Country | Russian Federation |
State | Khanty-Mansiysk Autonomous Okrug – Ugra |
Region | US |
Airspace | Yekaterinburg Ctr |
Municipality | Sovetskiy |
Elevation | 351ft (107m) |
Timezone | GMT +5 |
Coordinates | 61.32600, 63.60567 |
Magnetic var | |
Type | land |
Available since | X-Plane v10.40 |
ICAO code | USHS |
IATA code | OVS |
FAA code | n/a |
Sovetskiy ATIS | 122.900 |
Sovetskiy Tower | 120.800 |
code | identifier | dist | bearing | frequency |
---|---|---|---|---|
U | SOVETSKIY NDB | 1.2 | 125° | 530 |
SWT | DME | 2.8 | 123° | 112.90 |
UY | SOVETSKIY NDB | 2.8 | 123° | 10.750 |
Transition altitude | 2648ft |
SID end points | distance | outbound heading | |
---|---|---|---|
RW12 | |||
INSU2L, INSU2C, INSU2A | 27mi | 27° | |
BEDM2L, BEDM2C, BEDM2A | 27mi | 66° | |
LUTE2L, LUTE2C, LUTE2A | 27mi | 86° | |
TIRA2C, TIRA2A, TIRA2L | 27mi | 94° | |
DINR2C, DINR2L, DINR2A | 27mi | 99° | |
OLEM2A, OLEM2L, OLEM2C | 27mi | 133° | |
OBON2A, OBON2C, OBON2L | 27mi | 198° | |
ABIP2C, ABIP2A, ABIP2L | 27mi | 260° | |
NIGO2L, NIGO2C, NIGO2A | 27mi | 273° | |
RW30 | |||
INSU2D, INSU2M, INSU2B | 27mi | 27° | |
BEDM2M, BEDM2D, BEDM2B | 27mi | 66° | |
LUTE2M, LUTE2D, LUTE2B | 27mi | 86° | |
TIRA2M, TIRA2B, TIRA2D | 27mi | 94° | |
DINR2M, DINR2D, DINR2B | 27mi | 99° | |
OLEM2D, OLEM2M, OLEM2B | 27mi | 133° | |
OBON2D, OBON2B, OBON2M | 27mi | 198° | |
ABIP2M, ABIP2B, ABIP2D | 27mi | 260° | |
NIGO2D, NIGO2B, NIGO2M | 27mi | 273° |
STAR starting points | distance | inbound heading | |
---|---|---|---|
ALL | |||
OBON2H, OBON2G | 27.0 | 18° | |
ARKI2G, ARKI2H | 26.9 | 88° | |
NIGO2H, NIGO2G | 26.9 | 93° | |
OLEM2G, OLEM2H | 27.0 | 313° | |
RW12 | |||
OBON2J | 27.0 | 18° | |
ARKI2J | 26.9 | 88° | |
NIGO2J | 26.9 | 93° | |
INSU2J | 26.8 | 207° | |
OLEM2J | 27.0 | 313° | |
RW30 | |||
OBON2K | 27.0 | 18° | |
ARKI2K | 26.9 | 88° | |
NIGO2K | 26.9 | 93° | |
INSU2K | 26.8 | 207° | |
BEDM2K | 26.8 | 246° | |
LUTE2K | 26.8 | 266° | |
TIRA2K | 26.8 | 274° | |
DINR2K | 26.9 | 279° | |
OLEM2K | 27.0 | 313° |
runway | airway (heading) | route (dist, bearing) |
---|---|---|
RW12 | HS003 (154°) | HS003 2320ft HS002 (6mi, 233°) 2320ft |
RW12 | HS004 (104°) | HS004 2320ft HS002 (6mi, 81°) 2320ft |
RNAV | HS002 2320ft HS001 (4mi, 122°) 1990ft USHS (6mi, 121°) 391ft HS006 (4mi, 123°) HS007 (12mi, 277°) 2320ft HS004 (7mi, 321°) 2320ft | |
RW30 | HS011 (333°) | HS011 2310ft HS009 (6mi, 53°) 2310ft |
RW30 | HS012 (285°) | HS012 2310ft HS009 (6mi, 261°) 2310ft |
RW30 | HS013 (302°) | HS013 2310ft HS009 (6mi, 302°) 2310ft |
RNAV | HS009 2310ft HS008 (4mi, 302°) 1980ft USHS (6mi, 303°) 388ft HS014 (4mi, 301°) HS016 (13mi, 176°) 2310ft HS011 (7mi, 109°) 2310ft |
STAR name | hold at | type | turn | heading* | altitude | leg | speed limit |
---|---|---|---|---|---|---|---|
ARKI2G | UY | FIX | right | 303 (123)° | 2160ft - 10000ft | 1.0min timed | 230 |
ARKI2H | U | VHF | right | 33 (213)° | 1.0min timed | ICAO rules | |
ARKI2J | HS004 | VHF | right | 233 (53)° | 1820ft - 10000ft | 1.0min timed | 230 |
ARKI2K | HS011 | VHF | right | 193 (13)° | 1660ft - 10000ft | 1.0min timed | 230 |
BEDM2G | UY | FIX | right | 303 (123)° | 2160ft - 10000ft | 1.0min timed | 230 |
BEDM2H | U | VHF | right | 33 (213)° | 1.0min timed | ICAO rules | |
DINR2G | UY | FIX | right | 303 (123)° | 2160ft - 10000ft | 1.0min timed | 230 |
DINR2H | U | VHF | right | 33 (213)° | 1.0min timed | ICAO rules | |
INSU2G | UY | FIX | right | 303 (123)° | 2160ft - 10000ft | 1.0min timed | 230 |
INSU2H | U | VHF | right | 33 (213)° | 1.0min timed | ICAO rules | |
LUTE2G | UY | FIX | right | 303 (123)° | 2160ft - 10000ft | 1.0min timed | 230 |
LUTE2H | U | VHF | right | 33 (213)° | 1.0min timed | ICAO rules | |
NIGO2G | UY | FIX | right | 303 (123)° | 2160ft - 10000ft | 1.0min timed | 230 |
NIGO2H | U | VHF | right | 33 (213)° | 1.0min timed | ICAO rules | |
NIGO2J | HS004 | VHF | right | 233 (53)° | 1820ft - 10000ft | 1.0min timed | 230 |
NIGO2K | HS011 | VHF | right | 193 (13)° | 1660ft - 10000ft | 1.0min timed | 230 |
OBON2G | UY | FIX | right | 303 (123)° | 2160ft - 10000ft | 1.0min timed | 230 |
OBON2H | U | VHF | right | 33 (213)° | 1.0min timed | ICAO rules | |
OBON2J | HS004 | VHF | right | 233 (53)° | 1820ft - 10000ft | 1.0min timed | 230 |
OBON2K | HS011 | VHF | right | 193 (13)° | 1660ft - 10000ft | 1.0min timed | 230 |
OLEM2G | UY | FIX | right | 303 (123)° | 2160ft - 10000ft | 1.0min timed | 230 |
OLEM2H | U | VHF | right | 33 (213)° | 1.0min timed | ICAO rules | |
OLEM2J | HS004 | VHF | right | 233 (53)° | 1820ft - 10000ft | 1.0min timed | 230 |
TIRA2G | UY | FIX | right | 303 (123)° | 2160ft - 10000ft | 1.0min timed | 230 |
TIRA2H | U | VHF | right | 33 (213)° | 1.0min timed | ICAO rules | |
*) magnetic outbound (inbound) holding course |
