Airports for X-Plane

Annabah - Rabah Bitat

Airport details

CountryAlgeria
StateAnnaba
RegionDA
AirspaceAlgiers Ctr
MunicipalityEl Bouni
Elevation16ft (5m)
TimezoneGMT +1
Coordinates36.82812, 7.80319
Magnetic var
Typeland
Available sinceX-Plane v10.40
ICAO codeDABB
IATA codeAAE
FAA coden/a

Communication

Rabah Bitat ANNABA TOUR118.700
Rabah Bitat ANNABA Approach119.700

Approach frequencies

ILS-cat-IRW18109.718.00mi
3° GSRW18109.718.00mi
Nearby Points of Interest:
El Feidja National Park

Runway info

Runway 18 / 36
 length3007m (9865ft)
 bearing189° / 9°
 width45m (148ft)
 surfaceasphalt
 displ threshold0m (0ft) / 101m (331ft)
Runway 05 / 23
 length2289m (7510ft)
 bearing58° / 238°
 width45m (149ft)
 surfaceasphalt
 blast zone33m (108ft) / 0m (0ft)

Airport layout - parking location A1


Parking locations

 A1  A2  A3  A4  E1  E2  E3  E4
 E5  E6

Nearby beacons

codeidentifierdistbearingfrequency
ANBANNABA VOR/DME0.669°113.50
BOANNABA NDB0.6184°392
