Barquisimeto
Airport details
| Country | Venezuela |
| State | Lara State |
| Region | SV |
| Airspace | Maiquetia Ctr |
| Municipality | Parroquia Juan de Villegas |
| Elevation | 2041ft (622m) |
| Timezone | GMT -4 |
| Coordinates | 10.04545, -69.35641 |
| Magnetic var | |
| Type | land |
| Available since | X-Plane v10.35 |
| ICAO code | SVBM |
| IATA code | BRM |
| FAA code | n/a |
Communication
| Barquisimeto ATIS | 132.750 |
| Barquisimeto SMC | 121.900 |
| Barquisimeto Tower | 123.500 |
Approach frequencies
| ILS-cat-I | RW09 | 110.5 | 18.00mi |
| 3.2° GS | RW09 | 110.5 | 18.00mi |
Nearby beacons
| code | identifier | dist | bearing | frequency |
|---|---|---|---|---|
| BRM | BARQUISIMETO VOR/DME | 0.3 | 123° | 112.20 |
| YAR | YARITAGUA NDB | 16.4 | 89° | 260 |
| AGV | ACARIGUA VOR/DME | 30.4 | 166° | 113.40 |
| SPE | SAN FELIPE NDB | 38.4 | 68° | 230 |
| COR | CARORA VOR/DME | 42.7 | 280° | 112.70 |
Departure and arrival routes
| Transition altitude | 11000ft |
| SID end points | distance | outbound heading | |
|---|---|---|---|
| RW09 | |||
| ATEXA1, KOLEG1 | 16mi | 89° | |
| UGOSI1 | 14mi | 347° | |
| RW27 | |||
| ARTOL1, KOLEG1 | 16mi | 89° | |
| KOKRY1 | 23mi | 301° | |
| UGOSI1 | 14mi | 347° | |
Instrument approach procedures
| runway | airway (heading) | route (dist, bearing) |
|---|---|---|
| RW09-Y | COR (101°) | COR 5400ft ENSAM (29mi, 104°) 5400ft DOBRI (5mi, 125°) 5400ft |
| RW09-Y | GELEM (60°) | GELEM 11000ft ANRIS (12mi, 45°) 11000ft DOSGA (14mi, 67°) 5400ft DOBRI (5mi, 37°) 5400ft |
| RW09-Y | RODOL (68°) | RODOL 11000ft ANRIS (12mi, 71°) 11000ft DOSGA (14mi, 67°) 5400ft DOBRI (5mi, 37°) 5400ft |
| RW09-Y | UGOSI (167°) | UGOSI 5400ft ENSAM (17mi, 221°) 5400ft DOBRI (5mi, 125°) 5400ft |
| RW09-Y | VASOT (271°) | VASOT 7400ft EKETU (52mi, 261°) 7400ft DOSGA (5mi, 308°) 5400ft DOBRI (5mi, 37°) 5400ft |
| RNAV | DOBRI 5400ft EGISA (5mi, 81°) 3600ft SVBM (5mi, 80°) 2099ft UGUPU (turn) ENSAM (14mi, 275°) 6400ft ENSAM (turn) | |
| RW09-Z | COR (101°) | COR 5400ft ENSAM (29mi, 104°) 5400ft DOBRI (5mi, 125°) 5400ft |
| RW09-Z | GELEM (60°) | GELEM 11000ft ANRIS (12mi, 45°) 11000ft DOSGA (14mi, 67°) 5400ft DOBRI (5mi, 37°) 5400ft |
| RW09-Z | RODOL (68°) | RODOL 11000ft ANRIS (12mi, 71°) 11000ft DOSGA (14mi, 67°) 5400ft DOBRI (5mi, 37°) 5400ft |
| RW09-Z | UGOSI (167°) | UGOSI 5400ft ENSAM (17mi, 221°) 5400ft DOBRI (5mi, 125°) 5400ft |
| RW09-Z | VASOT (271°) | VASOT 7400ft EKETU (52mi, 261°) 7400ft DOSGA (5mi, 308°) 5400ft DOBRI (5mi, 37°) 5400ft |
| RNAV | DOBRI 5400ft EGISA (5mi, 81°) 3600ft SVBM (5mi, 80°) 2099ft UGUPU (turn) ENSAM (14mi, 275°) 6400ft ENSAM (turn) | |
| RW27-Y | COR (101°) | COR 5800ft ETERA (50mi, 90°) 5800ft ESASA (5mi, 127°) 5800ft IRORA (5mi, 217°) 5000ft |
| RW27-Y | GELEM (60°) | GELEM 11000ft ANRIS (12mi, 45°) 11000ft GAXUL (37mi, 81°) 7400ft UDUSA (5mi, 35°) 5000ft IRORA (5mi, 305°) 5000ft |
| RW27-Y | MULCA (224°) | MULCA ESASA (12mi, 198°) 5800ft IRORA (5mi, 217°) 5000ft |
| RW27-Y | RODOL (68°) | RODOL 11000ft ANRIS (12mi, 71°) 11000ft GAXUL (37mi, 81°) 7400ft UDUSA (5mi, 35°) 5000ft IRORA (5mi, 305°) 5000ft |
| RW27-Y | VASOT (271°) | VASOT 7400ft UDUSA (29mi, 269°) 6800ft IRORA (5mi, 305°) 5000ft |
| RNAV | IRORA 5000ft DIBIX (4mi, 261°) 3600ft SVBM (5mi, 263°) 2070ft IVTIX (turn) ESASA (14mi, 67°) 6800ft ESASA (turn) | |
| RW27-Z | COR (101°) | COR 5800ft ETERA (50mi, 90°) 5800ft ESASA (5mi, 127°) 5800ft IRORA (5mi, 217°) 5000ft |
| RW27-Z | GELEM (60°) | GELEM 11000ft ANRIS (12mi, 45°) 11000ft GAXUL (37mi, 81°) 7400ft UDUSA (5mi, 35°) 5000ft IRORA (5mi, 305°) 5000ft |
| RW27-Z | MULCA (224°) | MULCA ESASA (12mi, 198°) 5800ft IRORA (5mi, 217°) 5000ft |
| RW27-Z | RODOL (68°) | RODOL 11000ft ANRIS (12mi, 71°) 11000ft GAXUL (37mi, 81°) 7400ft UDUSA (5mi, 35°) 5000ft IRORA (5mi, 305°) 5000ft |
| RW27-Z | VASOT (271°) | VASOT 7400ft UDUSA (29mi, 269°) 6800ft IRORA (5mi, 305°) 5000ft |
| RNAV | IRORA 5000ft DIBIX (4mi, 261°) 3600ft SVBM (5mi, 263°) 2070ft IVTIX (turn) ESASA (14mi, 67°) 6800ft ESASA (turn) |
