Airports for X-Plane

Meadow Lake

Airport details

CountryCanada
StateSaskatchewan
RegionCY
AirspaceWinnipeg Ctr
MunicipalityMeadow Lake No. 588
Elevation1576ft (480m)
TimezoneGMT -6
Coordinates54.12539, -108.52290
Magnetic var
Typeland
Available sinceX-Plane v10.40
ICAO codeCYLJ
IATA codeYLJ
FAA coden/a

Communication

Meadow Lake CTAF122.800
Meadow Lake COLD LAKE TRML124.500

Runway info

Runway 09 / 27
 length1525m (5003ft)
 bearing96° / 276°
 width30m (98ft)
 surfaceasphalt
Runway 17 / 35
 length699m (2293ft)
 bearing180° / 0°
 width23m (75ft)
 surfaceasphalt

Airport layout - taxiway location 27


Taxiway locations

 17  27  9
Parking locations

 New

Instrument approach procedures

runwayairway (heading)route (dist, bearing)
RW09KIVOP (112°)KIVOP
IGTAT (5mi, 197°) 3000ft
RW09XUMDI (81°)XUMDI
IGTAT (5mi, 16°) 3000ft
 RNAVIGTAT 3000ft
VINPO (6mi, 96°) 3000ft
CYLJ (5mi, 95°) 1627ft
MEBER (5mi, 97°) 3900ft
MEBER (turn)
RW17IKMIB (143°)IKMIB
IRLUX (5mi, 90°) 3000ft
RW17ITPUP (221°)ITPUP
IRLUX (5mi, 270°) 3000ft
 RNAVIRLUX 3000ft
OLOBO (6mi, 180°) 3000ft
CYLJ (5mi, 187°) 1628ft
MIXIX (5mi, 174°) 3900ft
MIXIX (turn)
RW27DUVSI (293°)DUVSI
GUBAN (5mi, 17°) 3000ft
RW27ROPVI (261°)ROPVI
GUBAN (5mi, 197°) 3000ft
 RNAVGUBAN 3000ft
VOLIG (6mi, 276°) 2900ft
CYLJ (4mi, 277°) 1619ft
ITSAM (5mi, 275°) 3900ft
ITSAM (turn)
RW35PUTUT (38°)PUTUT
IKNUR (5mi, 90°) 3300ft
RW35RIDUD (319°)RIDUD
IKNUR (5mi, 270°) 3300ft
 RNAVIKNUR 3300ft
URKUR (6mi, 0°) 2900ft
CYLJ (4mi, 353°) 1620ft
GOXIX (5mi, 6°) 3900ft
GOXIX (turn)
