Corozal - Las Brujas
Airport details
| Country | Colombia |
| State | Sucre |
| Region | SK |
| Airspace | Barranquilla Ctr |
| Municipality | Corozal |
| Elevation | 495ft (151m) |
| Timezone | GMT -5 |
| Coordinates | 9.33260, -75.28522 |
| Magnetic var | |
| Type | land |
| Available since | X-Plane v10.40 |
| ICAO code | SKCZ |
| IATA code | CZU |
| FAA code | n/a |
Communication
| Las Brujas Las Brujas Tower | 118.400 |
Nearby beacons
| code | identifier | dist | bearing | frequency |
|---|---|---|---|---|
| CZU | COROZAL VOR/DME | 0.2 | 40° | 113.40 |
| MGN | MAGANGUE VOR/DME | 26.1 | 96° | 114.10 |
| MTR | MONTERIA VOR/DME | 44 | 228° | 114.80 |
| CTG | CARTAGENA VOR/DME | 54.1 | 346° | 112.30 |
Departure and arrival routes
| Transition altitude | 18000ft |
| Transition level | 19000ft |
| SID end points | distance | outbound heading | |
|---|---|---|---|
| RW21 | |||
| LOLU1B | 43mi | 28° | |
| NIMV1A, UGAL1B | 104mi | 162° | |
| AKPA1M | 16mi | 308° | |
| STAR starting points | distance | inbound heading | |
|---|---|---|---|
| RW03 | |||
| BUTA1G | 89.4 | 7° | |
| MTR1B | 44.0 | 48° | |
| GEKI1A | 10.5 | 167° | |
| VUKR1A | 10.6 | 197° | |
| XOGE1B | 103.5 | 333° | |
| GERN1B | 105.2 | 346° | |
Instrument approach procedures
| runway | airway (heading) | route (dist, bearing) |
|---|---|---|
| RW03 | CZ934 (355°) | CZ934 5000ft CZ938 (5mi, 290°) 4000ft |
| RW03 | CZ936 (46°) | CZ936 5000ft CZ938 (5mi, 110°) 4000ft |
| RW03 | CZ938 (20°) | CZ938 4000ft |
| RNAV | CZ938 4000ft CZ940 (5mi, 20°) 2450ft SKCZ (6mi, 20°) 541ft CZ932 (10mi, 20°) 4000ft CZ932 (turn) 4000ft |
