Airports for X-Plane

Stephenville

Airport details

CountryCanada
StateNewfoundland and Labrador
RegionCY
AirspaceGander Oceanic Ctr
MunicipalityStephenville
Elevation80ft (24m)
TimezoneGMT -3.5
Coordinates48.54145, -58.54991
Magnetic var
Typeland
Available sinceX-Plane v10.40
ICAO codeCYJT
IATA codeYJT
FAA coden/a

Communication

Stephenville ATC122.100

Approach frequencies

ILS-cat-IRW27109.518.00mi
3° GSRW27109.518.00mi

Runway info

Runway 09 / 27
 length3044m (9987ft)
 bearing77° / 257°
 width61m (200ft)
 surfaceasphalt
 blast zone255m (837ft) / 0m (0ft)

Airport layout - parking location Cargo


Taxiway locations

 A  B
Parking locations

 Cargo  GA  Helo  Mil  Ramp

Nearby beacons

codeidentifierdistbearingfrequency
YJTSTEPHENVILLE VOR/DME5.3289°113.10
ZJTHARMON (STEPHENVILLE) NDB7.177°340

Instrument approach procedures

runwayairway (heading)route (dist, bearing)
RW09ITPUS (58°)ITPUS
EMBOL (5mi, 333°) 1900ft
RW09UKNUL (94°)UKNUL
EMBOL (5mi, 153°) 1900ft
 RNAVEMBOL 1900ft
OBNAS (6mi, 77°) 1400ft
CYJT (5mi, 79°) 62ft
(4191mi, 130°) 700ft
ITPUS (4196mi, 309°) 3100ft
ITPUS (turn)
RW27EBDAX (270°)EBDAX
MEGVU (5mi, 333°) 2900ft
RW27SATIV (242°)SATIV
MEGVU (5mi, 153°) 2900ft
 RNAVMEGVU 2900ft
VEVRI (7mi, 257°) 2200ft
CYJT (7mi, 256°) 135ft
PEKLI (4mi, 259°) 3000ft
PEKLI (turn)
