Country | China |
State | Zhejiang |
Region | |
Airspace | Shanghai Ctr |
Municipality | Zhoushan |
Elevation | 4ft (1m) |
Timezone | GMT +8 |
Coordinates | 29.94668, 122.36217 |
Magnetic var | |
Type | land |
Available since | X-Plane v10.40 |
ICAO code | ZSZS |
IATA code | HSN |
FAA code | n/a |
Zhoushan Putuoshan Zhoushan Tower | 118.050 |
ILS-cat-I | RW18 | 108.75 | 18.00mi |
ILS-cat-I | RW36 | 110.5 | 18.00mi |
3° GS | RW18 | 108.75 | 18.00mi |
3° GS | RW36 | 110.5 | 18.00mi |
code | identifier | dist | bearing | frequency |
---|---|---|---|---|
L | PUTUOSHAN (ZHOUSHAN) NDB | 0 | 354° | 228 |
HSN | ZHOUSHAN VOR/DME | 0.9 | 176° | 112.30 |
LA | PUTUOSHAN NDB | 4.1 | 36° | 363 |
NGB | NINGBO VOR/DME | 47.3 | 263° | 116.30 |
XSY | SHUYUAN VOR/DME | 64.3 | 334° | 112.70 |
SID end points | distance | outbound heading | |
---|---|---|---|
RW18 | |||
PON12D, PON62X | 39mi | 3° | |
BK12D, BK62X | 54mi | 267° | |
RW36 | |||
PON11D, PON61X | 39mi | 3° | |
BK13D, BK61X, BK63X, BK11D | 54mi | 267° |
STAR starting points | distance | inbound heading | |
---|---|---|---|
RW18 | |||
BK02A, BK04A, BK52F, BK54F | 53.5 | 87° | |
PON52F, PON02A | 38.5 | 183° | |
RW36 | |||
BK01A, BK51F, BK53F | 53.5 | 87° | |
PON51F, PON03A, PON01A | 38.5 | 183° |
STAR name | hold at | type | turn | heading* | altitude | leg | speed limit |
---|---|---|---|---|---|---|---|
BK01A | HSN | NDB | right | 343 (163)° | > 4930ft | 1.0min timed | 215 |
BK02A | HSN | NDB | right | 343 (163)° | > 4930ft | 1.0min timed | 215 |
BK04A | HSN | NDB | right | 343 (163)° | > 4930ft | 1.0min timed | 215 |
BK51F | ZS206 | VHF | right | 179 (359)° | > 4930ft | 1.0min timed | 215 |
BK52F | ZS206 | VHF | right | 179 (359)° | > 4930ft | 1.0min timed | 215 |
PON01A | HSN | NDB | right | 343 (163)° | > 4930ft | 1.0min timed | 215 |
PON51F | ZS206 | VHF | right | 179 (359)° | > 4930ft | 1.0min timed | 215 |
*) magnetic outbound (inbound) holding course |
