Airports for X-Plane

Nakhon Phanom

Airport details

CountryThailand
StateNakhon Phanom Province
RegionVT
AirspaceBangkok Ctr
MunicipalityNong Yat
Elevation585ft (178m)
TimezoneGMT +7
Coordinates17.38534, 104.64189
Magnetic var
Typeland
Available sinceX-Plane v10.40
ICAO codeVTUW
IATA codeKOP
FAA coden/a

Communication

Nakhon Phanom Tower122.500
Nakhon Phanom SAKHON NAKHON Approach123.350

Approach frequencies

ILS-cat-IRW15109.718.00mi
3° GSRW15109.718.00mi
Nearby Points of Interest:
Wat Phra That Renu
-
Wat Phra That Dum
-
Wat Phra That Prasit

Runway info

Runway 15 / 33
 length2512m (8241ft)
 bearing144° / 324°
 width45m (148ft)
 surfaceasphalt
 blast zone60m (197ft) / 60m (197ft)

Airport layout


Taxiway locations

 A1  A2  A3
Parking locations

 G1  G2  M1  M2

Nearby beacons

codeidentifierdistbearingfrequency
NKPNAKHON PHANOM VOR/DME0.2310°111.60
NPNAKHON PHANOM NDB0.46°383
SKNSAKON NAKHON VOR/DME30.7251°114.20
SNSAKON NAKHON NDB32.2250°365
SAVSAVANNAKHET VOR/DME49.9171°113.50

Instrument approach procedures

runwayairway (heading)route (dist, bearing)
RW15OPAAR (72°)OPAAR 3000ft
XASSY (8mi, 359°) 3000ft
YACOB (7mi, 56°) 2500ft
 RNAVYACOB 2500ft
UW152 (5mi, 144°) 2000ft
UW151 (4mi, 144°) 637ft
(6243mi, 261°) 2400ft
OPAAR (6232mi, 81°) 3000ft
OPAAR (turn) 3000ft
RW33OPAAR (72°)OPAAR 3000ft
XICLE (14mi, 124°) 3000ft
PRITY (7mi, 56°) 2500ft
 RNAVPRITY 2500ft
UW332 (5mi, 324°) 2000ft
UW331 (4mi, 324°) 605ft
(6244mi, 261°) 2400ft
OPAAR (6232mi, 81°) 3000ft
OPAAR (turn) 3000ft
