intl CALI Approach119.100

Approach frequencies

ILS-cat-IRW02109.918.00mi
3° GSRW02109.918.00mi
Nearby Points of Interest:
Edificio Coltabaco
-
Palacio Nacional de Cali
-
Edificio Otero
-
St. Peter the Apostle Cathedral, Cali
-
Torre Mudéjar

Runway info

Runway 02 / 20
 length3018m (9902ft)
 bearing10° / 190°
 width45m (148ft)
 surfaceasphalt
 blast zone0m (0ft) / 25m (82ft)

Airport layout


Taxiway locations

 A1  A2  A3  B  C  D  E
Parking locations

 A  B  C  D  G  L  R

Nearby beacons

codeidentifierdistbearingfrequency
CLOCALI VOR/DME8.5188°115.50
ULQTULUA VOR/DME34.217°117.70
BUNBUENAVENTURA VOR/DME40.2295°113.80
AXMARMENIA VOR/DME66.434°111.60

Departure and arrival routes

Transition altitude18000ft
Transition level17000ft
SID end pointsdistanceoutbound heading
RW02
 KIKU4A59mi8°
 ULQ9B34mi17°
 CLO9D, CLO9C21mi284°
 BUN2C40mi295°
 SIGI5C18mi313°
RW20
 KIKU4B59mi8°
 ULQ9C34mi17°
 PPN8B67mi192°
 ISOP4B33mi200°

STAR starting pointsdistanceinbound heading
RW02
 PPN3C67.112°
 ISOP3A32.720°
 ANKA3A71.523°
 DAKO3B, DAKO7A69.151°
 BUN1F40.2115°
 ASIK1C51.6144°
 ULQ6D, ULQ1G, ULQ4E34.2197°
 OREG1C, OREG5A56.7250°
 MANGA917.3267°
 ISAD3A44.1298°
 ESAR1A43.5339°
RW20
 DAKO3C69.151°
 ISKU3A67.563°
 BURP3A66.172°
 BUN4E40.2115°
 ASIK3B51.6144°
 ETAL3A40.4160°
 KIKU3C58.5188°
 ULQ1A, ULQ4F34.2197°
 SIPA3A45.2221°

Instrument approach procedures

runwayairway (heading)route (dist, bearing)
RW02LOMIM (9°)LOMIM 6000ft
RW02MUKIX (9°)MUKIX 9000ft
LOMIM (10mi, 10°) 6000ft
 RNAVLOMIM 6000ft
KOGLO (5mi, 10°) 4800ft
SKCL (6mi, 7°) 3202ft
SIPOG (11mi, 11°) 6400ft
SIPOG (turn) 7000ft
RW20-YOREGA (250°)OREGA 17000ft
CL400 (26mi, 271°) 16000ft
CL401 (11mi, 271°) 13000ft
CL402 (8mi, 271°) 10500ft
CL403 (8mi, 230°) 7500ft
SIPOG (5mi, 190°) 6400ft
 RNAVSIPOG 6400ft
SUNSO (5mi, 190°) 4800ft
SKCL (6mi, 192°) 3212ft
LOMIM (11mi, 189°) 6000ft
LOMIM (turn) 6000ft
RW20-ZMUDRO (191°)MUDRO 8000ft
SIPOG (6mi, 190°) 6400ft
RW20-ZSIPOG (191°)SIPOG 8000ft
 RNAVSIPOG 6400ft
SUNSO (5mi, 190°) 4800ft
CL405 (3mi, 190°) 3800ft
SKCL (3mi, 195°) 3212ft
LOMIM (11mi, 189°) 6000ft
LOMIM (turn) 6000ft

Holding patterns

STAR namehold attypeturnheading*altitudelegspeed limit
ANKA3ALOMIMVHFright196 (16)°> 6000ft1.0min timed200
DAKO3BLOMIMVHFright196 (16)°> 6000ft1.0min timed200
PPN3CLOMIMVHFright196 (16)°> 6000ft1.0min timed200
*) magnetic outbound (inbound) holding course
