Airports for X-Plane

Beloyarsky

Airport details

CountryRussian Federation
StateKhanty-Mansiysk Autonomous Okrug – Ugra
RegionUS
AirspaceTyumen Ctr
MunicipalityBeloyarsky
Elevation78ft (24m)
TimezoneGMT +5
Coordinates63.68806, 66.69972
Magnetic var
Typeland
Available sinceX-Plane v11.51r1
ICAO codeUSHQ
IATA coden/a
FAA coden/a

Communication

Beloyarsky Tower118.100

Approach frequencies

ILS-cat-IRW16110.318.00mi
3° GSRW16110.318.00mi

Runway info

Runway 16 / 34
 length2138m (7014ft)
 bearing185° / 5°
 width44m (144ft)
 surfaceconcrete
 blast zone30m (98ft) / 44m (144ft)

Airport layout


Parking locations

 Ramp

Nearby beacons

codeidentifierdistbearingfrequency
IBELOYARSKIY NDB0.96°387
IUBELOYARSKIY NDB2.35°785

Departure and arrival routes

Transition altitude2703ft
Transition level4000ft
SID end pointsdistanceoutbound heading
RW16
 TOLK1A, TOLK1B, TOLK1E22mi76°
 RUKA1A, RUKA1E, RUKA1B22mi142°
 OKIM1B, OKIM1E, OKIM1A22mi210°
 RAMU1B, RAMU1A, RAMU1E22mi258°
 MALU1A, MALU1B, MALU1E22mi278°
 SULO1E, SULO1B, SULO1A22mi358°
RW34
 TOLK1D, TOLK1F, TOLK1C22mi76°
 RUKA1F, RUKA1D, RUKA1C22mi142°
 OKIM1F, OKIM1D, OKIM1C22mi210°
 RAMU1C, RAMU1D, RAMU1F22mi258°
 MALU1C, MALU1F, MALU1D22mi278°
 SULO1F, SULO1D, SULO1C22mi358°

STAR starting pointsdistanceinbound heading
RW16
 OKIM1J, OKIM1G, OKIM1H21.530°
 RAMU1H, RAMU1G, RAMU1J21.578°
 MALU1J, MALU1H, MALU1G21.598°
 SULO1G, SULO1H, SULO1J21.5178°
 TOLK1J, TOLK1H, TOLK1G21.5256°
 RUKA1J, RUKA1H, RUKA1G21.5322°
RW34
 OKIM1K, OKIM1H, OKIM1G21.530°
 RAMU1G, RAMU1H, RAMU1K21.578°
 MALU1K, MALU1H, MALU1G21.598°
 SULO1K, SULO1H, SULO1G21.5178°
 TOLK1H, TOLK1K21.5256°
 RUKA1K, RUKA1H, RUKA1G21.5322°

Instrument approach procedures

runwayairway (heading)route (dist, bearing)
RW16HQ103 (131°)HQ103 2710ft
HQ102 (6mi, 91°) 2710ft
RW16HQ104 (185°)HQ104
HQ102 (6mi, 185°) 2710ft
RW16HQ105 (235°)HQ105 2710ft
HQ102 (6mi, 271°) 2710ft
 RNAVHQ102 2710ft
HQ101 (5mi, 185°) 1720ft
USHQ (6mi, 185°) 126ft
(4799mi, 226°) 480ft
HQ106 (4797mi, 46°)
HQ107 (13mi, 52°)
HQ105 (4mi, 6°) 2710ft
RW34HQ112 (313°)HQ112 2710ft
HQ111 (6mi, 271°) 2710ft
RW34HQ113 (53°)HQ113 2710ft
HQ111 (6mi, 91°) 2710ft
 RNAVHQ111 2710ft
HQ110 (5mi, 5°) 1720ft
USHQ (6mi, 5°) 121ft
(4799mi, 226°) 470ft
HQ114 (4800mi, 46°)
HQ115 (12mi, 132°)
HQ112 (3mi, 186°) 2710ft

Holding patterns

STAR namehold attypeturnheading*altitudelegspeed limit
MALU1GIUFIXleft341 (161)°1560ft - 6000ft1.0min timedICAO rules
MALU1HIVHFright206 (26)°4900ft - 26600ft1.0min timedICAO rules
OKIM1GIUFIXleft341 (161)°1560ft - 6000ft1.0min timedICAO rules
OKIM1HIVHFright206 (26)°4900ft - 26600ft1.0min timedICAO rules
RAMU1GIUFIXleft341 (161)°1560ft - 6000ft1.0min timedICAO rules
RAMU1HIVHFright206 (26)°4900ft - 26600ft1.0min timedICAO rules
RUKA1GIUFIXleft341 (161)°1560ft - 6000ft1.0min timedICAO rules
RUKA1HIVHFright206 (26)°4900ft - 26600ft1.0min timedICAO rules
RUKA1JHQ105VHFleft342 (162)°5000ft - 6000ft1.0min timedICAO rules
SULO1GIUFIXleft341 (161)°1560ft - 6000ft1.0min timedICAO rules
SULO1HIVHFright206 (26)°4900ft - 26600ft1.0min timedICAO rules
TOLK1GIUFIXleft341 (161)°1560ft - 6000ft1.0min timedICAO rules
TOLK1HIVHFright206 (26)°4900ft - 26600ft1.0min timedICAO rules
TOLK1JHQ105VHFleft342 (162)°5000ft - 6000ft1.0min timedICAO rules
TOLK1KHQ112VHFright162 (342)°5000ft - 6000ft1.0min timedICAO rules
*) magnetic outbound (inbound) holding course
