Ouagadougou
Airport details
| Country | Burkina Faso |
| State | Kadiogo |
| Region | DF |
| Airspace | Niamey Ctr |
| Municipality | Ouagadougou |
| Elevation | 1037ft (316m) |
| Timezone | GMT +0 |
| Coordinates | 12.35367, -1.51194 |
| Magnetic var | |
| Type | land |
| Available since | X-Plane v10.40 |
| ICAO code | DFFD |
| IATA code | OUA |
| FAA code | n/a |
Communication
| Ouagadougou OUAGA Tower | 118.100 |
| Ouagadougou AG VOICE OUAGA RDO | 120.300 |
| Ouagadougou OUAGA Approach | 118.100 |
Approach frequencies
| ILS-cat-I | RW04 | 110.1 | 18.00mi |
| 3° GS | RW04 | 110.1 | 18.00mi |
Nearby beacons
| code | identifier | dist | bearing | frequency |
|---|---|---|---|---|
| OG | OUAGADOUGOU VOR/DME | 0.4 | 187° | 112.90 |
| OUA | OUAGADOUGOU NDB | 1.4 | 214° | 333 |
| OG | OUAGADOUGOU NDB | 4.6 | 214° | 305 |
Departure and arrival routes
| Transition altitude | 3600ft |
| STAR starting points | distance | inbound heading | |
|---|---|---|---|
| ALL | |||
| TUMU1V | 85.8 | 19° | |
| BURO1V | 90.2 | 67° | |
| GUPO1V | 74.5 | 92° | |
| NURE1V | 52.6 | 155° | |
| GULI1V | 79.9 | 201° | |
| BULS1V | 59.7 | 253° | |
| OXID1V | 106.7 | 319° | |
| UMOV1V | 89.0 | 335° | |
| NAVO1V | 83.4 | 347° | |
| RW04 | |||
| TUMU1P, OPEN1P | 85.8 | 19° | |
| PORO1P | 100.4 | 57° | |
| BURO1P, SEMO1P | 90.2 | 67° | |
| GUPO1P, TIXO1P | 74.5 | 92° | |
| BIKO1A, NURE1P | 52.6 | 155° | |
| GULI1P, ARIB1A | 79.9 | 201° | |
| BULS1P, EDGA1B | 59.7 | 253° | |
| OXID1P, INEG1B | 106.7 | 319° | |
| LIKE1P, UMOV1P | 89.0 | 335° | |
| NAVO1P, NUTE1P | 83.4 | 347° | |
| RW22 | |||
| TUMU1T, OPEN1M | 85.8 | 19° | |
| PORO1K | 100.4 | 57° | |
| BURO1T, SEMO1K | 90.2 | 67° | |
| GUPO1T, TIXO1K | 74.5 | 92° | |
| BIKO1L, NURE1T | 52.6 | 155° | |
| GULI1T, ARIB1L | 79.9 | 201° | |
| EDGA1L, BULS1T | 59.7 | 253° | |
| OXID1T, INEG1M | 106.7 | 319° | |
| LIKE1M, UMOV1T | 89.0 | 335° | |
| NUTE1M, NAVO1T | 83.4 | 347° | |
Instrument approach procedures
| runway | airway (heading) | route (dist, bearing) |
|---|---|---|
| RW04 | AMPEK (57°) | AMPEK 2600ft POTIM (5mi, 123°) 2600ft |
| RW04 | BOSTA (10°) | BOSTA 2600ft POTIM (5mi, 303°) 2600ft |
| RNAV | POTIM 2600ft FD501 (6mi, 34°) 2600ft DFFD (6mi, 34°) 1084ft FD502 (4mi, 34°) AMPEK (16mi, 232°) 2600ft | |
| RW22 | KEROT (188°) | KEROT 2600ft LIMAM (5mi, 123°) 2600ft |
| RW22 | MOKER (239°) | MOKER 2600ft LIMAM (5mi, 303°) 2600ft |
