Airports for X-Plane

Verkuta - Vorkuta

Airport details

CountryRussian Federation
StateKomi Republic
RegionUU
AirspaceSyktyvkar Ctr
MunicipalityVorkuta
Elevation603ft (184m)
TimezoneGMT +3
Coordinates67.48889, 63.99306
Magnetic var
Typeland
Available sinceX-Plane v10.40
ICAO codeUUYW
IATA codeVKT
FAA coden/a

Communication

Vorkuta Tower120.600

Approach frequencies

ILS-cat-IRW08109.518.00mi
3° GSRW08109.518.00mi

Runway info

Runway 08 / 26
 length2196m (7205ft)
 bearing95° / 275°
 width50m (164ft)
 surfaceasphalt
 displ threshold0m (0ft) / 300m (984ft)
 blast zone50m (164ft) / 0m (0ft)

Airport layout


Taxiway locations

 A  B
Parking locations

 Stand

Nearby beacons

codeidentifierdistbearingfrequency
KVORKUTA NDB0.895°315
DVORKUTA NDB1.3275°315
KZVORKUTA NDB2.794°522
DWVORKUTA NDB3275°522

Departure and arrival routes

Transition altitude2900ft
SID end pointsdistanceoutbound heading
RW08
 TINU1E, TINU1A43mi27°
 LUSI1E, LUSI1A43mi83°
 GUBA1A, GUBA1E44mi109°
 ABOS1E, ABOS1A48mi160°
 ABNO1E, ABNO1A43mi253°
 BAPA1A, BAPA1E43mi259°
 ADIB1A, ADIB1E43mi272°
RW26
 TINU1C, TINU1F43mi27°
 LUSI1F, LUSI1C43mi83°
 GUBA1F, GUBA1C44mi109°
 ABOS1F, ABOS1C48mi160°
 ABNO1F, ABNO1C43mi253°
 BAPA1C, BAPA1F43mi259°
 ADIB1C, ADIB1F43mi272°

STAR starting pointsdistanceinbound heading
RW08
 ABNO1B, ABNO1G, ABNO1H43.073°
 BAPA1G, BAPA1B, BAPA1H43.079°
 ADIB1G, ADIB1H, ADIB1B43.092°
 TINU1B, TINU1G, TINU1H43.0207°
 LUSI1H, LUSI1G, LUSI1B43.0263°
 GUBA1B, GUBA1H, GUBA1G44.1289°
 ABOS1H, ABOS1G, ABOS1B47.7340°
RW26
 ABNO1K, ABNO1J, ABNO1D43.073°
 BAPA1K, BAPA1J, BAPA1D43.079°
 ADIB1D, ADIB1J, ADIB1K43.092°
 TINU1D, TINU1J, TINU1K43.0207°
 LUSI1K, LUSI1J, LUSI1D43.0263°
 GUBA1K, GUBA1J, GUBA1D44.1289°
 ABOS1D, ABOS1J, ABOS1K47.7340°

Instrument approach procedures

runwayairway (heading)route (dist, bearing)
RW08YW001 (87°)YW001
YW004 (6mi, 58°) 2520ft
RW08YW002 (95°)YW002
YW004 (6mi, 95°) 2520ft
RW08YW003 (103°)YW003
YW004 (6mi, 160°) 2520ft
 RNAVYW004 2520ft
YW005 (8mi, 95°) 2190ft
UUYW (6mi, 95°) 593ft
YW006 (2mi, 95°)
YW007 (10mi, 261°)
YW001 (10mi, 275°) 2520ft
RW26YW008 (262°)YW008
YW011 (6mi, 209°) 2570ft
RW26YW009 (275°)YW009
YW011 (6mi, 275°) 2570ft
RW26YW010 (291°)YW010
YW011 (6mi, 28°) 2570ft
 RNAVYW011 2570ft
YW012 (5mi, 275°) 2240ft
UUYW (4mi, 275°) 647ft
YW013 (4mi, 275°)
YW014 (10mi, 114°)
YW010 (5mi, 95°) 2570ft

Holding patterns

STAR namehold attypeturnheading*altitudelegspeed limit
ABNO1BYW001VHFleft163 (343)°1860ft - 11000ft1.0min timed185
ABNO1DYW010VHFright167 (347)°2900ft - 11000ft1.0min timed185
ABNO1GDWFIXright257 (77)°> 2190ft1.0min timedICAO rules
ABNO1HDFIXright191 (11)°1.0min timed240
ABNO1JKZFIXleft77 (257)°> 4540ft1.0min timedICAO rules
ABNO1KKFIXright189 (9)°> 1470ft1.0min timedICAO rules
ABOS1BYW001VHFleft163 (343)°1860ft - 11000ft1.0min timed185
ABOS1DYW010VHFright167 (347)°2900ft - 11000ft1.0min timed185
ABOS1GDWFIXright257 (77)°> 2190ft1.0min timedICAO rules
ABOS1HDFIXright191 (11)°1.0min timed240
ABOS1JKZFIXleft77 (257)°> 4540ft1.0min timedICAO rules
ABOS1KKFIXright189 (9)°> 1470ft1.0min timedICAO rules
ADIB1DYW010VHFright167 (347)°2900ft - 11000ft1.0min timed185
ADIB1GDWFIXright257 (77)°> 2190ft1.0min timedICAO rules
ADIB1HDFIXright191 (11)°1.0min timed240
ADIB1JKZFIXleft77 (257)°> 4540ft1.0min timedICAO rules
ADIB1KKFIXright189 (9)°> 1470ft1.0min timedICAO rules
BAPA1BYW001VHFleft163 (343)°1860ft - 11000ft1.0min timed185
BAPA1DYW010VHFright167 (347)°2900ft - 11000ft1.0min timed185
BAPA1GDWFIXright257 (77)°> 2190ft1.0min timedICAO rules
BAPA1HDFIXright191 (11)°1.0min timed240
BAPA1JKZFIXleft77 (257)°> 4540ft1.0min timedICAO rules
BAPA1KKFIXright189 (9)°> 1470ft1.0min timedICAO rules
GUBA1GDWFIXright257 (77)°> 2190ft1.0min timedICAO rules
GUBA1HDFIXright191 (11)°1.0min timed240
GUBA1JKZFIXleft77 (257)°> 4540ft1.0min timedICAO rules
GUBA1KKFIXright189 (9)°> 1470ft1.0min timedICAO rules
LUSI1GDWFIXright257 (77)°> 2190ft1.0min timedICAO rules
LUSI1HDFIXright191 (11)°1.0min timed240
LUSI1JKZFIXleft77 (257)°> 4540ft1.0min timedICAO rules
LUSI1KKFIXright189 (9)°> 1470ft1.0min timedICAO rules
TINU1GDWFIXright257 (77)°> 2190ft1.0min timedICAO rules
TINU1HDFIXright191 (11)°1.0min timed240
TINU1JKZFIXleft77 (257)°> 4540ft1.0min timedICAO rules
TINU1KKFIXright189 (9)°> 1470ft1.0min timedICAO rules
*) magnetic outbound (inbound) holding course
