Airports for X-Plane

Rankin Inlet

Airport details

CountryCanada
StateNunavut
RegionCY
AirspaceEdmonton Ctr
MunicipalityRankin Inlet
Elevation94ft (29m)
TimezoneGMT -6
Coordinates62.81067, -92.11462
Magnetic var
Typeland
Available sinceX-Plane v10.40
ICAO codeCYRT
IATA codeYRT
FAA coden/a

Communication

RANKIN INLET MF RDO122.200

Runway info

Runway 13 / 31
 length1823m (5981ft)
 bearing110° / 290°
 width46m (150ft)
 surfaceasphalt
 blast zone47m (154ft) / 46m (151ft)

Airport layout - taxiway location B


Taxiway locations

 13  31  A  B  C
Parking locations

 B  Term

Nearby beacons

codeidentifierdistbearingfrequency
YRTRANKIN INLET VOR/DME0.2320°112.40
RTRANKIN INLET NDB0.819°284
YXNWHALE COVE NDB37220°256

Instrument approach procedures

runwayairway (heading)route (dist, bearing)
RW13PIGBU (131°)PIGBU
ONDOS (5mi, 241°) 1700ft
RW13USBAB (97°)USBAB
ONDOS (5mi, 60°) 1700ft
 RNAVONDOS 1700ft
URPOX (6mi, 110°) 1700ft
CYRT (5mi, 110°) 137ft
EPVOR (2mi, 110°)
NOXAX (3mi, 110°) 2100ft
NOXAX (turn)
RW31OVESA (312°)OVESA
TIGEP (5mi, 60°) 1700ft
RW31SEGIK (277°)SEGIK
TIGEP (5mi, 240°) 1700ft
 RNAVTIGEP 1700ft
UDPEP (6mi, 290°) 1700ft
CYRT (5mi, 290°) 146ft
SERTU (2mi, 290°)
VOGOM (3mi, 290°) 2100ft
VOGOM (turn)

Disclaimer

The information on this website is not for real aviation. Use this data with the X-Plane flight simulator only! Data taken with kind consent from X-Plane 12 source code and data files. Content is subject to change without notice.
