Airports for X-Plane

Antwerp - Antwerp Deurne

Airport details

CountryBelgium
StateAntwerp
RegionEB
AirspaceBrussels Ctr
Elevation39ft (12m)
TimezoneGMT +1
Coordinates51.18723, 4.45977
Magnetic var
Typeland
Available sinceX-Plane v10.32
ICAO codeEBAW
IATA codeANR
FAA coden/a

Communication

Antwerp Deurne ANTWERP Ground Control121.800
Antwerp Deurne ANTWERP Tower135.200
Antwerp Deurne BRUSSELS Approach118.250

Approach frequencies

ILS-cat-IRW29111.7518.00mi
3° GSRW29111.7518.00mi

Runway info

Runway 11 / 29
 length1510m (4954ft)
 bearing103° / 283°
 width55m (180ft)
 surfaceasphalt
 displ threshold145m (476ft) / 0m (0ft)

Airport layout - taxiway location E


Taxiway locations

 A1  A2  B1  B2  E  F  G  H
 J  NO
Parking locations

 111  112  113  12  121  122  123  124
 125  131  132  14  16  20  21  22
 23  24  25  30  31  North  South

Nearby beacons

codeidentifierdistbearingfrequency
ANTANTWERP (DEURNE) VOR/DME0.576°113.50
ONWANTWERP NDB4.1101°355
NIKNICKY VOR/DME10.4265°117.40
BUNBRUNO VOR/DME14.9100°110.60
OPBRUSSELS NATIONAL NDB15.7152°402
WDTWOENSDRECHT TACAN16.2336°115
OBBRUSSELS NDB17150°293
BUBBRUSSELS VOR/DME17.3165°114.60
AFIAFFLIGEM VOR/DME20.7229°114.90
OZBRUSSELS NATIONAL NDB21.6179°314
HULHULDENBERG VOR/DME27.1157°117.55
BBEBEAUVECHAIN TACAN28.3144°116
HTBBEAUVECHAIN NDB28.4145°381
GZRGILZE-RIJEN TACAN28.851°116.40
FLOFLORA VOR/DME31.5115°112.05
EHVEINDHOVEN TACAN37.774°117.20
MAKMACKEL NDB38.7257°360
ONCCHARLEROI NDB42172°323
CIVCHIEVRES VORTAC43.8226°113.20
GSYGOSLY (CHARLEROI) VOR/DME44181°115.70
RTMROTTERDAM VOR/DME47.22°110.40
FRTDME50.421°117.15
BFSFLORENNES TACAN57.2168°111.50

Departure and arrival routes

Transition altitude4500ft
SID end pointsdistanceoutbound heading
RW11
 SOND5E14mi90°
 GILO3E, GILO3F, GILO3G29mi144°
 NIK4E10mi265°
 PUTY6E, PUTY2G12mi326°
RW29
 SOND6C14mi90°
 GILO3C, GILO4B, GILO4D29mi144°
 NIK5C10mi265°
 PUTY2B, PUTY6C12mi326°

STAR starting pointsdistanceinbound heading
ALL
 ARVO3A53.056°
 TULN4A58.462°
 KOK4A68.187°
 WODY3A13.5157°
 BATY4A61.7291°
 LNO4A59.5296°

Instrument approach procedures

runwayairway (heading)route (dist, bearing)
RW11ANT (256°)ANT 3000ft
NIK (11mi, 265°) 3000ft
ARPUR (4mi, 285°)
BEVRI (5mi, 53°) 3000ft
 RNAVBEVRI 3000ft
AW11F (4mi, 103°) 3000ft
EBAW (8mi, 104°) 78ft
AW011 (4mi, 101°)
ANT (4mi, 284°) 2000ft

Holding patterns

STAR namehold attypeturnheading*altitudelegspeed limit
ARVO3AANTNDBleft297 (117)°8000ft - 14000ft1.0min timedICAO rules
BATY4AANTNDBleft297 (117)°8000ft - 14000ft1.0min timedICAO rules
KOK4AANTNDBleft297 (117)°8000ft - 14000ft1.0min timedICAO rules
LNO4AANTNDBleft297 (117)°8000ft - 14000ft1.0min timedICAO rules
TULN4AANTNDBleft297 (117)°8000ft - 14000ft1.0min timedICAO rules
WODY3AANTNDBleft297 (117)°8000ft - 14000ft1.0min timedICAO rules
*) magnetic outbound (inbound) holding course
