Country | China |
State | Heilongjiang |
Region | ZY |
Airspace | Shenyang Ctr |
Municipality | Daoli District |
Elevation | 457ft (139m) |
Timezone | GMT +8 |
Coordinates | 45.62500, 126.25166 |
Magnetic var | |
Type | land |
Available since | X-Plane v10.40 |
ICAO code | ZYHB |
IATA code | HRB |
FAA code | n/a |
Taiping ATIS | 127.400 |
Taiping HARBIN Tower | 118.700 |
Taiping HARBIN Tower | 118.100 |
ILS-cat-I | RW05 | 110.3 | 18.00mi |
ILS-cat-I | RW23 | 109.9 | 18.00mi |
3° GS | RW05 | 110.3 | 18.00mi |
3° GS | RW23 | 109.9 | 18.00mi |
code | identifier | dist | bearing | frequency |
---|---|---|---|---|
HRB | HARBIN VOR/DME | 0.3 | 79° | 112.50 |
M | HARBIN NDB | 1.2 | 50° | 202 |
L | HARBIN NDB | 1.5 | 229° | 220 |
MJ | HARBIN NDB | 4.4 | 49° | 417 |
LS | SHUIQUAN NDB | 13.6 | 230° | 445 |
Transition altitude | 9842ft |
Transition level | 11811ft |
SID end points | distance | outbound heading | |
---|---|---|---|
RW05 | |||
BUB01D, BUB08D, BUB09D | 53mi | 13° | |
IGA09D, IGA08D, IGA01D | 53mi | 74° | |
KET01D, KET08D, KET09D | 53mi | 123° | |
DUK09D, DUK01D | 67mi | 198° | |
LUV01D, LUV09D | 102mi | 246° | |
ONI09D, ONI08D, ONI01D | 54mi | 305° | |
RW23 | |||
BUB11D, BUB18D, BUB19D | 53mi | 13° | |
IGA19D, IGA18D, IGA11D | 53mi | 74° | |
KET11D, KET18D, KET19D | 53mi | 123° | |
DUK19D, DUK11D | 67mi | 198° | |
IGP11D, IGP19D | 102mi | 241° | |
ONI11D, ONI19D | 54mi | 305° |
STAR starting points | distance | inbound heading | |
---|---|---|---|
RW05 | |||
LAR09A, LAR02A, LAR01A | 61.2 | 6° | |
IGP09A, IGP01A, IGP02A | 72.0 | 60° | |
ONI01A, ONI09A | 54.4 | 125° | |
BUB01A, BUB08A, BUB09A | 53.1 | 193° | |
IGA09A, IGA08A, IGA01A | 52.6 | 254° | |
KET01A, KET09A, KET08A | 52.9 | 303° | |
RW23 | |||
LAR19A, LAR18A, LAR11A | 61.2 | 6° | |
LUV19A, LUV11A | 70.7 | 67° | |
ONI18A, ONI19A, ONI11A | 54.4 | 125° | |
BUB19A, BUB18A, BUB11A | 53.1 | 193° | |
IGA19A, IGA18A, IGA11A | 52.6 | 254° | |
KET18A, KET19A, KET11A | 52.9 | 303° |
STAR name | hold at | type | turn | heading* | altitude | leg | speed limit |
---|---|---|---|---|---|---|---|
BUB01A | HRB | NDB | right | 49 (229)° | > 3940ft | 1.0min timed | ICAO rules |
BUB09A | MIBAG | VHF | right | 355 (175)° | 1.0min timed | 250 | |
BUB11A | HRB | NDB | right | 49 (229)° | > 3940ft | 1.0min timed | ICAO rules |
BUB19A | MIBAG | VHF | right | 355 (175)° | 1.0min timed | 250 | |
IGA01A | HRB | NDB | right | 49 (229)° | > 3940ft | 1.0min timed | ICAO rules |
IGA08A | HB402 | VHF | left | 78 (258)° | 1.0min timed | 250 | |
IGA09A | HB402 | VHF | left | 78 (258)° | 1.0min timed | 250 | |
IGA11A | HRB | NDB | right | 49 (229)° | > 3940ft | 1.0min timed | ICAO rules |
IGA19A | HB402 | VHF | left | 78 (258)° | 1.0min timed | 250 | |
IGP01A | HRB44 | VHF | left | 244 (64)° | > 12800ft | 1.0min timed | ICAO rules |
IGP02A | HRB | NDB | right | 49 (229)° | > 3940ft | 1.0min timed | ICAO rules |
IGP02A | HRB44 | VHF | left | 244 (64)° | > 12800ft | 1.0min timed | ICAO rules |
IGP09A | HB510 | VHF | left | 245 (65)° | > 12800ft | 1.0min timed | 250 |
KET01A | HRB | NDB | right | 49 (229)° | > 3940ft | 1.0min timed | ICAO rules |
KET08A | HB401 | VHF | left | 143 (323)° | 1.0min timed | 250 | |
KET09A | HB401 | VHF | left | 143 (323)° | 1.0min timed | 250 | |
KET11A | HRB | NDB | right | 49 (229)° | > 3940ft | 1.0min timed | ICAO rules |
KET18A | HB401 | VHF | left | 143 (323)° | 1.0min timed | 250 | |
KET19A | HB401 | VHF | left | 143 (323)° | 1.0min timed | 250 | |
LAR01A | HRB30 | VHF | left | 183 (3)° | > 9850ft | 1.0min timed | ICAO rules |
LAR02A | HRB | NDB | right | 49 (229)° | > 3940ft | 1.0min timed | ICAO rules |
LAR02A | HRB30 | VHF | left | 183 (3)° | > 9850ft | 1.0min timed | ICAO rules |
LAR09A | UPKED | VHF | left | 170 (350)° | > 9850ft | 1.0min timed | 250 |
LAR11A | HRB | NDB | right | 49 (229)° | > 3940ft | 1.0min timed | ICAO rules |
LAR18A | UPKED | VHF | left | 170 (350)° | > 9850ft | 1.0min timed | 250 |
LAR19A | UPKED | VHF | left | 170 (350)° | > 9850ft | 1.0min timed | 250 |
LUV11A | HRB | NDB | right | 49 (229)° | > 3940ft | 1.0min timed | ICAO rules |
LUV19A | HB405 | VHF | left | 245 (65)° | 1.0min timed | 250 | |
ONI01A | HRB | NDB | right | 49 (229)° | > 3940ft | 1.0min timed | ICAO rules |
ONI09A | MIBAG | VHF | right | 355 (175)° | 1.0min timed | 250 | |
ONI11A | HRB | NDB | right | 49 (229)° | > 3940ft | 1.0min timed | ICAO rules |
ONI19A | MIBAG | VHF | right | 355 (175)° | 1.0min timed | 250 | |
*) magnetic outbound (inbound) holding course |
The information on this website is not for real aviation. Use this data with the X-Plane flight simulator only! Data taken with kind consent from X-Plane 12 source code and data files. Content is subject to change without notice.