| RNAV | LIMAM 2600ft FD503 (5mi, 214°) 2600ft DFFD (6mi, 214°) 1031ft FD504 (4mi, 214°) KEROT (16mi, 15°) 2600ft |
Holding patterns
| STAR name | hold at | type | turn | heading* | altitude | leg | speed limit |
|---|---|---|---|---|---|---|---|
| ARIB1L | LIMAM | VHF | left | 36 (216)° | 2600ft - 9000ft | 1.0min timed | 230 |
| BIKO1L | LIMAM | VHF | left | 36 (216)° | 2600ft - 9000ft | 1.0min timed | 230 |
| BULS1P | POTIM | VHF | right | 216 (36)° | 2600ft - 9000ft | DME 5.0mi | 230 |
| BULS1T | TATAB | VHF | left | 32 (212)° | < 9000ft | DME 5.0mi | 230 |
| BURO1P | POTIM | VHF | right | 216 (36)° | 2600ft - 9000ft | DME 5.0mi | 230 |
| BURO1T | TATAB | VHF | left | 32 (212)° | < 9000ft | DME 5.0mi | 230 |
| EDGA1L | LIMAM | VHF | left | 36 (216)° | 2600ft - 9000ft | 1.0min timed | 230 |
| GULI1P | POTIM | VHF | right | 216 (36)° | 2600ft - 9000ft | DME 5.0mi | 230 |
| GULI1T | TATAB | VHF | left | 32 (212)° | < 9000ft | DME 5.0mi | 230 |
| GUPO1P | POTIM | VHF | right | 216 (36)° | 2600ft - 9000ft | DME 5.0mi | 230 |
| GUPO1T | TATAB | VHF | left | 32 (212)° | < 9000ft | DME 5.0mi | 230 |
| LIKE1P | POTIM | VHF | right | 216 (36)° | 2600ft - 9000ft | DME 5.0mi | 230 |
| NAVO1P | POTIM | VHF | right | 216 (36)° | 2600ft - 9000ft | DME 5.0mi | 230 |
| NAVO1T | TATAB | VHF | left | 32 (212)° | < 9000ft | DME 5.0mi | 230 |
| NURE1P | POTIM | VHF | right | 216 (36)° | 2600ft - 9000ft | DME 5.0mi | 230 |
| NURE1T | TATAB | VHF | left | 32 (212)° | < 9000ft | DME 5.0mi | 230 |
| NUTE1P | POTIM | VHF | right | 216 (36)° | 2600ft - 9000ft | DME 5.0mi | 230 |
| OPEN1P | POTIM | VHF | right | 216 (36)° | 2600ft - 9000ft | DME 5.0mi | 230 |
| OXID1P | POTIM | VHF | right | 216 (36)° | 2600ft - 9000ft | DME 5.0mi | 230 |
| OXID1T | TATAB | VHF | left | 32 (212)° | < 9000ft | DME 5.0mi | 230 |
| PORO1P | POTIM | VHF | right | 216 (36)° | 2600ft - 9000ft | DME 5.0mi | 230 |
| SEMO1P | POTIM | VHF | right | 216 (36)° | 2600ft - 9000ft | DME 5.0mi | 230 |
| TIXO1P | POTIM | VHF | right | 216 (36)° | 2600ft - 9000ft | DME 5.0mi | 230 |
| TUMU1P | POTIM | VHF | right | 216 (36)° | 2600ft - 9000ft | DME 5.0mi | 230 |
| TUMU1T | TATAB | VHF | left | 32 (212)° | < 9000ft | DME 5.0mi | 230 |
| UMOV1P | POTIM | VHF | right | 216 (36)° | 2600ft - 9000ft | DME 5.0mi | 230 |
| UMOV1T | TATAB | VHF | left | 32 (212)° | < 9000ft | DME 5.0mi | 230 |
| *) magnetic outbound (inbound) holding course | |||||||
