Country | Russian Federation |
State | Republic of Karelia |
Region | UL |
Airspace | St Petersburg Ctr |
Municipality | Гарнизонное сельское поселение |
Elevation | 148ft (45m) |
Timezone | GMT +3 |
Coordinates | 61.88528, 34.15472 |
Magnetic var | |
Type | land |
Available since | X-Plane v10.40 |
ICAO code | ULPB |
IATA code | PES |
FAA code | n/a |
Petrozavodsk PETROZAVODSK Tower | 128.000 |
ILS-cat-I | RW19 | 110.7 | 18.00mi |
3° GS | RW19 | 110.7 | 18.00mi |
code | identifier | dist | bearing | frequency |
---|---|---|---|---|
PTZ | PETROZAVODSK VOR/DME | 0.2 | 69° | 109.25 |
X | PETROZAVODSK NDB | 1.2 | 222° | 645 |
XO | PETROZAVODSK NDB | 4.2 | 222° | 340 |
Transition altitude | 3104ft |
SID end points | distance | outbound heading | |
---|---|---|---|
RW01 | |||
SOPI2E, SOPI2B, SOPI2A | 40mi | 61° | |
PEME2E, PEME2B, PEME2A | 40mi | 137° | |
BOBM2A, BOBM2B, BOBM2E | 40mi | 250° | |
GITO2A, GITO2E, GITO2B | 40mi | 270° | |
OSNE2A, OSNE2E, OSNE2B | 40mi | 304° | |
RW19 | |||
SOPI2C, SOPI2D, SOPI2F | 40mi | 61° | |
PEME2F, PEME2D, PEME2C | 40mi | 137° | |
BOBM2F, BOBM2D, BOBM2C | 40mi | 250° | |
GITO2F, GITO2D, GITO2C | 40mi | 270° | |
OSNE2F, OSNE2C, OSNE2D | 40mi | 304° |
STAR starting points | distance | inbound heading | |
---|---|---|---|
RW01 | |||
BOBM2G, BOBM2J, BOBM2K | 40.3 | 70° | |
GITO2G, GITO2J, GITO2K | 40.3 | 90° | |
OSNE2K, OSNE2J, OSNE2G | 40.3 | 124° | |
SOPI2K, SOPI2J, SOPI2G | 40.3 | 241° | |
PEME2G | 21.4 | 316° | |
PEME2K, PEME2J | 40.4 | 317° | |
RW19 | |||
BOBM2H, BOBM2J, BOBM2K | 40.3 | 70° | |
GITO2K, GITO2J, GITO2H | 40.3 | 90° | |
OSNE2H, OSNE2J, OSNE2K | 40.3 | 124° | |
SOPI2K, SOPI2J, SOPI2H | 40.3 | 241° | |
PEME2H | 21.4 | 316° | |
PEME2K, PEME2J | 40.4 | 317° |
runway | airway (heading) | route (dist, bearing) |
---|---|---|
RW01 | PB003 (70°) | PB003 3110ft PB002 (6mi, 101°) 2120ft |
RW01 | PB004 (42°) | PB004 3110ft PB002 (6mi, 42°) 2120ft |
RW01 | PB005 (347°) | PB005 3110ft PB002 (6mi, 281°) 2120ft |
RNAV | PB002 2120ft PB001 (5mi, 42°) 1790ft 21THR (3mi, 42°) 880ft ULPB (3mi, 42°) 199ft (4027mi, 209°) 810ft PB006 (4020mi, 29°) PB003 (6mi, 221°) 3110ft | |
RW19 | PB022 (167°) | PB022 3110ft PB021 (6mi, 101°) 2110ft |
RW19 | PB023 (222°) | PB023 3110ft PB021 (6mi, 223°) 2110ft |
RW19 | PB024 (250°) | PB024 3110ft PB021 (6mi, 281°) 2110ft |
RNAV | PB021 2110ft PB020 (5mi, 222°) 1780ft 22THR (3mi, 222°) 860ft ULPB (3mi, 222°) 187ft (4027mi, 209°) 800ft PB025 (4030mi, 29°) PB022 (5mi, 42°) 3110ft |
STAR name | hold at | type | turn | heading* | altitude | leg | speed limit |
---|---|---|---|---|---|---|---|
BOBM2J | PTZ | NDB | left | 194 (14)° | > 2120ft | 1.0min timed | ICAO rules |
BOBM2K | XO | FIX | left | 190 (10)° | > 2120ft | 1.0min timed | ICAO rules |
GITO2J | PTZ | NDB | left | 194 (14)° | > 2120ft | 1.0min timed | ICAO rules |
GITO2K | XO | FIX | left | 190 (10)° | > 2120ft | 1.0min timed | ICAO rules |
OSNE2J | PTZ | NDB | left | 194 (14)° | > 2120ft | 1.0min timed | ICAO rules |
OSNE2K | XO | FIX | left | 190 (10)° | > 2120ft | 1.0min timed | ICAO rules |
PEME2J | PTZ | NDB | left | 194 (14)° | > 2120ft | 1.0min timed | ICAO rules |
PEME2K | XO | FIX | left | 190 (10)° | > 2120ft | 1.0min timed | ICAO rules |
SOPI2J | PTZ | NDB | left | 194 (14)° | > 2120ft | 1.0min timed | ICAO rules |
SOPI2K | XO | FIX | left | 190 (10)° | > 2120ft | 1.0min timed | ICAO rules |
*) magnetic outbound (inbound) holding course |
