Airports for X-Plane

Lightning Ridge

Airport details

CountryAustralia
StateNew South Wales
RegionYB
AirspaceBrisbane Ctr
MunicipalityLightning Ridge
Elevation540ft (165m)
TimezoneGMT +10
Coordinates-29.45667, 147.98500
Magnetic var
Typeland
Available sinceX-Plane v10.40
ICAO codeYLRD
IATA codeLHG
FAA coden/a

Communication

Lightning Ridge CTAF126.700

Runway info

Runway 10 / 28
 length1506m (4941ft)
 bearing107° / 287°
 width18m (59ft)
 surfaceasphalt
Runway 04 / 22
 length734m (2408ft)
 bearing51° / 231°
 width30m (98ft)
 surfacedirt

Airport layout - runway 04 / 22


Parking locations

 GA  RPT

Nearby beacons

codeidentifierdistbearingfrequency
WLGWALGETT NDB35166°374

Instrument approach procedures

runwayairway (heading)route (dist, bearing)
RW28LR2EA (267°)LR2EA 2200ft
LR2EI (5mi, 223°) 2200ft
RW28LR2EB (287°)LR2EB 2200ft
LR2EI (5mi, 287°) 2200ft
RW28LR2EC (307°)LR2EC 2200ft
LR2EI (5mi, 359°) 2200ft
 RNAVLR2EI 2200ft
LR2EF (5mi, 287°) 2180ft
YLRD (5mi, 286°) 587ft
LR2EH (3mi, 289°)
(8262mi, 281°) 1900ft
RWNVWLR2WD (127°)LR2WD 2200ft
LR2WI (5mi, 179°) 2200ft
RWNVWLR2WE (107°)LR2WE 2200ft
LR2WI (5mi, 107°) 2200ft
RWNVWLR2WG (89°)LR2WG 2200ft
LR2WI (5mi, 43°) 2200ft
 RNAVLR2WI 2200ft
LR2WF (5mi, 107°) 2160ft
YLRD (6mi, 108°) 568ft
LR2WH (2mi, 105°)
(8264mi, 281°) 1900ft
