Airports for X-Plane

Hainesville - Campbell

Airport details

CountryUnited States of America
StateIllinois
RegionK5
AirspaceChicago Ctr
MunicipalityLake County
Elevation788ft (240m)
TimezoneGMT -6
Coordinates42.32461, -88.07409
Magnetic var
Typeland
Available sinceX-Plane v10.40
ICAO codeC81
IATA coden/a
FAA coden/a

Communication

CAMPBELL CTAF/UNICOM122.700

Runway info

Runway 07 / 25
 length303m (994ft)
 bearing65° / 245°
 width30m (97ft)
 surfacehard surface
Runway 6 / 24
 length760m (2493ft)
 bearing65° / 245°
 width12m (40ft)
 surfaceasphalt
 displ threshold0m (0ft) / 91m (299ft)
Runway 9 / 27
 length994m (3261ft)
 bearing90° / 270°
 width12m (40ft)
 surfaceasphalt

Airport layout - parking location Tie


Parking locations

 Tie

Nearby beacons

codeidentifierdistbearingfrequency
OBKNORTHBROOK VOR/DME8.2130°113
UGWAUKE (CHICAGO/WAUKEGAN) NDB14.763°379
ENWDME17.627°109.20
GCODME21.2153°108.25
RAPASER (RACINE) NDB22.826°206
BUU(BURLINGTON) DME24.1328°114.50
HRK(RACINE) DME28.631°117.70
DPADUPAGE (CHICAGO) VOR/DME28.8212°108.40
MXKEDZI (CHICAGO) NDB38.9147°248
LJT(MILWAUKEE) DME47.13°115.65
JOTJOLIET VOR/DME47.9197°112.30
BAEBADGER (MILWAUKEE) VOR/DME48.4345°116.40
CGTCHICAGO HEIGHTS VORTAC53.8148°114.20
GYGARIE (GARY) NDB56.1135°236
RYVROCK RIVER (WATERTOWN) NDB58.5323°371

Instrument approach procedures

runwayairway (heading)route (dist, bearing)
RWNVBOBK (310°)OBK
EDAKE (17mi, 299°) 2500ft
EDAKE (turn) 2500ft
RWNVBSEJLE (88°)SEJLE
EDAKE (5mi, 33°) 2500ft
RWNVBWIPED (171°)WIPED
DIBSE (16mi, 195°) 2500ft
EDAKE (5mi, 213°) 2500ft
 RNAVEDAKE 2500ft
CIDAR (6mi, 109°) 2500ft
DUMRE (3mi, 110°) 1400ft
(5320mi, 116°) 2000ft
EDAKE (5328mi, 296°) 2500ft
EDAKE (turn)
