Airports for X-Plane

Hamilton - John C Munro Hamilton Intl

Airport details

CountryCanada
StateOntario
RegionCY
AirspaceToronto Ctr
MunicipalityHamilton
Elevation777ft (237m)
TimezoneGMT -5
Coordinates43.16399, -79.93458
Magnetic var
Typeland
Available sinceX-Plane v10.40
ICAO codeCYHM
IATA codeYHM
FAA codeYHM

Communication

John C Munro Hamilton Intl ATIS128.100
John C Munro Hamilton Intl Ground Control121.600
John C Munro Hamilton Intl Tower125.000
John C Munro Hamilton Intl Toronto Terminal Approach119.700
John C Munro Hamilton Intl Toronto Terminal Departure119.700

Approach frequencies

LOCRW30110.918.00mi
ILS-cat-IIRW12110.918.00mi
3° GSRW12110.918.00mi

Runway info

Runway 12 / 30
 length3053m (10016ft)
 bearing103° / 283°
 width61m (200ft)
 surfaceasphalt
 displ threshold500m (1640ft) / 0m (0ft)
 blast zone40m (131ft) / 45m (148ft)
Runway 06 / 24
 length1833m (6014ft)
 bearing57° / 237°
 width46m (150ft)
 surfaceasphalt

Airport layout - taxiway location G


Taxiway locations

 B  C  D  G  J  L  W
Parking locations

 Apron  Cargo  DHL  Gate  Jetport  Kelowna  Purolator

Nearby beacons

codeidentifierdistbearingfrequency
HMHAMILTON NDB4239°221
ZHAANCASTER (HAMILTON) NDB4.5290°397
ZHMBINBROOK (HAMILTON) NDB6.398°266
FDBRANTFORD NDB21.8259°207
ZKFWELLINGTON (KITCHENER) NDB25313°335
WT(KITCHENER) DME26.2304°115
SNST CATHARINES NDB29.791°408
ZYZQUEENSWAY (TORONTO) NDB32.140°368
YYZTORONTO VOR/DME32.432°112.15
YTPPEARSON (TORONTO) VOR/DME32.628°116.55
ZTOWOODHILL (TORONTO) NDB35.922°403
TZGIBRALTAR POINT NDB3651°257
IAGNIAGARA FALLS TACAN42.893°111
DKKDME49.8136°116.20
KZBUTTONVILLE NDB53.138°248
YMSMANS (MANSFIELD) VOR/DME59.5348°114.50
JHWJAMESTOWN VOR/DME68.7140°114.70

Departure and arrival routes

Transition altitude18000ft
Transition level18000ft
SID end pointsdistanceoutbound heading
RW06
 CYHM931mi111°
RW12
 CYHM931mi111°
RW24
 CYHM931mi111°
RW30
 MUNR231mi111°

STAR starting pointsdistanceinbound heading
RW06
 TIKUM214.24°
 AVSOX230.382°
 UDMIK332.4212°
 COLTS729.4288°
RW12
 TIKUM214.24°
 AVSOX230.382°
 UDMIK332.4212°
 COLTS729.4288°
RW24
 TIKUM214.24°
 AVSOX230.382°
 UDMIK332.4212°
 COLTS729.4288°
RW30
 TIKUM214.24°
 AVSOX230.382°
 UDMIK332.4212°
 COLTS729.4288°

Instrument approach procedures

runwayairway (heading)route (dist, bearing)
RW06-ZIGTUT (29°)IGTUT
DAXAT (5mi, 310°) 2300ft
RW06-ZLEVEX (80°)LEVEX
DAXAT (5mi, 130°) 2300ft
 RNAVDAXAT 2300ft
VIBKA (6mi, 57°) 2200ft
CYHM (4mi, 59°) 821ft
MUXIG (11mi, 57°) 3100ft
MUXIG (turn)
RW12-ZPUSAM (87°)PUSAM
LOGLI (5mi, 23°) 2200ft
RW12-ZREXUG (126°)REXUG
LOGLI (5mi, 203°) 2200ft
 RNAVLOGLI 2200ft
IGTIG (6mi, 103°) 2200ft
CYHM (5mi, 109°) 826ft
NORAG (4mi, 96°) 2800ft
NORAG (turn)
RW24-ZNOPOP (257°)NOPOP
MUXIG (5mi, 310°) 2500ft
RW24-ZUDMIK (211°)UDMIK
MUXIG (5mi, 130°) 2500ft
 RNAVMUXIG 2500ft
KEDIS (6mi, 237°) 2200ft
CYHM (5mi, 236°) 806ft
IKLOP (11mi, 238°) 3100ft
IKLOP (turn)
RW30-ZKEDBU (302°)KEDBU
DELVA (5mi, 23°) 2200ft
RW30-ZOTROX (261°)OTROX
DELVA (5mi, 203°) 2200ft
 RNAVDELVA 2200ft
GOPEB (5mi, 283°) 2200ft
CYHM (5mi, 277°) 816ft
EBKEM (9mi, 286°) 2300ft
EBKEM (turn) 2300ft
